2014 Massey Ferguson EU Harvesting MF Cutting Table Powerflow 35′ Operator’s Manual – PDF DOWNLOAD
DESCRIPTION:
2014 Massey Ferguson EU Harvesting MF Cutting Table Powerflow 35′ Operator’s Manual – PDF DOWNLOAD
Preface:
- This operator’s manual should be used as a handy reference book: It contains all the practical information on the operation, adjustment and maintenance of your new cutting table. The cutting table has been designed and engineered for maximum performance, comfort and ease when working under varying harvesting conditions. Prior to delivery, the table has undergone a thorough inspection, both at the factory and at the dealer, to ensure that it is ready for use when you receive it.
- Periodic maintenance must be performed at the recommended intervals to keep the table in good condition and ensure smooth operation. Read this operator’s manual carefully before you start to use and/or operate the table, and pay particular attention to the section on safety measures.
- Keep the operator’s manual within easy reach for additional information when needed. The terms “left” and “right” should be understood to mean in the forward direction of the machine. For more information, please contact your authorised dealer. He has specialised personnel, original spare parts and the equipment necessary to cover any service needs.
TABLE OF CONTENTS:
2014 Massey Ferguson EU Harvesting MF Cutting Table Powerflow 35′ Operator’s Manual – PDF DOWNLOAD
1 General Information 5
1 1 Dear Customer 7
1 1 1 Preface 7
1 1 2 Company policy 7
1 1 3 Optional Extra 7
1 1 4 Spare parts and accessories 7
1 1 5 Warranty 8
1 1 6 Service 8
1 1 7 Lubricants 9
1 1 8 Important environmental considerations 9
1 2 Appropriate Use 10
1 2 1 Appropriate use 10
1 2 2 Directives and standards 10
1 2 3 EC Declaration of conformity for table 11
1 2 4 Product Identification 13
1 3 Sectional drawing and Description of Table 14
1 3 1 Sectional drawing and parts identification 14
1 3 2 Operational description 15
2 Safety 17
2 1 Safety 19
2 1 1 General Safety Precautions 19
2 1 2 Attention – Warning Symbols 19
2 1 3 Safety precautions 20
2 1 4 Road Transport 21
2 1 5 Safe handling of the table 22
2 1 6 Warning/instruction decals on the cutting table 22
2 1 7 Location of warning/instruction decals 26
3 Operation and Adjustment 27
3 1 Safety precautions 29
3 1 1 Safety Precautions, Cutting Tables 29
3 2 Attachment/Removal of Table 30
3 2 1 General 30
3 2 2 Attachment of Table, Standard and Auto Level 30
3 2 3 Removal of Table 32
3 3 Table trailer 34
3 3 1 Table trailer 34
3 4 Auto Level table 35
3 4 1 Principle of Auto Level Table 35
3 4 2 Adjustment of ground sensor 35
3 5 Reel 36
3 5 1 Safety stop for reel 36
3 5 2 Reel Adjustment Up/Down, Fore/Aft 36
3 5 3 Bleeding 37
3 5 4 Rotation 38
3 5 5 Reel tine bars 38
3 5 6 Adjustment of the Reel in the Table 39
3 6 Knife 40
3 6 1 Knife and knife drive 40
3 7 Feeding 41
3 7 1 Table Auger 41
3 7 2 Replacement of Feathering Fingers 41
3 7 3 Auger extensions 42
PowerF/ow Cutting Table – EAME
D3113100M1
3
Table of contents MASSEY FERGUSON
3 7 4 Reversing 42
3 8 Transmissions 43
3 8 1 General 43
3 8 2 PowerFlow Table, 35 ft cutting table, knife drive and table auger 43
3 8 3 Slip clutches 45
3 8 4 Transmission diagram, left-hand side 46
3 8 5 Transmission diagram, right-hand side 46
3 9 Power Flow belts 4 7
3 9 1 PowerFlow belts 47
3 9 2 Inspection of Powerflow Belts 47
3 9 3 Adjustment of belts 48
3 9 4 Cleaning 48
3 10 Crop lifters 49
3 10 1 Using Crop Lifters 49
3 11 Vertical Knives and Straw Dividers 50
3 11 1 Vertical Knife 50
3 11 2 Mounting of Vertical Knife 50
3 11 3 Folding torpedo dividers and bow dividers 51
3 11 4 Mounting of Straw Dividers 51
3 11 5 Adjustment of Torpedo Divider 52
3 12 Hydraulics 53
3 12 1 Reel adjustment fore/aft – up/down 53
4 Lubrication and Maintenance 55
4 1 Lubrication Intervals 57
4 1 1 Lubrication chart, time intervals 57
4 1 2 Lubrication chart, right- and left-hand sides 58
4 1 3 Lubrication points, left-hand side 59
4 1 4 Lubrication points, right-hand side 61
4 1 5 Lubricants 63
4 2 Maintenance 64
4 2 1 Maintenance required 64
5 Storage 65
5 1 Storage 67
5 1 1 General 67
5 1 2 After harvest 67
5 1 3 Ordering spare parts 67
5 1 4 Before the Start of the New Season 67
6 Specifications 69
4
6 1 Specifications 71
6 1 1 Technical specifications 71
Alphabetical index 73
