Case IH Tractor 7100,7200 Series Less engine Service Manual 8-92038
FILE DETAILS:
Case IH Tractor 7100,7200 Series Less engine Service Manual_8-92038
Size : 1.69 GB
Format : PDF
Language : English
Brand: Case IH
Type of machine: Tractor
Type of document: Service Manual
Model: 7100,7200 Series Less engine
Part No: 8-92038
TABLE OF CONTENTS:
- Case IH Tractor 7100,7200 Series Less engine Service Manual 8-92038
- General
- Engine
- Fuel System
- Electrical
- Steering
- Power Train
- Brakes
- Hydraulics
- Chassis
DESCRIPTION:
- A service men must correctly find the cause of the problem before making any repairs or adjustments on an engine.
- A service man must find and remove the cause of the problem. Too many repairs are made without removing the causes that made the repair necessary.
- Three conditions are needed for an engine to start and work correctly:
- 1. FUEL 2. COMPRESSION 3. IGNITION
- An engine will not start or operate correctly during the power range if any of these conditions are not present or have restrictions because of mechanical causes.
- 1. FUEL. Problems with the fuel system can be pre- sent in: A. the fuel tank. B. the fuel filters. C. the injection pump. D. the injectors. E. the injection pump timing.
- 2. COMPRESSION. Compression in an engine is the result of increasing the air pressure. Correct engine compression will be changed by: A. the condition of the air cleaner. B. muffler restriction. C. valve condition and operation. D. valves not being correctly adjusted. E. a defect in the gasket of the cylinder head. F. the condition of sleeves, rings, pistons and camshaft. G. camshaft timing.
- 3. IGNITION. Ignition is the result of good compres- sion. Compression causes heat. Heat causes the fuel in the cylinders to burn. The fuel injectors atomize the fuel that is being sent to the cylinders in a spray pattern.
- Timing the fuel injection pump to the engine to an exact degree is necessary for correct ignition. The following pages will give the problems and the causes and the adjustments and repairs required to correct the problems. Find your problem in the Table of Contents and see the pages that are given for the causes and repairs.
