Daewoo Doosan Mega 400 parts manual 4021- 7069EF – PDF DOWNLOAD
DESCRIPTION:
- Daewoo Doosan Mega 400 parts manual 4021- 7069EF – PDF DOWNLOAD
- Daewoo reserves the right to improve our products in a continuing process to provide the best possible product to the market place.
- These improvements can be implemented at any time with no obligation to change materials on previously sold products.
- It is recommended that consumers periodically contact their distributors for recent documentation on purchased equipment.
- This documentation may include attachments and optional equipment that is not available in your machine’s package.
- Please call your distributor for additional items that you may require. Illustrations used throughout this manual are used only as a representation of the actual piece of equipment, and may vary from the actual item
FOREWORD
2. HOW TO USE THIS PARTS LIST
- Key No. : It shows the reference no. on the illustration. Part No. : It shows the part number. Description : It shows the name of part. Components of an assembly part are shown with [.] marks and are shown on the line, or lines, below the assernbly part. Also if the components with [.] mark consists of further components part. these further components are shown by the marks [ .. ]. Q’ty : It shows the quantity use for one machine.
- quantity of components show the quantity for one assembly part. Service code : Abbreviations in this column have their own meaning as show below. B: The parts with this abbreviation shows that the part requires some work on it before installing in the machine. D: The part with this abbreviation is a component of an assembly and is not available independently.
- The assembly part containing this part should be ordered. K: This means that the part is contained in the service part kit. M: This means that the part is available only with its mating parts altogether. R: The part with this abbreviation shows that the quantity of the part is changed depending on the machine, such as an adjusting shim etc. S: This part is specially provided as a service part, which was not provided in the machine before shipping from the factory. G: This part need grade control and should be requested as the same grade of counter part. OP: Optional parts. EX: Spi~f!fi~~~ffl1ooK IS FOR
- OS: Over-sized parts. US: Under-sized parts. (Part with abbreviation “OS” or “US” is described on the line below the standard sized part.) #: The part with this mark is newly added on that page of the equipment. Serial no.: Serial No. shows the machine serial number which the parts were applied.
- As to the engine Serial No. shows only engine serial number shich the parts were applied. Parts without any applicable serial number are used in every machine. ICA : !CA shows the interchangeability between the original and the improved parts. Abbreviations used in this column are as follows; : Part No. in the column of “Replaceable part” can be used instead of this part but not vice versa. P : This must not be used for machine.
