Fiat Allis Wheel Loader FW110 FW130 Service Manual
FILE DETAILS:
Fiat Allis Wheel Loader FW110 FW130 Service Manual
Size : 24.9 MB
Format : PDF
Language : English
Brand: Fiat
Type of machine: Wheel Loader
Type of document: Service Manual
Model: Fiat Allis FW110 FW130 Wheel Loaders
Number of Pages: 355 pages
Part Number: 60402223
DESCRIPTION:
Fiat Allis Wheel Loader FW110 FW130 Service Manual
SAFETY RULES:
GENERALITIES:
Read this Manual carefully before starting. operating. maintaining. fuelling or servicing the machine. Read and comply with all safety precautions before any intervention- Do not allow unauthorised personnel to operate orservlce this machine. Do not wear rings. wrist watches, jewellery, loose or hang- ing garments. such as ties, torn clotting. scarves, unbur- toned or unzipped jackets that can get caught in moving parts.
- Wear certified safety clothes such as: hard hat. no- slip footwear, heavy gloves, earprotection. safety glasses, reflector vests, respirators. Ask your employer about spe- cific safety equipment requirements. Keep the operator’s compartment, step plates. grab-rails and handles clean and clear of foreign objects, oil, grease, mud or snow to minimize the danger of slipping or stum- bling. Remove mud or grease from your shoes before attempting to mount or operate the machine. 00 notiump on oroti the machine. Always keepbothhands and one foot. or both feet and one hand In contact with steps and grab rails.
- 00 not use controls or hoses as hand holds when climbing on or off the machine. Hoses and controls are movable parts and do not provide solid support. Besides, controls may be inadvertently moved and cause unexpected move- ment of the machine or its attachments.
- Never operate the machine or its attachmenm from any position other than sitting in the driver’s seat. Keep head. body. limbs, hands and feet inside the opera- tor‘s compartment at all times to reduce exposure to extemat hazards .
- Be careful of possible slippery conditions of the steps and hand rails as well as of the ground around the machine. 00 not leave the machine until it is has come to a complete stop. Check the seat safety belt at least twice per year and replace it if it shows signs of near, fraying or other weakness that could lead to failure.
STARTING:NEVER START 0R OPERATE AN UNSAFE MACHINE. Before operating a machine, always ensure that any unsale condition has been satisfactoniy remedied. Check brakes, steering and attachment controls before moving. Advise the proper maintenance authority ol any mallunctioning part or system. Be sure all protective guards or panels are in place. and all safety devices provided are In place and in good operating conditions.
- Be sure exposed personnel In the area of operation are clear of the machine before moving it or its attachments. WALK COMPLETELY AROUND the machine before mounting. Sound horn. Obey flag man, safety signals and signs. Before starting machine, check, adjust and lock the operator’s seat for maximum comfort and control of the machine. Fasbn your seat belt (when provided).
- Obey all flag signals and signs. Duetc the presence on the machine of flammable fluids, never check or fill fuel reservoirs or batteries near open flames, smoking materials or sparks. REMEMBER THAT STARTING FLUID IS FLAMMABLE Follow recommendations printed on containers and in the Operation and Maintenance Manual. DO NOT PUNCTURE OR BURN CONTAINERS. Conteiners must bestored in fresh places, out of reach of unauthorised persons. Follow strictly the instructions provided by the Manufacturer. Never use these products near open flames. smoking materials or sparks.
OPERATION: Check the fasteners of wheels and rims before starting a working shift. If necessary, retighten to the prescribed toque. Do not run the engine of this machine in closed areas without proper ventilation to remove deadly exhaust gases.
- RoilOver Protective Structures are required on loaders. dozers, graders. excavators. NEVER OPERATE ma- chines without ROPS. Matte sure the Operator’s compartment is free of foreign objects, especialty it not firmly secured.
- Never use the machine to transport objects, unless proper securing poirts are provided. DO NOT CARRY RIDERS ON MACHINE Study and familiarize with escape routes alternate to normal exit routes. Seat belts are required to be provided with Roll Over Protection Structuresor cabs. Keep safety belts fastened around you during operation. For your personal protection, do not climb on or off machine while machine in motion.
