Kobelco SK150LC III Hydraulic Excavator Service Manual – PDF DOWNLOAD
DESCRIPTION:
Kobelco SK150LC III Hydraulic Excavator Service Manual – PDF DOWNLOAD
The GENERAL Section deals with general specifications. operation and troubleshooting. etc. Further details regarding Systems, Components anti Procedure may be found in each respective section.
- The SYSTEMS Sutton includes descriptions specific to the mechanism of each system. each system’s relation to other systems. and procedures for repair. maintenance. removal and installation.
- In the COMPONENTS Section is information concerning the construction, functions, assemhly and assembly of this model. Maintenance standards for each component are also entered in detail.
- The PROCEDURE Section contains instructions regarding the installation of optimal parts and subsequent necessary modifications.’
When checking or repairing the machine we suggest that you refer to this manual carefully. We hope that reference to this manual will help to maintain it high level of working efficiency and reliability. For further dctafls on maintenance and checks refer to the “OPERATORS MANUAL” which has been supplied with the machine.
- Although all data was correct at the time of printing. due to continual design changes and improvements. some content: may not conform to the actual machine. Take special care to order parts only after confirming the validity of the parts number in the “PARTS MANUAL.”
- If you notice any explanatory discrepanCies. after consulting one of our representatives. please update your manual according to the latest data. However. in the event of any specification changes. we will issue revised edition.