- The part No. in the column “Replaceable part” should be used instead. T : Parts Nos. those in the column of “Replaceable part” can be used as an assembly instead of this part. Y : This part and the part in the column of “Replaceable part” are interchangeable with each other.
- BLANK : This part has no “Repleaceable part” Replaceable part : Interchangeable parts nos. and their required quantity are shown in this column. If interchangeable improved parts are provided for the parts which you may order, the improved parts classified as “I”, “P” “T” or “Y” may be supplied. • When repairing, it is recommended to use our standard part. • Researching the assembling parts from Part No., see the parts lndex of this
TABLE OF CONTENTS:
Daewoo Doosan Mega 400 parts manual 4021- 7069EF – PDF DOWNLOAD
e ENGINE PARTS
Rg. 011 CYLINDER BLOCK BLOC CYLINDRES 2
012 TIMING GEAR CASE CARTER DE DISTRIBUTION 6
013 BEARING CASE CARTER DE PAILER 8
. 014 FLYWHEEL HOUSING CARTER DE VOLANT MOTEUR 10
015 CRANK SHAFT ASS’Y VILEBREQUIN 12
016 PISTON ASS’Y PISTON 16
017 CYLINDER HEAD CULLASSE 18
018 ENGINE TIMING ARBRE A CAMES 22
019 OIL PUMP POMPE A HUILE 26
020 OIL PAN CARTER D’HUILE 28
021 OIL COOLER REFROIDISSEUR D’HUILE 32
022 COOLING WATER PUMP POMPEA EAU 36
023 COOLING SYSTEM SYSTEME DE VENTILATEUR 38
024 INTAKE,EXHAUST MANIFOLD TUBULURE ET COLLECTEUR 42
025 TURBO CHARGER TURBO CHARGER 44
026 NOZZLE AND HOLDER PORTE INJECTEUR 48
027 INJECTION PIPE CONDUITES D’INJECTION 50
028 INJECTION PUMP POMPE D’INJECTION 52
029 FUEL FILTER FILTRE A GAZOLE 56
030 ELEC.PARTS & TACHOMETER DRIVE PIECES ELECTRIQUE ET TACHYMETRE 58
031 AIR COMPRESSOR MOUNTING B’KT SUPPORT DE MONTAGE POUR COMPRESS 60
eBODY PARTS
Fig. 1100 FRAME CHASSIS 62
1110 ENGINE MOUNTING MOTEUR 66
1120 HYDRAULIC OIL TANK RESERVOIR D’HUILE 74
1130 FUEL TANK RESERVOIR DE GAZOLE 78
1140 FUEL PUMP ASS’Y POMPE DE GAZOLE 80
1150 FUEL SYSTEM SYSTEME D’INJECTION 82
1160 AXLES AND DRIV:: SHAFT PONTS ::T ARBRES DE TRANSMISSION 84
1170 REAR AXLE PIVOT LUB.PIPING GRAISSAGE DU PIVOT DE PONT 90
1180 MAIN PIPING(l) CANALISATIONS PRINCIPALES 92
1190 MAIN PIPING(2) CANALISATIONS PRINCIPALES 100
1200 MAIN PIPING(3)-3 SPOOL CANALISATIONS PRINCIPALES 104
1210 PILOT PIPING-2 SPOOL(STD] CANALISATIONS PILOTE 108
1220 PILOT PIPING-3 SPOOL[OPTION) CANALISATIONS PILOTE 110
1230 STEERING PIPING CANALISATIONS DE DIRECTION 112
1240 BRAKE PIPING CANALISATIOr,,,JS DE FREIN 114
1250 LIS SYSTEM PIPINGlOPTION] CANALISATIONS DU SYSTEME LIS
1260 HEATER PIPING CANALISATIONS DE CHAUFFAGE 122
1270 COOLING SYSTEM SYSTEME DE REFROIDISSEMENT 124
1280 HOSE CLAMPING FIXATION DES FLEXIBLES 128
1290 CABIN MOUNTING FIXATION DE LA CABINE 130 >,
1300 CAB COVER STRUCTURE DE PROTECTION 132
1310 CABIN CABINE 134
1320 SEAT AND FLOOR PLATE SIEGE· ET TOLE DE PLANCHER 144
1330 INSTRUMENT PANEL TABLEAU DE BORD 150
1340 STEERING ASS’Y ENSEMBLE DE DIRECTION 152
1350 ENGINE CONTROL SYSTEME D’ACCELERATION DU MOTEUR 156
1360 FRONT LAMP SUPPORT SUPPORT DE PHARES 158
