Wacker Neuson RD 12 Roller Repair Manual – PDF DOWNLOAD
FILE DETAILS:
Wacker Neuson RD 12 Roller Repair Manual – PDF DOWNLOAD
Language : English
Pages : 138
Downloadable : Yes
File Type : PDF
Size: 8.32 MB
IMAGES PREVIEW OF THE MANUAL:
VIDEO PREVIEW OF THE MANUAL:
DESCRIPTION:
Wacker Neuson RD 12 Roller Repair Manual – PDF DOWNLOAD
Operating / Parts Information:
- You must be familiar with the operation of this machine before you
attempt to troubleshoot or repair it. Basic operating and maintenance
procedures are described in the Operator’s Manual supplied with the
machine. Keep a copy of the Operator’s Manual with the machine at all
times. Use the separate Parts Book supplied with the machine to order
replacement parts. If you are missing either of the documents, please
contact Wacker Neuson Corporation to order a replacement. - Damage caused by misuse or neglect of the unit should be brought to
the attention of the operator to prevent similar occurrences from
happening in the future.
TABLE OF CONTENTS:
Wacker Neuson RD 12 Roller Repair Manual – PDF DOWNLOAD
1 Safety Information 9
1 1 Operating Safety 10
1 2 Operator Safety while using Internal Combustion Engines 12
1 3 Service Safety 13
1 4 Label Locations 15
1 5 Safety and Operating Labels 16
2 Operation 22
2 1 Operation and Service Locations 22
2 2 Control Panel 24
2 3 Vibration 26
2 4 Water Spray System 27
2 5 Starting 28
2 6 Stopping/Parking 30
2 7 Auxiliary Battery Positive Terminal 31
3 Honda Engine Starting System 32
3 1 Checking the 20A Main Fuse 33
3 2 Checking Wiring to the Starter Solenoid & Anti-backfire Solenoid 34
3 3 Checking the Key Switch 36
3 4 Checking the Crank Relay 37
3 5 Checking the Neutral Switch 38
3 6 Checking the Neutral Relay 39
4 Wacker Neuson Engine Starting System 40
4 1 Checking the 20A Main Fuse 41
4 2 Checking the Wiring to the Starter Solenoid & Anti-backfire Solenoid 42
4 3 Checking the Key Switch 43
4 4 Checking the Crank Relay 44
4 5 Checking the Neutral Switch 45
4 6 Checking the Neutral Relay 46
Table of Contents RD 12/RD 12A
wc_br0170797en_002TOC fm 6
5 Drive System 48
5 1 Checking the Tow Valve 49
5 2 Adjusting the Drive Control Cable 50
5 3 Checking the Drive System Operating Pressure 51
5 4 Checking the Drive System Relief Pressure 52
5 5 Checking Drive Motors for Binding 53
5 6 Checking Oil Flow through the Drive Motors 55
6 Vibration System and Steering 56
6 1 Checking the Engine Speed and Vibration Speed 57
6 2 Troubleshooting a System that Vibrates Poorly 58
6 3 Checking the Vibration Solenoid Valve 60
6 4 Checking the Vibration Switch 61
7 Steering System 62
7 1 Checking the Steering System Hydraulic Pressure 62
7 2 Troubleshooting the Steering System 63
8 Spray System 64
8 1 Troubleshooting the Spray System 64
8 2 Checking Power to the Spray Bar Pump 65
8 3 Checking the Pump Timer Module 66
8 4 Checking the Spray System Switch 67
9 Disassembly & Assembly 68
9 1 Tools Required for Disassembly/Assembly Procedures 68
9 2 Information Regarding Replacement Parts 68
9 3 Information Regarding Reference Numbers ( ) 68
9 4 Information Regarding Threadlocking Compounds 68
9 5 Removing the Articulating Joint 69
9 6 Installing the Articulating Joint 70
RD 12/RD 12A Table of Contents
7
9 7 Removing the Rear Drum 71
9 8 Installing the Rear Drum 73
9 9 Removing the Brake and Brake Cable 75
9 10 Installing the Brake and Brake Cable 77
9 11 Removing Rear Drive Motor 79
9 12 Installing the Rear Drive Motor 81
9 13 Removing the Front Drum 83
9 14 Installing the Front Drum 85
9 15 Removing the Front Drive Motor 87
9 16 Installing the Front Drive Motor 88
9 17 Removing the Exciter 89
9 18 Installing the Exciter 91
9 19 Disassembling the Exciter Bearings 93
9 20 Assembling the Exciter Bearings 95
9 21 Removing the Control Cable and Control Lever 97
9 22 Installing the Control Cable and Control Lever 99
9 23 Removing the Exciter Pump 100
9 24 Installing the Exciter Pump 101
9 25 Removing the Drive Pump 102
9 26 Installing the Drive Pump 103
9 27 Removing the Engine 104
9 28 Installing the Engine 106
9 29 Removing the Steering Valve 108
9 30 Installing the Steering Valve 110
9 31 Removing the Hydraulic Tank 112
9 32 Installing the Hydraulic Tank 114
9 33 Removing the Fuel Tank 116
9 34 Installing the Fuel Tank 118
10 Schematics 120
10 1 Hydraulic Schematic 120
10 2 Hydraulic Schematic Components 121
10 3 Electrical Schematic Identification—RD 12A 121
10 4 Electrical Schematic “A”—RD 12A 122
10 5 Electrical Schematic “A” Components—RD 12A 123
10 6 Electrical Schematic “B”—RD 12A 124
10 7 Electrical Schematic “B” Components—RD 12A 125
10 8 Electrical Schematic—RD 12 126
10 9 Electrical Schematic Components—RD 12 127
Table of Contents RD 12/RD 12A
wc_br0170797en_002TOC fm 8
11 Technical Data 128
11 1 Engine 128
11 2 Roller 129
11 3 Lubrication 129
11 4 Dimensions 130
11 5 Sound Measurements 131
11 6 Measurements of Operator Exposure to Vibration 131
11 7 Hydraulic Pressures 132
