Perkins 4 2482,4 248,T4 236,4 236,4 212,T4 38 Diesel Engines Workshop Manual
File Details:
Perkins 4 2482,4 248,T4 236,4 236,4 212,T4 38 Diesel Engines Workshop Manual
Language : English
Pages : 168
Size : 18.6 MB
Downloadable : Yes
Format : PDF
Video Preview:
Image Preview:
Table Of Contents:
Perkins 4 2482,4 248,T4 236,4 236,4 212,T4 38 Diesel Engines Workshop Manual
CO NTE NTS
Section
ENGINE PHOTOGRAPHS A
TECHNICAL DATA 8
I OPERATING AND MAINTENANCE C’
FAULT DIAGNOSIS O
CYLINDER HEAD MAINTENANCE E
PISTONS AND CONNECTING RODS F
l CYLINDER BLOCK AND LINERS G
CRANKSHAFT AND MAIN BEARINGS H
BALANCER UNIT J
TIMING CASE AND DRIVE K
LUBRICATINO SYSTEM L
COOLING SYSTEM M
AIR FILTERS AND FUEL SYSTEM N
FLYWHEEL AND FLYWNEEL HOUSING P
EXHAUSTER O
COMPRESSOR R
ALTERNATOR. DYNAMO AND STARTER MOTOR S
TURBOCHARGER T
APPROVED SERVICE TOOLS Appendix
lNDEX u
j MARINE SUPPLEMENT ..
Description:
Perkins 4 2482,4 248,T4 236,4 236,4 212,T4 38 Diesel Engines Workshop Manual
This Workshop Manual has been compiled for use in conjunction with normal workshop practice.
Mention of certain accepted practices. therefore. has been purposely omitted in order to avoid repetition.
Reference to renewing joints and cleaning off joint faces. has to a great extent been omitted from the text, it being understood that this will be carried out where applicable.
Similarly, it is understood that in reassembly and inspection, all parts are to be thoroughly cleaned, and where present, burrs and scale are to be removed. It follows that any open ports of high precision components. e.g. fuel injection equipment. exposed by dismantling, will be blanked off until reassembled.
to prevent the ingress of foreign matter. To give improved sealing. later engines are built with controlled swell type joints which are fitted dry. When fitting setscrews into “through” holes into the interior ofthe engine, a suitable sealant should be used. Note: Some setscrews may already have sealant coated threads.
These can be identified by the colour of the threads which will be red or blue etc. Engines built for Massey Ferguson applications are designated A4248, A4236. AT4.236 and A4212. Where information specific to these engines is referred to. the appropriate engine designation is given, otherwise the information is the same as listed under standard engine types.
For T4.38 engines, the information given will apply as for T4236 engines. unless otherwise stated. Throughout this manual.
whenever the “left” or right” hand side of the engine is referred to, it is that side of the engine when viewed from the flywheel end.
I Most of the general information which is included in the multi-iingual 4.236 Series Users ‘ Handbooks has not been repeated in this workshop manual and the two publications should be i used together.
: Read and remember the “Safety precautions”. They are given for your protection and must be used I at all times.