1370 COUNTER WEIGHT.BATTERY BOX CONTRE-POIDES ET COFFRE A BATTERIE 160
1380 CANOPIES CAPOTS 162
1390 FENDER,LADDER GARDE-BOUE,ECHELLE 170
1391 FENDER,LADDER-OPTION GARDE-BOUE,ECHELLE 174
1400 REAR FENDER-OPTION GARDE-BOUE ARRIERE 178
1410 COOLER ASS’Y(l) ENSEMBLE DE CLIMATISATION 180
1415 COOLER ASS’Y(2) ENSEMBLE DE CLIMATISATION 182
1420 ELECTRICAL PARTS ( l) EQUIPMENT ELECTRIC 184
1430 ELECTRICAL PARTS(2) EQUIPMENT ELECTRIC 194
e FRONT PARTS
Fig. 2100 LOADER EQUIPMENT FRONTAL 202
2110 ARM RAISE KICK OUT CAPTEU R DE POSITION 206
2120 ARM FLOAT KICK OUT CAPTEUR DE POSITION 208
2130 RETURN TO DIG POSITIONNEUR DE GODET 210
2140 DUMP CUT OUT(OPTION) POSITION 212
2150 BUCKET(ST ANDARD)-3.9M3 GODET 214
2160 BUCKET(OPTION)-3.5M 3 GODET 216
2170 BUCKET(OPTION)-3.5M3 W/O TOOTH GODET 218
2171 BUCKET(STANDARD) GODET 220
2172 BUCKET-OPTION GODET 221-1
2180 LOG FORK-OPTION PINCES 222
2190 PALLET FORK FOURCHES A PALETTES 224
2200 REAR DEFROSTER ASS’Y-OPTION DEG ELEMENT 225-1
e HYDRAULIC COMPONENTS
Fig. 3100 CONVERTER CONVERTISSEUR 226
3110 CONVERTER HOUSING,TRAN,CASE CARTERS DE CONNVERTISSEUR ET DE TRANS. 230
3120 0 /REGULATING&CHARGING PUMP REGULATEUR DE PRES.ET POMPE DE CHARGE 234
3130 FORWARD;3TH,4TH,IDLE GROUP MARCHE AVANT,3EME,4EME,ENSEMBLE MOBILE 238
3140 REVERSE;LOW,2ND,OUTPUT GROUP MARCHE ARRIERE.PETITE VITESSE.2ND SORTIE 244
3150 CONTROL VAL VE TIROIRS DE COMMANDE 250
3160 CONTROL VAL VE HOUSING BLOC DE COMMANDE 254
3170 FRONT AXLrMrs PARTs BooK 1s F5#~F’E~l!:~ t>’ift..Nl. 256
PART NUMBERS AND SERAIL NUMBERS MAY BE
OUTDATED. ALWAYS USE THE ONLINE PARTS SYSTEM) MEGA4O0
3180 FRONT _DIFFERENTIAL GEAR ASS’Y
3190 FRONT PLANETARY GEAR ASS’Y
3200 PARKING BRAKE ASS’Y
3210 REAR AXLE ASS’Y
3220 REAR DIFFERENTIAL GEAR ASS’Y
3230 REAR PLANET ARY GEAR ASS’Y
3240 MAIN PUMP
3250 STEERING PUMP
3260 3 SPOOL CONTROL VALVE
3270 SERVO CENTERING
3280 CONTROL VAL VE SPOOL
3290 STEERING UNIT
3300 CUSHION VALVE
3310 PRIORITY VALVE
3320 OPTION PILOT SUPPLY VAL VE
3330 UNLOADER V Al VE
3340 BRAKE PILOT SUPPLY VALVE
3350 BY-PASS VALVE
3360 STEERING CYLINDER
3370 BUCKET CYLINDER-L.H
3380 BUCKET CYLINDER-R.H
3390 LIFT CYLINDER-L.H
3400 LIFT CYLINDER-R.H
e OTHER PARTS
Fig. 4100 NAME PLATE-DOMESTIC
4110 NAME PLATE-ENGLISH
4120 TOOLS
4130 SPAREPARTS(l)
4140 SPARE PARTS(2)
4150 SPARE PARTS{3}
ENSEMBLE DU DIFFERENCIEL AV ANT
ENSEMBLE DU REDUCTEUR AV ANT
ENSEMBLE DU FREIN DE PARKING
ENSEMBLE PONT ARRIERE
ENSEMBLE DU DIFFERENCIEL ARRI ERE
ENSEMBLE DU REDUCTEUR ARRIERE
POMPE P.RINCIPALE
POMPE DE DIRECTION
BLOC DE COMMANDE A 3 TIROIRS
SYSTEME DE CENTRAGE
TIROIR DE COMMANDE
ORBITROL
SOUP APE DE SECVRITE
SOUPAPE DE PRIORITE
SOUPAPE DE PILOTAGE OPTIONNELLE
SOUPAPE DE DECHARGE
SOUPAPE DE DISTRIBUTION DE FREINAGE
SOUPAPE DE BY-PASS
VERIN DE DIRECTION
VERIN DE GODET GAUCHE
VERIN DE GODET DROIT
VERIN DE LEV AGE GAUCHE
VERIN DE LEV AGE DROIT
PLAQUE D’IDENTIFICATION
OUTILS
PIECES DE RECHANGE
PIECES DE RECHANGE
PIECES DE RECHANGE
(THIS PARTS BOOK IS FOR REFERENCE ONLY.
MEGA400
PART NUMBERS AND SERAIL NUMBERS MAY BE
OUTDATED. ALWAYS USE THE ONLINE PARTS SYSTEM)
