FIAT ALLIS 545B WHEEL LOADER PARTS MANUAL – PDF DOWNLOAD
FILE DETAILS:
FIAT ALLIS 545B WHEEL LOADER PARTS MANUAL – PDF DOWNLOAD
Format: PDF
Language: English
Brand: Fiat Allis
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
FIAT ALLIS 545B WHEEL LOADER PARTS MANUAL – PDF DOWNLOAD
INSTRUCTIONS FOR ORDERING PARTS:
- Order parts from the dealer covering the local territory.
- ALWAYS GIVE THE MODEL AND SERIAL NUMBER OF MACHINE. IF PARTS ARE FOR AN ASSEM-BLY WHICH HAS A MODEL AND/OR SERIAL NUMBER (SUCH AS ENGINE ASSEMBLY, PUMP AS-SEMBLY), ALSO INCLUDE THIS INFORMATION.
- To obtain parts promptly, give part name and part number.
- Give post office address, town, county and state where parts are to be shipped. Also specify whether material is to be shipped by freight; or parcel post.
- Confirm all telephone or telegraph orders in writing.
- No credit will be allowed on parts unless they are returned to the dealer from whom they were purchased; from there they will be returned, at the customer’s expense, to the factory for inspection.
- Unless claims for shortages or errors are made immediately upon receipt of goods, they will not be con-sidered.
- When broken goods are received, a full description of the damage should be made by the carrier agent on the freight bill. If this description is insisted upon, full damage can always be collected from the transportation company.
- No responsibility is assumed for delay or damage to merchandise while in. transit. Our responsibility ceases upon delivery of shipment to the transportation company from whom a receipt is received showing that shipment was in good condition when delivered to them; therefore, claims (if any) should be filed with the transportation company and not with Fiat-Allis.
- The right is reserved to change the construction or material of any parts where it seems desirable to do so without incurring the obligation of installing such changes on units already delivered.
TABLE OF CONTENTS:
FIAT ALLIS 545B WHEEL LOADER PARTS MANUAL – PDF DOWNLOAD
Air Application Valve Assembly 152
Air Brake System 132
Air Cleaner 54
Air Compressor 144
Air Heater 37
Air Heater Kit 37A
Air Horn & Lines 143
Air Tank & Lines I 132
Air Tank Drain Valve 135
Alcohol Injector 136
Alternator & Mounting 2448,245
Ammeter Assembly 240
Automatic Bucket Leveler 180,183
Automatic Boom Kick-Out 186,189
Axle & Supports 106
Axle Housing Assembly
Front 107
Rear 117
Back-up Alarm 236
Batteries & Cables 232,232A
Battery Covers 218
Bonnet Assembly 218
Boom 222
Boom Kick-Out, Hydraulic 186
Brake Air Lines 132
Brake Assembly
Front 122
Rear 124
Parking 120 Brake Systems
Air 132
Hydraulic 128
Bucket 225C,224,225A
Bucket(Multi-Purpose) 226
Bucket Hydraulics(Multi-Purpose) 228
Bucket Indicator(Multi-Purpose) 226
Bucket Level Indicator 192
Bucket Leveler, Hydraulic 180,183
Cab and Wiper Assembly 252,255
Cab Heater 267,267A
Cab Rear Window 257,258
Camshaft 20
Canopy Assembly 268
Charging Oil Pump, Transmission 89
Clutch Cut-Off Valve 131
Cold Weather Starting Aid 36
Compressor Crankcase 156
Compressor Cylinder Block 146
Compressor Cylinder Head 149
Controls, Hydraulic 200,202,204
Control Valve Parts 197
Counterweight 214
Cowl & Platform 210
Crankshaft 14
Cranking Motor 233
Cylinder
Bucket(Multi-purpose) 230,231
Dump 176
Lift 178
Steering 164
Cylinder Block 12
Cylinder Head 18
Dash Light 240
Decals 279
Defroster Fan 254,254A
Demand Valve Assembly 165
Differential Carrier Assy , front 108
Differential Carrier Assy , rear 112
Differential No-Spin 115,116
Dipstick, Transmission Oil 100
Discharge Tube, Hydraulic Tank 193
Door Assembly, Cab
259,261
Drain Valve
135
Drawbar 213
Drive Shaft Assembly 102,103,104
Drive Shaft Group 101
Dump Cylinder Assembly 176
Electrical System 234
Emergency Brake Control Group 140
Emergency Control Valve Assembly 141
Emergency Steering Motor & Pump 269
Emergency Steering Group 270,272
Engine Air Heater 37
Engine & Mounting 11
Engine Coolant Heater 30
