New Holland 8365 Engine Wheel Loader Service Manual
FILE DETAILS:
New Holland 8365 Engine Wheel Loader Service Manual
Size: 81.6 MB
Format: PDF
Language: English
Number of Pages: 738 pages
Brand: New Holland
DESCRIPTION:
New Holland 8365 Engine Wheel Loader Service Manual
GENERAL INFORMATION:
- Stuflv I he Operation and Maintenance Instruction Manual before starting, operating, maintaining, lueling. or servicing mai hine Read and heed all machine-mounted safely signs before starting, operating, maintaining, lueling or servicing machine Machine-mounted safety signs have been color coded vellow with black borders and lettering for warning and red with white borders and lettering for danger points
- Do not allow unauthorized personnel to service or main- tain this machine Do not perform any work on equipment that is not authorized Follow the Maintenance and Service procedures Study the Operation and Maintenance Instruc- tion Manual before starting, operating, maintaining, fueling or servicing this machine Always wear safety glasses with side shields Do not wear rings, wrist watches, jewelry, or loose or hang- ing apparel, such as ties, tom clothing, scarves, unbuttoned or unzipped jackets that can catch on moving parts Wear proper safety equipment as authorized for the job
- Examples: hard hats, safety shoes, heavy gioves, ear pro- tectors. safety glasses or goggles, reflector vests, or respira- tors Consult your employer for specific safety equipment requirements Do not use controls or hoses as handholds when climbing on or off machine Hoses and controls are movable and do not provide a solid support. Controls may also be inadvert- ently moved causing accidental machine or equipment movement
- Do not jump on or off machine Keep two hands and one foot, or two feet and one hand, in contact with steps and grab-rails and handles at all times Machine should not be serviced with anyone in the opera- tor’s seat unless they are qualified to operate the machine mid are asaialing in the servicing. Keep operator’s compartment, stepping points, grab-rails and handles clean of foreign objects, oil. grease, mud or snow accumulation to minimize the danger of slipping or stumbling
- Clean mud or grease from shoes before attempt- ing to mount or operate the machine Never attempt to operate the machine or its tools from any other position than seated in the operator’s seat Keep operator’s compartment clear of loose objects If movement of an attachment by means of the machine’s hydraulic system is required for service or maintenance, do not raise or lower attachments from any position other than when seated in the operator’s seat Before starting machine or moving attachment or tool, make sure to set brakes, sound norn ana call tor an an clear naise auacn- ment slowly
- Always block with external support any linkage or part on machine that requires work under the raised linkage, parts, or machine according to local or national requirements. Never allow anyone to walk under or be near unblocked raised equipment.
- Avoid working or walking under raised blocked equipment unicss you are assured of your safety. Never place head, body, limbs, fingers, feet or hands into an exposed portion between uncontrolled or unguarded scissor points 01 macnine wunoui nrsi providing secure blocking Never lubricate, service or adjust a machine with the engine running, except as called for in the Operation and Maintenance Instruction Manuals Do not wear loose cloth- ing or jewelry near moving parts
- When servicing or maintenance requires access to areas that cannot be reached from the ground, use a ladder or step platform that meets local or national requirements to reach the service point. If such ladders or platforms are not available, use the machine handholds and steps as provided Perform all service or maintenance carefully Shop or field service platforms and ladders used to maiNtain or service machinery should be constructed and main- tained according to local or national requirements
- Disconnect batteries and TAG all controls according to local or national requirements to warn that work is in progress Block the machine and all attachments that must be raised according to local or national requirements Never check or fill fuel tanks, storage butteries or use starter fluid near lighted smoking materials or open flame due to the presence of flammable fluid Brakes are inoperative when manually releised for servic- ing
- Provision must be made to maintain control of the machine by blocking or other means Always place the fuel nozzle against the side of the filler opening before starting and during fuel flow To reduce the chance of a static electricity spark, keep contact until after fuel flow is shut off Use only designated towing or pulling attachment points Use care in making attachment Be sure uns and locks as provided are secure before pulling. Stay clear of drawbars, cables or chains under load To move a disabled machine, use a trailer or low boy truck if available
- If towing is necessary, provije warning signals <u> ivcjuiied by local rules and cegulationsand follow opeta- tion and maintenance instruction maiual recommenda- tions Load and unload on a level area hat gives full sup- port to the trailer wheels. Use ramps of adequate strength, low angle and proper height. Keep trailei bed clean of clay, oil and all materials that become slippery
- Tie machine down securely to truck or trailer bed aid block tracks (or wheels) as required by the carrier Never align holes with fingers or hants. Use the proper aligning tool Remove sharp edges and burrs fron rew 9? <s Use only grounded auxiliary power svurce chargers, pumps and similar equipmett to hazards of electrical shock.
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
TABLE OF CONTENTS:
New Holland 8365 Engine Wheel Loader Service Manual
60406293-8365 Engine 1
Table of Contents 8
General 10
Cylinder Block and Cylinder Head 14
Timing System 20
Crank Mechanism 27
Fuel System 35
Lubrication 41
Cooling System 42
Troubleshooting and Tests 43
Specifications 55
Tightening Torques 58
Service Tools 60
60406384-Axles FR7, FR9, FR10, FR12, FR15 63
Table of Contents 66
Safety Rules 67
8 – Disassembly, Servicing and Reassembly – FR7 and FR9 70
9 – Specifications and Data 87
10 – Torque Specifications 90
11 – Service Tools 91
12 – Disassembly, Servicing and Assembly 93
13 – Specification and Data 111
14 – Torque Specifications 113
15 – Service Tools 114
16 – Super Max-Trac Differential 115
60406412-FR15, FR15B 123
Table of Contents 124
General 128
Engine Related Components 144
Power Train 166
Axles and Wheels 172
Brake System 180
Hydraulic System 208
Electrical System 265
FR 15B/M Implement Hydraulic System 271
Service Manual FR158 Wheel Loader 306
60406415-FR15 Transmission 311
Supplement No 2 Form 604 06 415 312
Table of Contents 324
Safety Rules 326
General Information 330
Transmission System Operation 332
Torque Converter/ Transmission Specifications 336
Diagnostic Checks and Troubleshooting 345
Special Tools 349
Disassembly and Reassembly 353
60406432-FR15B Wheel Loader 423
73146366-Electrical Systems 429
Safety Rules 430
Table of Contents 437
General Description 438
Troubleshooting 439
Changing Circuit 442
Starting Circuit 450
Ignition Circuit 452
Accessory Ciruits 456
Batteries 458
Electrical System Schematics 463
73160623-Reference Service Specifictions 621
Supplement #2 To Form #73160623 623
Supplement #3 To Form #73160623 625
Index 626
I Machine Fuel Pump Part No , Timing, and Specification Page Numbers 627
II Fuel and Lubricant Specifications 628
IV Table of Lubricants 633
V Viscosity Charts 634
VI Definitions and Abbreviations 635
VII Model Specifications 637
VIII Fuel Consumption 714
IX Machine Dimensions 716
Engine Capscrew Torques 730
XI Fiat Common Engines 736
Benati Excavator Specifications 737
