Genie Lift Truck GS-3390 GS-4390 GS-5390 Parts Manual 65758 – PDF DOWNLOAD
The Genie Lift Truck GS-3390 GS-4390 GS-5390 Parts Manual (65758) is crucial for maintenance. It offers detailed parts information for efficient servicing and repairs.
FILE DETAILS:
Genie Lift Truck GS-3390 GS-4390 GS-5390 Parts Manual 65758 – PDF DOWNLOAD
Language : English
Pages :276
Downloadable : Yes
File Type : PDF
DESCRIPTION
Genie Lift Truck GS-3390 GS-4390 GS-5390 Parts Manual 65758 – PDF DOWNLOAD
SN 40001 to 42685
How to Order Parts
Please be prepared with the following information when ordering replacement parts for your Terex or Genie product.
- Machine model number
Machine serial number
Part number
Part description and quantity
Purchase order number
Ship to” address
Desired method of shipment
Name and telephone number of the authorized
distributor in your area. - Use the Service Parts Fax Order Form on the next page and fax your order to our Parts Department.
- If you don’t know the name of your authorized distributor, or if your area is not currently serviced by an authorized distributor, please call Terex or Genie Industries
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
TABLE OF CONTENTS:
Genie Lift Truck GS-3390 GS-4390 GS-5390 Parts Manual 65758 – PDF DOWNLOAD
How to Read Your Serial Number3
Parts Stocking List7
How to Order Parts8
Service Parts Fax Order Form9
Electronic Version
Click on any page number to view the figure
100 Decals
1011 Decals with Words (to SN 41522)10
1021 Decals with Words (from SN 41523)12
1031 Decals with Symbols (from SN 41523)16
200 Drive Chassis Components
2011 Steer Axle and Linkage18
2021 Steer Axle, Wheels and Drive Hubs (to SN 41618)20
2022 Steer Axle and Drive Hubs (from SN 41619)22
2031 Non-steer Axle, Wheels and Drive Hubs (to SN
41072)24
2032 Non-steer Axle, Wheels and Drive Hubs (from SN 41073
to 41618)26
2033 Non-steer Axle, Wheels and Drive Hubs (from SN
41619)28
2041 Drive Manifold (to SN 41690)30
2042 Drive Manifold (from SN 41691)32
2051 Function Manifold, Models with Outriggers (to SN
40518)34
2052 Function Manifold, Models with Outriggers (from SN
40519 to 42239)36
2053 Function Manifold, Models with Outriggers (from SN
42240)38
2061 Function Manifold, Models without Outriggers (to SN
40518)40
2062 Function Manifold, Models without Outriggers (from SN
40519 to 42239)42
2063 Function Manifold, Models without Outriggers (from SN
42240)44
2071 Oscillate Manifold (from SN 41619 to 42297)46
2072 Oscillate Manifold (from SN 42298)48
2081 Hydraulic Hoses and Fittings, Function Manifold (to SN
41690)50
2082 Hydraulic Hoses and Fittings, Function Manifold (from
SN 41691)52
2091 Hydraulic Hoses and Fittings, 4WD Manifold (to SN
41072)54
2092 Hydraulic Hoses and Fittings, 4WD Manifold (from SN
41073 to 41320)56
2093 Hydraulic Hoses and Fittings, 4WD Manifold (from SN
41321 to 41690)58
2094 Hydraulic Hoses and Fittings, 4WD Manifold (from SN
41691)60
2101 Hydraulic Hoses and Fittings, Oscillate Manifold (from
SN 41619)62
2121 Power Cables64
2131 Electrical Wiring66
300 Engine Components
3011 Ford LRG-425 EFI Engine, View 1 (to SN 41693)70
3012 Ford LRG-425 EFI Engine, View 1 (from SN 41694)72
3021 Ford LRG-425 EFI Engine, View 2 (to SN 41693)74
3022 Ford LRG-425 EFI Engine, View 2 (from SN 41694)78
3031 Ford LRG-425 EFI Engine, View 3 (to SN 41693)82
3032 Ford LRG-425 EFI Engine, View 3 (from SN 41694)84
3041 Ford LRG-425 EFI Engine, View 4 (to SN 41693)86
3042 Ford LRG-425 EFI Engine, View 4 (from SN 41694)88
3051 Deutz F4L 1011F Engine, View 1 (to SN 41586)90
3061 Deutz F4L 1011F Engine, View 2 (to SN 41586)92
3071 Deutz F4L 1011F Engine, View 3 (to SN 41586)94
3081 Deutz F3L 2011/ D2011L03i Engine, View 1 (from SN
41587)96
