Fiat Allis FR35 Wheel Loader Transmission Service Manual
FILE DETAILS:
Fiat Allis FR35 Wheel Loader Transmission Service Manual
Language : English
Pages : 61
Downloadable : YES
Format : PDF
Part No : 73148892
DESCRIPTION:
Fiat Allis FR35 Wheel Loader Transmission Service Manual
FOREWORD:
Always furnish serial number it making an inquiry to dealerortactory about this machine. Many equipment owners employthe Dealer Service Department for all work other than routine lubrication and minor service. This practice is encouraged. as our Dealers are well iniomied and equipped to render efficient service by factory trained mechanics This manual may not be reprinted or reproduced. either in whole or in part. without written permission of Fiataiils ®. Illustrations show standard and optional items.
GENERAL :
Study the Operation and Maintenance Instruction Manual be- fore starting, operating, maintaining, fueling. or servicing machine. – Read and heed all machine-mounted safety signs before starting, operating, maintaining, fueling or servicing machine. Machine~mounted safety signs have been color coded yellow with black border and lettering for WARNING and red with white border and lettering for DANGER points. Never attempt to operate the machine or its tools from any position other than seated in the operator’s seat. Keep head, body, limbs, hands and feet inside operator’s compartment at alltirnes to reduce exposure to hazards outside the operator’s compartment.
- Do not allow unauthorized personnel to operate service or maintain this machine. Aiways check work area for dangerous features. The follow. ing are examples of dangerous work areas: slopes. over hangs, timber. demolitions. fire. high walls, drop off, back fills, rough terrain, ditches. ridges, excavations, heavy traffic, crowded parking, crowded maintenance and closed areas. Use extreme care when in areas such as these. An operator must know the machine‘s capabilities. When working on slopes or near drop offs be alert to avoid loose or soft conditions that could cause sudden tipping or loss of control.
- Do not jump on or off machine. Keep two hands and one foot, or two feet and one hand, in contact with steps grab rails and handles at all times. Do not use controls or hoses as hand holds when climbing on or off machine. Hoses and controls are movable and do not provide a send support. Controls also may be inadvertently moved causing accidental machine or equipment movement. Keep operator‘s compartment, stepping points, grab-rails and handles clear of foreign objects, oil. grease. mud or snow accumulation to minimize the danger of sliping or stumbling. Clean mud or grease from shoes before attempting to mount or operate the machine.
- Be careful of slippery conditions on stepping points, hand rails. and on the ground. Wear safety boots orshoes that have a high slip resistant sole material. ‘ Foryour personal protection. Do not attempt to climb on or off machine while machine is in motion. Never leave the machine unattended with the engine running. Always look up machine when leaving it unattended. Return keys to authorized security. Heed all shut down procedures of the Operation and Maintenance instruction Manual.
TABLE OF CONTENTS:
Fiat Allis FR35 Wheel Loader Transmission Service Manual
FORWARD
GENERAL INFORMATION
11 DESCRIPTION AND OPERATION
12 Specriicatlons
121 General
122 Oil System
123 Oil Pressure
124 Power Takecli Provisions
125 Gear Ratios
126 Controls
TRANSMISSION TESTING AND TROUBLESHOOTING
21 BEFORE TESTING OR TROUBLESHOOTING
221 Machine Starts But Will Not Move In Any Range
222 No Power In One Particular Range Foward Or Reverse
223 No Power In Forward Reverse Good
224 No Power In Reverse Fomard Good
225 Machine Lacks Power Under load
226 Machine Travels In Neutral When eEgine Is Accelerated In Forward Or
Reverse, But Not Both
227 Machine Travels In Neutral When Engine Is Accelerated
In Forward And Reverse
228 Transmission Overheating, Power Good
23 MAIN PRESSURE TESTING (CLUTCHES)
231 Primary Pressure Testing (using the instrument panel transmission
pressure gauge)
232 Final Pressure Testing (reference foldout schematics at back of manual)
24 TORQUE CONVERTER, AND IMPLEMENT PUMP, STALL TESTING
25 TRANSMISSION PUMP FLOW TESTING
TRANSMISSION INSTALLATION
41 OIL COOLER CLEANING
42 TRANSMISSION INSTALLATION
43 ASSEMSLE AND ADJUSTTRANSMISSION UNKAGE
431 Transmission Linkage Arrangements
432 Transmission Linkage Adjustments
TRANSMISSION DISASSEMBLY(and housingrs) assembly)
52 EXTERNAL COMPONENT REMOVAL”
53 TORQUE CONVERTER HOUSING REMOVAL AND CONVERTER DISASSEMBLY
54 TORQUE CONVERTER HOUSING DISASSEMBLY/ASSEMBLY
55 ADAPTER HOUSING REMOVAL, DISASSEMBLY/ASSEMBLY
56 MAIN (CLUTCH) HOUISNG DISASSEMBLY/REi/IOVAL
57 DROP-Box DISASSEMBLY (transfer gear housrng)
58 DROP- BOX ASSEMBLY Itransfer gear housrrg)
59 MAIN CONTROL VALVE REBUILD
510 MAIN PRESSURE REGULATOR VALVE REBUILD NOTES
511 TRANSMISSION OIL PUMP REBUILD NOTES
TRANSMISSION ASSEMBLY
61 MAIN (CLUTCH) HOUSING ASSEMBLY AND INSTALLATION
62 MAIN HOUSING ASSEMBLY (forward/reverse components)
63 ADAPTER HOUSING ASSEMBLY AND INSTALLATION
64 TORQUE CONVERTER HOUSING ASSEMBLY AND INSTALLATION
65 INSTALLING EXTERIOR COMPONENTS
SCHEMATICS
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
PLEASE NOTE:
- This is the SAME manual used by the dealers to troubleshoot any faults in your vehicle. This can be yours in 2 minutes after the payment is made.
- Contact us at [email protected] should you have any queries before your purchase or that you need any other service / repair / parts operators manual.
