Liebherr Crane HS 841 HD Ersatzteilkatalog 183216 – PDF DOWNLOAD (German)
Suche von Ersatzteilen:
Suche über Baugruppenaufstellung:
Um das gewünschte Ersatzteil zu finden, müssen Sie durch die Stücklistenstruktur
von vorne nach hinten navigieren.
Orientieren Sie sich dazu zuerst an den Bildern in der Baugruppenaufstellung.
Die Bilder in der Baugruppenaufstellung geben Ihnen eine grobe Auskunft darüber,
was sich in den unter dem Bild angeführten Stückliste befindet.
Beachten Sie, dass gewisse Baugruppen und deren Ersatzteile auch in
Nachrüstsätzen der Baugruppenaufstellung enthalten sein können.
Numerischer Index:
Der numerische Index ist sortiert nach der Artikelnummer mit dem Hinweis auf
Seitennummer, Baugruppe, Position und Menge.
Alphabetischer Index:
Der alphabetische Index ist sortiert nach Artikel-Bezeichnung mit Hinweis auf die
Artikelnummer, Position, Menge, Seitennummer, Baugruppe und Bezeichnung der
Baugruppe in der dieser Artikel zu finden ist.
Hinweis zur Bestellung:
Vor der Bestellung prüfen, ob die Seriennummer am Typenschild der Maschine mit
der auf ihrem Ersatzteilkatalog übereinstimmt.
Um Ihre Bestellung schnell und richtig ausführen zu können, senden Sie uns mit ihrer
Bestellung bitte folgende Informationen mit:
• Maschinentyp und Seriennummer (ersichtlich am Typenschild der Maschine)
• Artikel, Bezeichnung und gewünschte Anzahl
Bei der Bestellung von Ersatzteilen für Antriebsmotoren, Winden,
Hydraulikpumpen, Hydraulikmotoren, Ventilen und Zylindern müssen Sie
unbedingt die Seriennummer auf dem Typenschild der Komponente
mitschicken.
• Lieferadresse und Versandart.
PREFACE:
This instruction ,nanual shall enable you to operate this machine as safe as possible and to take
advantage of all operating possibilities that this machine offers you.
Many useful hints about the operating principle of important assemblies and systems are given.
Moreover it can be used to order eventually required spare parts.
The instruction manual consists of:
VOLUME 1 OPERATION/ MAINTENANCE/ASSEMBLY
INSTRUCTION
VOLUME 2 – TECHNICAL INFORMATIONS
VOLUME 3 – SPARE PART LIST
VOLUME 3.1 – CROSS SECTION DRAWINGS
Only qualified and trained staff is allowed to use this machine.
The operating instructions and relevant rules and regulations (e.g. safety precantions) have to be
observed.
NON OBSERVANCE OF THIS PRINCIPLES CAN RESULT IN PERSONAL AND STRUCTURAL DAMAGE
- You have to turn your special attention to the built – in safety devices. They always have to be
checked for proper function. - It is not allowed to use this machine if the properfunction of the safety devices is not given.