3091 Deutz F3L 2011/ D2011L03i Engine, View 2 (from SN
41587)98
3101 Deutz F3L 2011/ D2011L03i Engine, View 3 (from SN
41587)102
400 Engine and Chassis Tray Components
4011 Engine Tray Components (to SN 41314)104
4012 Engine Tray Components (from SN 41315)106
4021 Engine Cover Components108
4031 Cable Track Components (to SN 40073)110
4032 Cable Track Components (from SN 40074)112
4041 Fuel and Hydraulic Tank Installation114
4051 Fuel and Hydraulic Tank Tray Components116
4061 Fuel Pump Installation, Gasoline/LPG models118
4071 Ground Controls and Cover Installation (to SN
40085)120
4081 Ground Controls, Gasoline/LPG Models (to SN
40085)122
4091 Ground Controls, Diesel Models (to SN 40085)124
4101 Ground Controls, Gasoline/LPG and Diesel Models (from
SN 40086 to 41522)126
4102 Ground Controls, Gasoline/LPG and Diesel Models (from
SN 41523)128
4111 Drive Chassis Trays130
4121 Hydraulic Tray, View 1 (from SN 40001 to 41522)132
4122 Hydraulic Tray, View 1 (from SN 41523)134
4131 Hydraulic Tray, View 2136
4141 Filters and Accumulator Installation (to SN 41006)138
4142 Filters and Accumulator Installation (from SN
41007)140
500 Scissor Components
5011 Scissor Components, View 1 – GS-3390142
5011 Scissor Components, View 1 – GS-4390144
5011 Scissor Components, View 1 – GS-5390146
5021 Scissor Components, View 2 – GS-3390148
5021 Scissor Components, View 2 – GS-4390150
5021 Scissor Components, View 2 – GS-5390152
5031 Scissor Components, View 3 – GS-3390154
5031 Scissor Components, View 3 – GS-4390156
5031 Scissor Components, View 3 – GS-5390158
5041 Scissor Components, View 4 (GS-3390)160
5051 Scissor Components, View 5 (GS-4390)162
5061 Scissor Components, View 6 (GS-5390)164
5071 Scissor Components, View 7 (to SN 40351)166
5072 Scissor Components, View 7 (from SN 40352 to
40850)168
5073 Scissor Components, View 7 (from SN 40851)170
600 Platform Components
6011 Platform Installation – GS-3390172
6011 Platform Installation – GS-4390174
6011 Platform Installation – GS-5390176
6021 Platform Rails and Entry Gates Installation178
6031 Platform Extension Deck, Steer End180
6041 Platform Extension Deck, Non-steer End, View 1182
6051 Platform Extension Deck, Non-steer End, View 2184
6061 Platform Extension Deck, Non-steer End, View 3186
6071 Platform End Rail Installation (models with single
deck)188
6081 Platform Floor Installation and Super Deck Roller
Brackets190
6091 Platform Controls Installation (to SN 41522)192
6092 Platform Controls Installation (from SN 41523)194
6101 Joystick Controller (to SN 41522)196
6102 Joystick Controller (from SN 41523)198
6111 Platform Controls (to SN 41522)200
6112 Platform Controls (from SN 41523)202
700 Accessories
7011 Power to Platform204
7021 Hydraulic Hoses and Fittings, Outriggers206
7031 Outrigger Cylinder and Footpad Assembly208
7041 Outrigger Components, View 1210
7051 Outrigger Components, View 2 (to SN 41141)212
7052 Outrigger Components, View 2 (from SN 41142)214
7061 Link Guard Assembly216
7071 Generator (to SN 40283)218
7072 Generator (from SN 40284)220
7081 Hydraulic Hoses and Fittings, Generator (to SN
40283)222
7082 Hydraulic Hoses and Fittings, Generator (from SN
40284)224
7091 Flashing Beacon226
7101 Oil Cooler228
7111 Hydraulic Hoses and Fittings, Oil Cooler230
7121 Air Line to Platform232
7131 Work Light234
7141 Spare LPG Tank236
7151 Pipe Cradle238
7161 Cold Start Package, Ford and Deutz Engines240
800 Platform Overload Components
8011 Platform Overload Components (to SN 41522)242
8021 Platform Overload Components (from SN 41523 to
42411)244
8031 Platform Overload Components (from SN 42412)246
8041 Platform Overload Plumbing Components (from SN
42412)248
Indices
Part Number Index250
Part Description Index257
Cross References
Fittings Cross Reference268
S.M 3/24
