Mahindra Tractor 4510c Parts Manual
FILE DETAILS:
LANGUAGE:ENGLISH
PAGES:106
DOWNLOADABLE:YES
FILE TYPE:PDF
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Mahindra Tractor 4510c Parts Manual
FOREWORD
This flat rate schedule has prepared as a useful guide to help dealers and distributors in executing effectively servicing jobs at fair prices. It provides for the standard operation times needed to do individual servicing jobs. The time schedule is completed to be readily understandable with the three headings: JOB CODE, DESCRIPTION AND LABOR TIME.
EXPLODED ILLUSRATION
-Any of the following method is used to indicate the point to service.
(1) Indicating the point by using a leading line.
(2) Indicating the range of servicing by using the marking.
Identify the points or the ranges to be serviced with any of these indications and select appropriate procedure for the servicing with the relevant JOB CODE.
JOB CODE
-Use these codes when filling out the warranty claim report Form.
DESCRIPTION
-Each of the job descriptions listed covers all the works to be performed.from starting the servicing job to be the completion of the service when the unit is fully restored to the operating condition. This also include incidental works such as cleaning,adjustment and inspection of the parts involved.
LABOR TIME
-The Labor times are expressed in hours and tenths of an hour. ( 1 tenths of an hour = 6 minutes)
-The time schedule has based on :
1.Service done by a mechanic with average ability and experience.
2.Use of special tools and mechanic’s hand tools.
3.Use of adequate repair facilities with flat concrete floor and hoist.
-The listed time includes:
1.Repair diagnosis time
2.The time required to obtain necessary parts and tools.
3.The time required to clean and inspection parts during disassembly and assembly.
-The listed time does not include:
1.The time required to clean and apply touch-up painting to the external outfits and implements not specifically referred to in this flat rate schedule, except for those jobs that must meet wash, clean and paint requirements.
2.Removal and reinstallation of optional equipment/implements and other attachments which are not mentioned in this flat rate schedule.
TABLE OF CONTENTS:
Mahindra Tractor 4510c Parts Manual
1. EN —————————————————–ENGINE
(1) EN01 : NOZZLE, HOLDER GROUP
(2) EN02 : COOLING GROUP
(3) EN03 : LUBRICATION GROUP
(4) EN04 : CAM SHAFT, INJECTION GROUP
(5) EN05 : ROCKER ARM, TIMING GEAR GROUP
(6) EN06 : CRANK, PISTON, FLYWHEEL GROUP
(7) EN07 : SPEED CONTROL, ENGINE STOP GROUP
(8) EN08 : INLET, EXHAUST GROUP
(9) EN09 : ELECTRICAL, etc GROUP
(10) EN10 : ACCELERATOR, FUEL LINE GROUP
2. ST————————————————–STEERING
(1) ST01 : STEERING WHEEL, PUMP GROUP
(2) ST02 : FRONT AXLE, TIRE GROUP
3. TR——————————————TRANSMISSION
(1) TR01 : DAMPER, HST UNIT GROUP
(2) TR02 : REVERSE, 4WD GEAR GROUP
(3) TR03 : REAR TRANSMISSION, BRAKE GROUP
(4) TR04 : PTO GROUP
4. HY———————————————–HYDRAULIC
(1) HY01 : MAIN LINE, PTO VALVE GROUP
(2) HY02 : CYLINDER, VALVE GROUP
(3) HY03 : 3 POINT GROUP
5. EL———————————————-ELECTRICAL
(1) EL01 : ELECTRICAL GROUP
6. EX————————————————-EXTERIOR
(1) EX01 : HOOD, GRILLE GROUP
(2) EX02 : SEAT, FENDER GROUP
