BT L23X; BT L23QX; BT L23UX; BT L23UQX Quality Parts Manual – PDF DOWNLOAD
FILE DETAILS:
BT L23X; BT L23QX; BT L23UX; BT L23UQX Quality Parts Manual – PDF DOWNLOAD
Language : English
Pages : 35
Downloadable : Yes
File Type : PDF
Size: 1.53 MB
TABLE OF CONTENTS:
BT L23X; BT L23QX; BT L23UX; BT L23UQX Quality Parts Manual – PDF DOWNLOAD
Valid for machine number – 2430800 AA-
Ordering number – 177960
Date – 2000-09-11/ ITS/ ESIT
Language – GB; SE; DE; FR
0000 Chassis 4
Chassi; Chassis; Châssis 4
3000 Brake/Wheel/Caterpillar system 4
Broms-/Hjul/Bandsystem; Brems-/Rad-/Bandsystem; Freins/Roues/ Chenilles 4
4000 Steering system 5
Styrsystem; Steuer-/Lenksystem; Système de direction 5
6000 Hydraulic/pneumatic system 5
Hydraulik/pneumatik; Hydraulikanlage/Pneumatik; Système hydraulique/pneumatique 5
0380-159 6
0380-159 Fork frame (low lifters) [2000-03-21] 6
0380-160 8
0380-160 Fork frame (low lifters) [2000-03-21] 9
0640-06511
0640-065 Driver controls ( mechanical ) [2000-03-28]11
0850-13012
0850-130 Signs, warnings, decals [2000-05-09]13
3360-00514
3360-005 Parking brake drum/disc assembly [2000-09-01]15
3550-05516
3550-055 Fork/support arm wheels [2000-03-27]16
3550-05616
3550-056 Fork/support arm wheels [2000-03-27]16
3550-05717
3550-057 Fork/support arm wheels [2000-03-27]17
3550-05817
3550-058 Fork/support arm wheels [2000-03-27]17
3570-02318
3570-023 Wheel locating points [2000-02-25]18
3570-02518
3570-025 Wheel locating points [2000-02-25]18
3570-02619
3570-026 Wheel locating points [2000-02-24]19
3570-02820
3570-028 Wheel locating points [2000-02-24]20
3580-00121
3580-001 Guide rollers/wheels [2000-03-27]21
3580-00221
3580-002 Guide rollers/wheels [2000-02-25]21
3580-00622
3580-006 Guide rollers/wheels [2000-02-25]22
3590-00823
3590-008 Steered wheel [2000-03-22]23
4110-17424
4110-174 Steering arm / wheel / lever [2000-09-04]25
6400-01426
6400-014 Manual pump unit, jack [1999-06-22]26
6400-01527
6400-015 Manual pump unit, jack [1997-04-04]27
6410-00128
6410-001 Pump unit housing/tank [2000-05-25]28
6410-00329
6410-003 Pump unit housing/tank [2000-03-27]29
6420-00130
6420-001 Lift cylinder/piston [1999-06-22]30
6420-00331
6420-003 Lift cylinder/piston [1996-11-26]31
6440-00132
6440-001 Manual pump [2000-03-27]32
6460-00133
6460-001 Valve functions [2000-03-27]33
6460-00434
6460-004 Valve functions [1995-11-30]35
