Clark Forklift EC(SV)50-70 English O-219 Operator’s Manual
Video Preview:
Image Preview:
Description:
Clark Forklift EC(SV)50-70 English O-219 Operator’s Manual
- SAFETY INSTRUCTIONS FOR MAINTAINING INDUSTRIAL TRUCKS ? mmmm Powered industrial trucks may become hazardous if adequate maintenance is neglected. Therefore, adequate maintenance facilities, personnel and procedures should be provided.
- Maintenance and inspection of all powered industrial trucks should be performed in conformance with the recommendation in this manual and the following practices. 1. A scheduled preventive maintenance, lubrication, and inspection system should be followed.
- 2. Only qualified and authorized personnel should be permitted to maintain, repair, adjust, and inspect industrial trucks. 3. Before Leaving The Truck: A. Stop truck. B. Fully lower the load engaging means.
- C. Place directional controls in neutral. D. Apply the parking brake. E. Stop the engine or turn off power. F. Lock the control or ignition circuit. G. Block the wheels if truck is on a ramp, or being worked on.
- 4. Before Working On Truck: A. Raise wheels free of floor or disconnect power source. B. Use chocks or other positive truck positioning devices. C. Block load engaging means, innermast(s), or chassis before working under them. Before working on engine fuel system of gasoline powered trucks with gravity feed fuel systems, be sure fuel shutoff valve is closed.
- Before working on engine fuel system of LP gas powered trucks, close LP gas cylinder valve and run engine until fuel in system is depleted and engine stops running. Operation to check performance of the truck or attacmients should be conducted in an authorized, safe clearance area.
- 5. Before Starting To Operate The Truck; A. Be in operating position. B. Depress clutch (or brake pedal on automatic transmission and electric trucks). C. Place directional controls in neutral.
- D. Start engine or turn on power. E. Before operating truck, check functioning of lift and tilt systems, directional and speed controls, steering, warning devices, brakes, and any attachment, (If used) F. Release parking brake.
Table Of Contents:
Clark Forklift EC(SV)50-70 English O-219 Operator’s Manual
Horn, Lights (Machines so equipped); Control Circuit Fuse.
Battery charge indicator, hour meter.
Brake pedal free travel, check; parking brake, check.
Brake interlock switch check; seat safety (deadman) switch, check.
Battery, inspect,
HydrauJ ic sump tank, level check; operation check; hydrauJ ic controls,
check.
Tires, inspect.
100 Hour Lubrication & Preventive Maintenance Illustration.
Ax.le adapter, lubricant level check.
Sol id State Control-Control Fuses-Inspection and Ground Tests.
Parking brake power cut-off switch, check and adjust; Service brake
power cut-off switch, check and adjust.
Service brake power cut-off switch, check and adjust,
Brake pedal free travel, check and adjust.
Brake system, inspect,
Lubricate machine; hydraulic control valve and I ines, inspect,
1 ift cylinder and tilt cyl lnder, inspect; 11ft chains, check and
adjust.
Pump control switches (1 ift and tilt); check and adjust,
Master (speed cor.trol) cylinder, check and adjust:1HS and 2HS switches
(accelerator pedal), check and adjust.
Sol id State Control, test and adjust.
Hydraulic sump tank breather, inspect.
Steering gear, lubricant level check.
Forward, reverse, 1A contactors, inspect and adjust.
Lubrication Chart
Lubrication Chart
500 Hour Lubrication & Preventive Hai,ntenaoce l]lustration
Hydraulic sump tank, drain- and refill.
Hydraulic sump tank filter, change.
Steering gear, check and adjust.
Typical steering 1 inkage (side view); 1 inkage adjustment specifications.
Steer axle and 1 inkage, check and adjust.
lQOO Hour Lubrication & Preventive Maintenance IJ]ustratlon
Typical drive motor assembly.
Drive and pump motor, inspect; brush spring tension, check.
Brushes, inspect.
Typical pump drive motor (disassembled vlew).
Steering wheel bearings, clean, repack and adjust.
Axle ends, clean and repack.
Brake system, ii lustration.
Brake system, bleed.
Service wheel brake assembly.
