Tigercat S855C LS855C SHOVEL LOGGER SERVICE MANUAL – PDF DOWNLOAD
DESCRIPTION:
Tigercat S855C LS855C SHOVEL LOGGER SERVICE MANUAL – PDF DOWNLOAD
SERIAL NUMBER 85550101 TO 85551000
SERIAL NUMBER 85500101 TO 85501000
INTRODUCTION:
An Operator’s manual, Service manual and a Parts catalog are made available by Tigercat to assist the dealer, customer and operator in becoming familiar with the features of the S855C/LS855C Shovel Logger
Serial numbers:-
S855C 85550101 TO 85551000
LS855C 85500101 TO 85501000
- The S855C/LS855C Shovel Logger is designed for log transfering, loading, and shovel logging (hoe-chucking) by swinging logs closer to the road side minimizing ground surface impact and damage.
- The operator’s manual will assist the operator with the techniques of proper and safe operation of the S855C/LS855C Shovel Logger. There is also important information regarding the safe operation of the attachment. The service manual contains safety and servicing procedures and a preventive maintenance schedule to ensure optimum machine performance.
- Section 1 in both the operator’s manual and the service manual contains safety information that must be followed. As well, throughout the rest of the manuals, WARNING and CAUTION notices are displayed where necessary, drawing attention to possible hazards when performing certain procedures.
- Only trained personnel should be allowed to operate or work on the machine.
- The information contained in this manual is current at time of printing. Improvements to the machine are on-going and may not be covered, therefore in these cases contact your Tigercat dealer for the appropriate information.
- The phrase “and up” appearing in this manual after the serial number implies that the related information is current for any machine serial number HIGHER than the serial number preceding the “and up”.
- Tigercat reserves the right to make changes to the machine after this manual release date that may not immediately appear in this manual.
