Fiat Allis Wheel Loader FR130.2 Service Manual
FILE DETAILS:
Fiat Allis Wheel Loader FR130.2 Service Manual
Size : 61.5 MB
Format : PDF
Language : English
Brand: Fiat
Type of machine: Wheel Loader
Type of document: Service Manual
Model: Fiat Allis FR130.2 Wheel Loaders
Number of Pages: 421 pages
Part Number: 60402205
DESCRIPTION:
Fiat Allis Wheel Loader FR130.2 Service Manual
GENERALITIES:
Study this Manual before starting. operating, maintaining, fuelling or servicing the machine. Read and heed all safety rules before any intervention. 00 not allow un authorised personnel to operate service or maintain this machine. Do not wear rings, wrist watches, jewellery, loose or hanging apparels, such as ties. tom clothing. scarves, unbut- toned or unzipped jackets that can catch on moving parts. Wear proper safety equipment as recommended for the job. Examples: hard hat, heavy gloves. ear protection, safety glasses or goggles, reflector vests. respirator. Con- sult your employer for specific safety equipment requirements.
- Keep operator‘s compartment, stepping points, grab-rails and handles clear of foreign objects, oil, grease, mud or snow accumulation to minimize the danger of slipping or stumbling. Clean mud or grease from shoes beiere at- tempting to mount or operate the machine.
- Do not pump on or oil the machine. Keep two hands and one foot. or two lectand one hand in contact with step grab rails and handles at all times. 00 not use controls or hoses as hand holds when climbing on or of machine. Hoses and controls are movable and do not provide a solid support. Controls also may be inadvertently moved musing accidental machine or equipment movement.
- Never attempt to operate the machine or its tools from any position other than seated in the operator’s seat. Keep head. body. limbs. hands and feel inside operator‘s compartment at all times to reduce exposure to hazards outside the operator’s compartment.
- Be careful oi slippery conditions on stepping points, hand rails. and on the ground. Wear saiety boots or shoes that have a high slip resistant sole material. 00 not leave the machine until it is completely stopped. Check the seat safety belt at least twice a year. If there are signs of wear or fraying or other signs of weakness that could lead to tailure. replace it.
STARTING:NEVER START 0R OPERATE AN UNSAFE MACHINE. Before operating a machine, always ensure that any unsale condition has been satisfactoniy remedied. Check brakes, steering and attachment controls before moving. Advise the proper maintenance authority ol any mallunctioning part or system. Be sure all protective guards or panels are in place. and all safety devices provided are In place and in good operating conditions.
TABLE OF CONTENTS:
Fiat Allis Wheel Loader FR130.2 Service Manual
- Specification and Main Data FR130.2
- Safety Rules
- Units of Measure Used in Manual
- Lubricants
- Section 1 – Engine Components
- Section 2 — Transmission
- Section 3 — Axles
- Section 4 – Brakes
- Section 5 – Steering System
- Section 6 – Equipment Hydraulic System
- Section 7 – Bucket Boom and Frame
- Section 8 – Electrical System
- Section 9 – Cab
