Bobcat Compact Excavator E50 Operation & Maintenance Manual – PDF DOWNLOAD
FILE DETAILS:
Bobcat Compact Excavator E50 Operation & Maintenance Manual – PDF DOWNLOAD
Language : English
Pages : 252
Downloadable : Yes
File Type : PDF
DESCRIPTION:
Bobcat Compact Excavator E50 Operation & Maintenance Manual – PDF DOWNLOAD
FOREWORD
This Operation & Maintenance Manual was written to give the owner / operator instructions on the safe operation and maintenance of the Bobcat excavator. READ AND UNDERSTAND THIS OPERATION & MAINTENANCE MANUAL BEFORE OPERATING YOUR BOBCAT EXCAVATOR. If you have any questions, see your Bobcat dealer. This manual may illustrate options and accessories not installed on your excavator.
SAFETY INSTRUCTIONS
Before Operation
- Carefully follow the operating and maintenance instructions in this manual. The Bobcat excavator is highly maneuverable and compact. It is rugged and useful under a wide variety of conditions.
- This presents an operator with hazards associated with off highway, rough terrain applications, common with Bobcat excavator usage. The Bobcat excavator has an internal combustion engine with resultant heat and exhaust. All exhaust gases can kill or cause illness so use the excavator with adequate ventilation.
- The dealer explains the capabilities and restrictions of the Bobcat excavator and attachment for each application. The dealer demonstrates the safe operation according to Bobcat instructional materials, which are also available to operators. The dealer can also identify unsafe modifications or use of unapproved attachments.
- The attachments and buckets are designed for a Rated Lift Capacity. They are designed for secure fastening to the Bobcat excavator. The user must check with the dealer, or Bobcat literature, to determine safe loads of materials of specified densities for the machine – attachment combination.
The following publications and training materials provide information on the safe use and maintenance of the Bobcat machine and attachments:
- The Delivery Report is used to assure that complete instructions have been given to the new owner and that the machine and attachment is in safe operating condition.
- The Operation & Maintenance Manual delivered with the machine or attachment gives operating information as well as routine maintenance and service procedures. It is a part of the machine and can be stored in a container provided on the machine. Replacement Operation & Maintenance Manuals can be ordered from your Bobcat dealer.
- Machine signs (decals) instruct on the safe operation and care of your Bobcat machine or attachment. The signs and their locations are shown in the Operation & Maintenance Manual. Replacement signs are available from your Bobcat dealer.
- An Operator’s Handbook is fastened to the operator cab of the excavator. Its brief instructions are convenient to the operator. The handbook is available from your dealer in an English edition or one of many other languages. See your Bobcat dealer for more information on translated versions.
- The AEM Safety Manual delivered with the machine gives general safety information.
- The Compact Excavator Operating Training Course is available through your Bobcat dealer. This course is intended to provide rules and practices of correct operation of the Bobcat excavator. The course is available in English and Spanish versions.
- Service Safety Training Courses are available from your Bobcat dealer. They provide information for safe and correct service procedures.
TABLE OF CONTENTS:
Bobcat Compact Excavator E50 Operation & Maintenance Manual – PDF DOWNLOAD
OPERATOR SAFETY WARNING 2
CONTENTS 3
FOREWORD 4
BOBCAT COMPANY IS ISO 9001 CERTIFIED 5
REGULAR MAINTENANCE ITEMS 5
SERIAL NUMBER LOCATIONS 6
Excavator Serial Number 6
Engine Serial Number 6
DELIVERY REPORT 6
EXCAVATOR IDENTIFICATION 7
FEATURES, ACCESSORIES AND ATTACHMENTS 8
Standard Items 8
Options And Accessories 8
