Fiat Allis Wheel Loader FR70 Service Manual
FILE DETAILS:
Fiat Allis Wheel Loader FR70 Service Manual
Size : 80.3 MB
Format : PDF
Language : English
Brand: Fiat
Type of machine: Wheel Loader
Type of document: Service Manual
Model: Fiat Allis FR70 Wheel Loaders
Number of Pages: 464 pages
Part Number: 60402201
DESCRIPTION:
Fiat Allis Wheel Loader FR70 Service Manual
GENERAL:
Study the Operation and Maintenance instruction Manual before starting, operating. maintaining, fuelling or servicing machine. Read and heed all machine-mounted safety Signs before starting. operating. maintaining. fuelling orservicing machine. Machine-mounted safety signs have been color coded yellow with black border and letterign for WARNING and red with white border and lettering for DANGER points.
- Do not allow unauthorized personnel to operate service or maintain this machine. Do not wear rings. wrist watches. jewellery. loose or hanging apparel, such as lies. torn clothing. scarves. unbuttoned or unzipped jackets that can catch on moving parts. Wear proper safety equipment as authorized for the job. Examples: hard hats.safety shoes. heavy glovw. ear protectors. safety glasses or gog- gles, reflector vests. or respirators, Consult your employer for specific safety equipment requirements. Keep operator‘s compartment. stepping points. grab- rails and handles clear. oil grease, mud or snow accumulation to minimize the danger of slipping or stumbling. Clean mud or grease from shoes before attempting to mount or operate the machine. 00 not jump on or off machine.
- Keep two hands and one foot. or two feet and one hand in contact with steps. grab rails and handles at all times. Do not use controls or hoses as handhelds when climbing on or off machine. Hoses and controls are movable and do not provide a solid support. Controls also may be inadvertently moved causing accidental machine or equipment movement. Never attempt to operate the machine or its tools from any position other than seated in the operator’s seat.
- Keep head. body. limbs, hands and feet inside opera- tor‘s compartment at ail times. to reduce exposure to hazards outside the operator’s compartment. Be careful of slippery conditions on stepping points. hand rails and on the ground. Fory our personal protection, do not ettempttodimb on or off machine while machine is in motion.
START :
DO NOT START AN UNSAFE MACHINE. Before working the machine. be sure that any unsafe condition has been satisfactorily remedied. Check bral:es.steering and attachment controls before moving. Advise the proper maintenance authority of any malfunctioning part or system.
- Be sure allprotective guards or panels are in place and in good operating condition. Be sure exposed personnel in the area of operation are clear of the machine before moving the machine oriLs attachments. WALK COMPLETELY AROUND ma- chine before mounting. Sound horn. Before starting machine. check.
- artfust and lock the operator seat for maximum comfort and control of the machine. Fasten seat belts (where needed]. Obey flag man. safety signals and signs. Because of the presence of flammable liquid on board, never check or fuel the tanks, batteries and accumula- tors near I re, free flame or sparks. STARTING FLUID IS FLAMMABLE. Follow the recommendaions as outlined in the Operation and Maintenance Instruction Manual and as marked on the containers.
- DO NOT PUNCTURE OR BURN CONTAINERS. Store containers in cold. well-ventilated place secure from unauthorized personnel. Follow the Manufactur- cr‘s instructions. Never use these products near fire, has flame or sparks. OPERATION Check wheels and bead wires clamps before starting your shift. Clamp. if necessary. acording to instructions.
