New Holland L213 L223 L215 L225 L218 L230 L220 Tier 3 200 Series Skid Steer Loader Operator’s Manual 47571742 – PDF DOWNLOAD
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
New Holland L213 L223 L215 L225 L218 L230 L220 Tier 3 200 Series Skid Steer Loader Operator’s Manual 47571742 – PDF DOWNLOAD
200 Series Skid Steer Loader
L213 PIN NBM441228 and above
L215 PIN NBM439248 and above
L218 PIN NBM437313 and above
L220 PIN NBM435678 and above
L223 PIN NBM434543 and above
L225 PIN NBM433048 and above
L230 PIN NBM432323 and above
200 Series Compact Track Loader
C227 PIN NBM429443 and above
C232 PIN NBM427253 and above
C238 PIN NBM425088 and above
GENERAL INFORMATION:
This operators manual is to be stored in the manual compartment equipped on this machine. Make sure this manual is
complete and in good condition. Contact your dealer to obtain additional manuals. Contact your dealer for any further
information or assistance about your machine.
- Your dealer has corporation approved service parts. Your dealer has
technicians with special training that know the best methods or repair and maintenance for your skid steer. Your New
Holland Construction Dealer is available for any further information. - The information in this manual is provided on the basis of information that was available at the time that the manual
was written. Settings, procedures, part numbers, software, and other items can change. These changes can affect
the service that is given to the machine. Ensure that you have complete and current information from your dealer
before you start any machine operation.
Personal safety:
- This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible death or injury. - Throughout this manual and on machine decals, you will find the signal words DANGER, WARNING, and CAUTION
followed by special instructions. These precautions are intended for the personal safety of you and those working
with you. - DO NOT operate or permit anyone to operate or service this machine until you or the other persons have read and
understand the safety, operation, and maintenance instructions in this manual. Use only trained operators who have
demonstrated the ability to operate and service this machine correctly and safely. - All persons who will be operating
this machine shall possess a valid local vehicle operating permit and/or other applicable local age work permit. The
information in this manual is provided on the basis of information that was available at the time that the manual was
written. Settings, procedures, part numbers, software and other items can change. These changes can affect the
service that is given to the machine. Ensure that you have complete and most current information from your dealer
before you start your machine operation.