Attachments 8
Buckets Available 8
Falling-Object Guards (FOGS) 9
Special Applications Kit 9
Special Applications Kit Inspection And Maintenance 9
SAFETY AND TRAINING RESOURCES 10
SAFETY INSTRUCTIONS 11
Before Operation 11
Safe Operation Is The Operator’s Responsibility 12
Safe Operation Needs A Qualified Operator 12
Avoid Silica Dust 13
FIRE PREVENTION 13
Maintenance 13
Operation 13
Electrical 13
Hydraulic System 14
Fueling 14
Starting 14
Spark Arrester Exhaust System 14
Welding And Grinding 14
Fire Extinguishers 14
PUBLICATIONS AND TRAINING RESOURCES 15
MACHINE SIGNS (DECALS) 16
Pictorial Only Safety Signs 18
OPERATING INSTRUCTIONS 20
INTENDED USE 24
INSTRUMENTS AND CONSOLES 25
Cab Interior Light 25
Left Console 25
Right Console 26
Instrument Panel – Standard 27
Instrument Panel – Standard (Data Display Screen) 29
Instrument Panel – Deluxe 30
Radio Option 31
STD / ISO Selector Valve 33
Raising And Lowering The Console 33
Two-Speed Travel (Without Angle Blade Option) 34
Two-Speed Travel (With Angle Blade Option) 34
Auto-Shift Drive System 34
Auto Idle Feature 35
OPERATOR CANOPY (ROPS / TOPS) 36
Description 36
OPERATOR CAB (ROPS / TOPS) 36
Description 36
Cab Door 37
Front Window 38
Front Wiper 39
Window Washer Reservoir 39
Right Side Windows 40
Right Side Windows 41
Heating, Ventilation, And Air Conditioning Ducting 42
EMERGENCY EXIT 43
Right Side Rear Window 43
Front Window 43
MOTION ALARM SYSTEM 44
Operation 44
TRAVEL CONTROLS 45
Forward And Reverse Travel 45
Turning 45
HYDRAULIC CONTROLS 47
Description 47
STANDARD Control Pattern 47
ISO Control Pattern 48
Quick Couplers 49
Auxiliary Hydraulics – Standard Instrument Panel 50
Auxiliary Hydraulics – Deluxe Instrument Panel 51
Relieve Hydraulic Pressure With Standard Instrument Panel (Excavator And Attachment) 52
Relieve Hydraulic Pressure With Deluxe Instrument Panel (Excavator And Attachment) 52
Secondary Auxiliary Hydraulics 53
Relieve Secondary Auxiliary Hydraulic Pressure (Excavator And Attachment) 53
Return To Tank Valve 54
OVERLOAD WARNING 54
Description 54
Operation 54
BLADE CONTROL LEVER 55
Raising And Lowering Blade 55
Angling Blade (If Equipped) 55
ENGINE SPEED CONTROL DIAL 56
Setting Engine Speed (RPM) 56
ECO Mode (With Deluxe Instrument Panel Only) 56
BOOM SWING 57
Operation 57
BOOM LOAD HOLDING VALVE 58
Description 58
Lowering Boom With Load Holding Valve 58
ARM LOAD HOLDING VALVE 60
Description 60
Lowering Arm With Load Holding Valve 60
DAILY INSPECTION 62
Daily Inspection And Maintenance 62
PRE-STARTING PROCEDURE 63
Operation & Maintenance Manual And Operator’s Handbook Locations 63
Entering The Excavator 63
Seat Adjustment 64
Seat Belt 64
Control Console 65
Mirror Adjustment 65
STARTING THE ENGINE 66
Key Switch 66
Keyless 67
Deluxe Instrument Panel 68
Warming The Hydraulic System 69
Cold Temperature Starting 69
Cold Temperature Engine Speed Control 69
MONITORING THE DISPLAY PANELS 70
Instrument Panel 70
Warning And Shutdown 70
STOPPING THE ENGINE AND LEAVING THE EXCAVATOR 71
Procedure 71
ATTACHMENTS 72
Installing And Removing The Attachment (Hydraulic X-Change) 72
Installing And Removing The Attachment (Pin Grabber Quick Coupler) 75
Installing And Removing The Attachment (Pin-On X-Change) 80
Installing And Removing The Attachment (Pin-On Attachment) 86
Installing And Removing The Pro Clamp System Tool 87
OPERATING PROCEDURE 94
Inspect The Work Area 94
Basic Operating Instructions 94
Lowering The Work Equipment (Engine STOPPED) 94
Object Handling 95
Object Handling With The Lifting Device 96
Lift Capacity 98
Using The Clamp (If Equipped) 100
Using The Pro Clamp System (If Equipped) 101
Boom Swing 102
Driving The Excavator 103
Operating On Slopes 104
Operating In Water 106
Avoiding Track Damage 107
DEPTH CHECK 108
Setup / Calibration 108
Initial Setup 118
Operation 125
TOWING THE EXCAVATOR 131
Procedure 131
LIFTING THE EXCAVATOR 132
Procedure 132
TRANSPORTING THE EXCAVATOR ON A TRAILER 133
Loading And Unloading 133
