KOMATSU PC8000 HYDRAULIC MINING SHOVEL GENERAL ASSEMBLY MANUAL – PDF DOWNLOAD
FILE DETAILS:
KOMATSU PC8000 HYDRAULIC MINING SHOVEL GENERAL ASSEMBLY MANUAL – PDF DOWNLOAD
Language : English
Pages : 158
Downloadable : Yes
File Type : PDF
Size: 5.19 MB
TABLE OF CONTENTS:
KOMATSU PC8000 HYDRAULIC MINING SHOVEL GENERAL ASSEMBLY MANUAL – PDF DOWNLOAD
MAIN MENU 0
COVER 1
CONTENTS 9
1 Mounting of Crawler Segments to the Side Frames: Z22917 23
2 Assembly of Undercarriage: Z22918 25
3 Assembly of Cable Reel Unit: Z22919 27
4 Mounting of Final Drives: Z22921 31
5 Electric drive only: Mounting of auxiliary weight at the undercarriage: Z22993 33
6 Mounting of Slew Ring underneath the Superstructure Platform: Z22922 35
7 Assembly of the Superstructure Platform onto the Undercarriage: Z22923 37
7 1 Rotary Distributor Z22924 39
8 Assembly of the Prime Drive Unit to the Superstructure Platform: Z22925 / Z22926 43
8 1 Overview Drive unit 45
8 2 Electric drive: Direction of motor rotation; mounting the coupling 47
9 Preassembly Boom- and Stick Cylinders to the Boom: Z22932 49
9 1 Preassembly Boom- and Stick Cylinders to the Boom (Backhoe attachment) : Z23007; Z23008 51
10 Mounting of Boom Z22933 53
11 Mounting of Counterweight: Z22934A 55
12 Mounting the Fuel Tank: Z22935 or Main Switch Cabinet for electric Driven Unit 57
13 Mounting of Cab Support Z22936 59
13 1 Mounting of Cable transfer Z22937 61
13 2 Mounting of front cover 63
14 Mounting of Operator’s Cab Z22938; Z22939 67
14 1 Mounting of the Cab air cleaner (Cab support to Cab) Z22940 69
15 Mounting of Hydraulic Oil Tank Z22941 71
16 Mounting of Hydraulic Oil Coolers Z22942; Z22943 75
17 Mounting Hand Rails, Cat Walks, Steps, Stairs and Ladders: Z22944; Z22945 79
18 Install the hydraulic access ladder Z22946 81
19 Installation of Muffler assy, and Cover: Z22928 83
20 Installation of Air Filters: Z22929 – Z22931 89
21 Installation of Lubrication Station and auxiliary Crane Z22947; Z22948 93
22 Connection of cable harnesses to the X – boards 95
23 Installation of Hose connections on Hydr Tank and Hydr Oil Coolers: Z22949; Z22950 103
23 1 Installation of Hose connections on Auxiliary Hydraulic Oil Cooler (Z22951 and Z22952) 107
24 Installation of HP- Hoses in between HP – Filters and Main Valve Blocks: Z22953 109
25 Mounting of Bucket Cylinders : Z22954; Z22955 113
26 Mounting of Stick: Z22956 115
26 1 Mounting of Stick: Z22989 (Backhoe attachment) 117
27 Installation of Hose connections to the boom: Z22957; Z22958 121
28 Filling up hydraulic tank Z22959 123
28 1 Filling up fuel tank 125
29 Pre-checks for initial Start-up 127
30 Mounting of Stick Cylinders to the Stick: Z22961 131
31 Mounting of the Pin Seals 133
31 1 Mounting of the Pin Seals 135
32 Assembly of Bullclam Bucket to the Stick (Z21876; Z22962) 141
32 1 Assembly of Backhoe to the Stick (Z23005) 145
33 Assembling and testing the Fire Detection, Actuation and Suppression System 147
34 Checks and Adjustments Prior to Commissioning 153