Engine Controls
Engine Oil Cooler 56,11;
Engine Oil Pump 27
Engine Shut Off Control 57
Engine Water Filter 58
Exhaust Manifold 34
Exhaust Tube = 35,49
Fan, Defroster 254
Fan, Engine 60
Fenders 209,218
Filter
Engine Oil 28 29,31
Fuel 40;40A
Hydraulic Tank 193
Transmission Oil 98,99
Flex Disk & Converter Drive 64
Fluid Starting 36
Floodlight 239
Flywheel Assembly 25
Flywheel Housing 24
Forward Clutch & Planetary 73
Frame 216
Front Plate & Gear Cover 23
Front Piping Group 174
Fuel Filter & Lines 40,40A
‘Fuel Injection Pump 43,44A
Fuel Injection Pump, Aneroid 448
Fuel Shut-Off(Mechanical) 57
Fuel Tank & Lines 38
Governor(Compressor) 150
Grill 218
Hand Primer Pump 40C
Headlight 239
Handle & Rails 209
Heater, Cab 267
High Range Clutch 252 High Range Clutch & Transfer Drive Group 78
Hood 218
Horn, Air 142
Horn, Electric 142A
Host Parts 7 Hour Meter
Mechanical 16
Electrical 234
Hydraulic Brake System 135
Hydraulic Controls 200,202,204
Hydraulic Piping 171,175
Hydraulic Piping & Cylinders 171
Hydraulic Power Steering System 156
Hydraulic Pump Assembly 170
Hydraulic Pump & Piping 168A,169
Hydraulic Tank & Valve 193
Hydraulic Tank Filter 193
Idler Gear Assembly 22
Injection Nozzle 47, 47A
Injection Nozzles & Lines 45,46A,46C
Injection Pump, Fuel 43,44A
Instrument Panel Cover 244
Instrument Panel & Gauges 242
Instrument Panel & Electrical Components 240
Instrument Panel & Wiring(ROPS) 250
Intake Manifold 33
Ladder, Hand Rail & Fenders 209
Ladder-Right Side 209
Lift Cylinder Assembly Parts 178
Light Assembly Parts 238,239,247B
Lights & Wiring 236
Linkage Group 222
Logging Counterweight & Drawbar 214
Low Range Clutch & Transfer Drive Gear 80
Lube Oil Filter .
28
Manifold
Exhaust 34
Intake 33
Master Cylinder Assembly.. 138,180,183,186,189
Mirror, Rear View
Moisture Ejector
Muffler
Multi-Purpose Bucket
Multi-Purpose Bucket Hydraulics
Noise Suppression
Nozzle and Holder Assembly
Numerical Index Rear
Oil Cooler
Oil Filter, Engine
Oil Pan
Oil Pump
Packaged Parts
Painting & Marking
Parking Brake Assembly
Parking Brake Control
Parking Brake Warning Light
Piston & Connecting Rod
Pivot Pin, Frame
Platform
Power Cluster
Power Steering Cylinder
Power Steering Pump Assembly
Power Take-Off
Pump
Engine Oil 27
Fuel Injection 43
Hand Primer 40C
Hydraulic 170
Steering 161,166,167,168
Transmission Charging Oil 89
Water 60
Radiator & Fan Guard 62
Radiator Assembly 61
Radiator Support, Hood & Fenders 218
Rear Axle Disconnect 86
Rear Axle Disconnect Controls 96
Rear Output Group 84
Rear Window Assembly 257
Relief Valve Assembly 163
Reverse Clutch & Planetary 76
Safety Locking Bar 216
Seat Belt 221
Seat & Mounting 220
Shaft & Hub, Front
Shaft & Hub, Rear
Side Panels
Sight Gauge
Slave Cylinder
Sound Suppression Group
Starter
Steering Cylinder
Steering Cylinder & Piping
Steering Gear Assembly
Steering Gear & Linkage
Steering Pump, Demand Valve & Lines
Strainer & Magnet
Suction Fan
Tail Light/Stoplight Assembly
Tank, Fuel
Tank, Hydraulic
Thermostat & Housing
Tie Rod Assembly
Timing Gear Housing
Tire Inflation Kit
Tires
Tools
Torque Converter
Torque Converter Housing
Transmission Assembly Transmission,
Charging Oil Pump
Control Group
Control Valve
Cooling Lines & Dipstick
Filter & Mounting
Housing & Covers
Oil 98,99
Oil Cooler 32
Parking Brake 120
Rear Housing 88
Rear Mounting 60
Turbocharger and Lines 49
Turbocharger Asgembly 51
Turbine Driven Gear & Freewheel Unit 70
Turn Signals 246,248
Undercarriage Guard 215
Universal Joint Cartridge & Support 105
Valve
Air Application 152
Air Horn 143
Air Tank 132
Clutch Cut-Off 131
Demand 161,165
Engine Oil Pressure 12 Hydraulic Control 197
Relief, Steering 156,163
Steering 158
Transmission Control 91
Valve Operating Mechanism 20
Warning System-
Vigh Temperature Low Pressure 247A
Water Filter 58
Water Pump & Fan 60
Water Separator 41
Wheel Cylinder Assembly – 126
Wheel Group 207
Window Assembly(Rear Cab) 257,258
Window Assembly(Slide) 260A
Windshield Wiper Group, Rear 264
Wiper Group
