Hyundai HL760-9S Wheel Loader Operator’s Manual – PDF DOWNLOAD
The Hyundai HL760-9S Wheel Loader Operator’s Manual is a comprehensive guide for safe operation, maintenance, and troubleshooting of the HL760-9S model. It includes safety instructions, maintenance procedures, and important operational guidelines. Available for PDF download.
FILE DETAILS:
Hyundai HL760-9S Wheel Loader Operator’s Manual – PDF DOWNLOAD
Language : English
Pages : 181
Downloadable : Yes
File Type : PDF
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Hyundai HL760-9S Wheel Loader Operator’s Manual – PDF DOWNLOAD
The provided text seems to be an excerpt from a manual for a wheel loader, likely manufactured by Hyundai. It outlines various safety instructions and maintenance recommendations for operating the machine. Here’s a breakdown of the key points and suggestions provided: 1. **Purpose of the Manual**: The manual serves to provide instructions and safety recommendations for driving, handling, lubrication, maintenance, inspection, and adjustment of the wheel loader. It emphasizes promoting safety maintenance and enhancing machine performance. 2. **Distribution and Accessibility**: It suggests keeping the manual handy and ensuring all personnel periodically read it. Additionally, if the machine is sold, it should be passed on to the new owners to ensure they have access to the necessary safety and operational information. 3. **Compliance with Regulations**: The machine complies with the EC directive “2006/42/EC,” indicating adherence to relevant safety standards and regulations. 4. **Importance of Understanding the Manual**: Users are urged to read and understand the manual before operating the machine to prevent hazards and ensure safety. 5. **Local Consultation**: If there are attachments or optional equipment not available in the user’s area, they are advised to consult the local Hyundai distributor for assistance. 6. **Safety Precautions**: It highlights the potential hazards of improper operation and maintenance, stressing that following the manual’s instructions is crucial to avoid accidents and injuries. 7. **Intended Use**: The procedures and precautions outlined in the manual apply only to intended uses of the machine. Users are warned against engaging in prohibited uses or actions that deviate from the manual’s instructions. 8. **Jobsite Inspection**: Before operating the machine, users are advised to inspect the jobsite and follow the safety recommendations outlined in the manual’s safety hints section. 9. **Use of Genuine Parts**: Genuine Hyundai spare parts are recommended for replacements, as non-genuine parts or non-workmanlike repairs could lead to defects and damage for which Hyundai will not assume liability. 10. **Updates and Consultation**: Users are informed that design improvements may lead to changes not reflected in the manual. They are encouraged to consult Hyundai or their Hyundai distributor for the latest information regarding their machine. Overall, the manual emphasizes the importance of safety, proper maintenance, and adherence to guidelines for optimal machine performance and user protection.TABLE OF CONTENTS:
Hyundai HL760-9S Wheel Loader Operator’s Manual – PDF DOWNLOAD
Foreword 0-1
Before servicing this machine 0-2
Table to enter S/No and distribution 0-3
EC regulation approved 0-4
Safety labels 0-5
Machine data plate 0-13
Guide (direction, S/No, symbol) 0-14
1. SAFETY HINTS
1. Before operating the machine 1-1
2. During operating the machine 1-5
3. During maintenance 1-14
4. Parking 1-18
2. SPECIFICATIONS
1. Major components 2-1
2. Specifications 2-2
3. Weight 2-6
4. Specification for major components 2-7
3. CONTROL DEVICES
1. Cab devices 3-1
2. Cluster 3-2
3. Monitors 3-10
4. Switches 3-24
5. Control device 3-30
6. Air conditioner and heater 3-33
7. Others 3-37
4. OPERATION
1. Suggestion for new machine 4-1
2. Check before starting the engine 4-2
3. Starting and stop the engine 4-3
4. Warming-up operation 4-8
5. Operation of the working device 4-9
6. Traveling of the machine 4-10
7. Efficient working method 4-15
8. Adjustment of the work equipment 4-22
9. Operation in the special work sites 4-24
10. Storage 4-26
5. TRANSPORTATION
1. Road traveling 5-1
2. Preparation for transportation 5-2
3. Loading the machine 5-3
4. Fixing the machine 5-4
5. Loading and unloading by crane 5-6
6. Towing the machine 5-7
6. MAINTENANCE
1. Instructions 6-1
2. Tightening torque 6-5
3. Spec of fuel, coolant and lubricants 6-8
4. Maintenance check list 6-10
5. Maintenance chart 6-13
6. Service instruction 6-15
7. Electrical system 6-43
8. Air conditioner and heater 6-46
7. TROUBLESHOOTING GUIDE
1. Engine 7-1
2. Electrical system 7-2
3. Power train system 7-3
4. Hydraulic system 7-4
8. INDEX 8-1