Fastening 133
PREVENTIVE MAINTENANCE 134
MAINTENANCE SAFETY 137
SERVICE SCHEDULE 138
Maintenance Intervals 138
CONTROL CONSOLE LOCKOUTS 140
Inspection And Maintenance 140
SEAT BELT 141
Inspection And Maintenance 141
MOTION ALARM SYSTEM 142
Description 142
Inspecting 142
Adjusting Switch Position 143
TAILGATE 144
Opening And Closing 144
Adjusting The Latch 144
RIGHT SIDE COVER 145
Opening And Closing 145
CAB FILTERS 146
Cleaning And Maintenance 146
HEATING, VENTILATION AND AIR CONDITIONING (HVAC) 147
Cleaning And Maintenance 147
AIR CLEANER SERVICE 148
Replacing The Filter Elements 148
FUEL SYSTEM 150
Fuel Specifications 150
Biodiesel Blend Fuel 150
Filling The Fuel Tank 151
Fuel Filters 152
Removing Air From The Fuel System 153
Draining The Fuel Tank 153
ENGINE LUBRICATION SYSTEM 154
Checking And Adding Engine Oil 154
Engine Oil Chart 154
Removing And Replacing Oil And Filter 155
ENGINE COOLING SYSTEM 156
Cleaning 156
Checking Level 157
Removing And Replacing Coolant 158
ELECTRICAL SYSTEM 160
Description 160
Fuse And Relay Location / Identification 160
Battery Maintenance 162
Maintaining Battery Charge Level 162
Battery Service During Machine Storage 162
Battery Testing 163
Battery Charging 163
Using A Booster Battery (Jump Starting) 164
Removing And Installing The Battery 165
HYDRAULIC SYSTEM 166
Checking And Adding Hydraulic Oil 166
Hydraulic / Hydrostatic Fluid Chart 167
Removing And Replacing The Hydraulic Filters 168
Removing And Replacing The Hydraulic Fluid 170
TRACK TENSION 171
Adjusting 171
TRAVEL MOTOR 174
Checking And Adding Oil 174
Removing And Replacing Oil 174
ALTERNATOR BELT 175
Belt Adjustment 175
Belt Replacement 175
AIR CONDITIONING BELT 176
Belt Adjustment 176
Belt Replacement 176
X-CHANGE 177
Inspection And Maintenance 177
PIN GRABBER QUICK COUPLER 177
Inspection And Maintenance 177
BUCKET 178
Bucket Teeth Removal And Installation 178
TRACK ROLLER AND IDLER LUBRICATION 178
Procedure 178
CUTTING EDGE (ANGLE BLADE ONLY) 179
Removal And Installation 179
LUBRICATION OF THE HYDRAULIC EXCAVATOR 180
Lubrication Locations 180
PIVOT PINS 183
Inspection And Maintenance 183
EXCAVATOR STORAGE AND RETURN TO SERVICE 184
Storage 184
Return To Service 184
SYSTEM SETUP AND ANALYSIS 185
DIAGNOSTIC SERVICE CODES 186
Viewing Service Codes 186
Service Codes List 187
CONTROL PANEL SETUP 192
Panel Setup (Deluxe Instrument Panel) 192
PASSWORD SETUP (KEYLESS START PANEL) 197
Password Description 198
Changing The Owner Password 198
Password Lockout Feature 198
PASSWORD SETUP (DELUXE INSTRUMENT PANEL) 199
Password Description 199
Changing The Owner Password 199
Changing The User Passwords 200
Password Lockout Feature 200
MAINTENANCE CLOCK 201
Description 201
Standard Instrument Panel 201
Setup 201
Reset 201
Deluxe Instrument Panel 202
MACHINE SIGN TRANSLATIONS 203
MACHINE SIGN TRANSLATIONS 204
Service Schedule (7241461) 204
Warning (7178178) 207
Lift Chart (7188434) With Standard Arm 208
Lift Chart (7188442) With Standard Arm W/Counterweight 211
Lift Chart (7188436) With Long Arm 214
Warning (7148157) 217
Warning (7178177) 219
Warning (6708929) 222
Warning (7185933) 222
Warning (7148145) 223
Warning (7148147) 223
Using the X-Change (6818059) 224
Using the X-Change System (7220131) 227
Using the Pin Grabber Attachment Coupler System (7220038) 230
Joystick Control Pattern Selector Lever (7178179) 233
Warning (6810004) 234
Warning (7169006) 234
SPECIFICATIONS 235
EXCAVATOR SPECIFICATIONS 236
Excavator Machine Dimensions 236
Excavator Machine Dimensions – Standard Arm 237
Excavator Machine Dimensions – Long Arm 238
Excavator Machine Dimensions – Angle Blade 239
Performance 240
Controls 240
Engine 241
Hydraulic System 242
Hydraulic Cylinders 243
Hydraulic Cycle Times 243
Electrical 244
Drive System 245
Slew System 245
Undercarriage 245
Capacities 245
Tracks 245
Ground Pressure 245
WARRANTY 246
WARRANTY 247
ALPHABETICAL INDEX 249
IMAGES PREVIEW OF THE MANUAL:
VIDEO PREVIEW OF THE MANUAL:
