Case Wheel Loader 1221F Tier 4 Service Manual
FILE DETAILS:
Case Wheel Loader 1221F Tier 4 Service Manual
Size : 70.8 MB
Format : PDF
Language : English
Brand: Case
Type of machine: Case Wheel Loader
Type of document: Service Manual
Model: Case Wheel Loader 1221F Tier 4
Part No: 47544213
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Case Wheel Loader 1221F Tier 4 Service Manual
FOREWORD:
STRUCTURE:
This service manual has been prepared as an aid to improve the quality of repairs by giving the serviceman an accurate understanding of the product and by showing him the correct way to perform repairs and make judgements. Make sure you understand the contents of this manual and use it to full effect at every opportunity. This service manual mainly contains the necessary technical information for operations performed in a service workshop. For ease of understanding, the manual is divided into the following sections.
Structure and function:
This group explains the structure and function of each component. It serves not only to give an understanding of the structure, but also serves as reference material for troubleshooting.
Operational checks and troubleshooting:
This group explains the system operational checks and troubleshooting charts correlating problem to remedy.
Tests and adjustments
This group explains checks to be amide before and after performing repairs, as well as adjustments
to be made at completion of the checks and repairs.
Disassembly and assembly
- This section explains the order to be followed when removing, installing, disassembling or assembling each component, as well as precautions to be taken for these operations.
- The specifications contained in this shop manual are subject to change at any time and without any advance notice. Contact your Case distributor for the latest information.
Helpful hints:
• Avoid filling tanks using cans or inappropriate pressurized fuel delivery systems that may cause considerable spillage.
• In general, avoid skin contact with all fuels, oils, acids, solvents, etc. Most of them contain substances that may be harmful to your health.
• Modern oils contain additives. Do not burn contaminated fuels and or waste oils in ordinary heating systems.
• Avoid spillage when draining off used engine coolant mixtures, engine, gearbox and hydraulic oils, brake fluids, etc. Do not mix drained brake fluids or fuels with lubricants. Store them safely until they can be disposed of in a proper way to comply with local legislation and available resources.
• Modern coolant mixtures, i.e. antifreeze and other additives, should be replaced every two years. They should not be allowed to get into the soil, but should be collected and disposed of properly.
• Do not open the air-conditioning system yourself. It contains gases that should not be released into the atmosphere. Your [Brand] dealer or air conditioning specialist has a special extractor for this purpose and will have to recharge the system properly.
• Repair any leaks or defects in the engine cooling or hydraulic system immediately.
• Do not increase the pressure in a pressurized circuit as this may lead to a component failure.
• Protect hoses during welding as penetrating weld splatter may burn a hole or weaken them, allowing the loss of oils, coolant, etc.
TABLE OF CONTENTS:
Case Wheel Loader 1221F Tier 4 Service Manual
SECTION 1 GENERAL
Group 1 Safety Hints11
Group 2 Specifications 113
Group 3 Operational Checkout Record Sheet 126
SECTION 2 ENGINE
Group 1 Structure and Function 21
Group 2 Engine speed and Stall rpm 215
Group 3 Fuel Warmer System 216
SECTION 3 POWER TRAIN SYSTEM
Group 1 Structure and Function 31
Group 2 Operational Checks and Troubleshooting 369
Group 3 Test and Adjustments 380
Group 4 Disassembly and Assembly 382
SECTION 4 BRAKE SYSTEM
Group 1 Structure and Function 41
Group 2 Operational Checks and Troubleshooting 430
Group 3 Tests and Adjustments 437
Group 4 Disassembly and assembly 439
SECTION 5 STEERING SYSTEM
Group 1 Structure and Function 51
Group 2 Operational Checks and Troubleshooting 518
Group 3 Tests and Adjustments 526
Group 4 Disassembly and Assembly 534
SECTION 6 WORK EQUIPMENT
Group 1 Structure and Function 61
Group 2 Operational Checks and Troubleshooting 639
Group 3 Tests and Adjustments 650
Group 4 Disassembly and Assembly 664
SECTION 7 ELECTRICAL SYSTEM
Group 1 Component Location 71
Group 2 Electrical Circuit 73
Group 3 Monitoring System 721
Group 4 Electrical Component Specification 764
Group 5 Connectors 771
Group 6 Troubleshooting 792
