FIAT ALLIS CHALMERS 645M WHEEL LOADER PARTS MANUAL – PDF DOWNLOAD
DESCRIPTION:
FIAT ALLIS CHALMERS 645M WHEEL LOADER PARTS MANUAL – PDF DOWNLOAD
IMPORTANT
- All parts listed herein, which have no specific usage indicated, are applicable to all models.
- Those parts which are used only on specific models are so indicated.
- Attaching parts such as bolts, nuts, rivets, screws, washers, etc., are indented immediately following the parts which they attach.
- Parts indicated with a square (0) are also available in packaged sets. Refer to section titled “PACKAGED PARTS”.
The terms “right” and “left”
- used throughout this parts catalog are determined by facing the direction of forward travel.
- The engine is mounted unconventionally with the flywheel toward the front of the machine, but all engine parts are designated in respect to the engine as it would be installed in a conventional machine with the flywheel to the rear.
- INSTRUCTIONS FOR ORDERING PARTS Order parts from the dealer covering the local territory.
ALWAYS GIVE THE MODEL AND SERIAL NUMBER OF MACHINE. IF PARTS ARE FOR AN ASSEMBLY WHICH HAS A MODEL AND/OR SERIAL NUMBER (SUCH AS ENGINE ASSEMBLY, PUMP ASSEMBLY), ALSO INCLUDE THIS INFORMATION.
- To obtain parts promptly, give part name and part number.
- Give post office address, town, county and state where parts are to be shipped. Also specify whether material is to be shipped by freight, express or parcel post.
- Confirm all telephone or telegraph orders in writing.
- Parts for standard motor accessories such as generators and starting motors should be ordered from authorized Service Stations maintained by manufacturers of these units throughout the country.
- No credit will be allowed on parts unless they are returned to the dealer from whom they were purchased; from there they will be returned, at the customer’s expense, to the factory for inspection.
- Unless claims for shortages or errors are made immediately upon receipt of goods, they will not be considered. When broken goods are received, a full description of the damage should be made by the carrier agent on the freight bill. If this description is insisted upon, full damage can always be collected from the transportation company. No responsibility is assumed for delay or damage to merchandise while in transit.
- Our responsibility ceases upon delivery of shipment to the transportation company from whom a receipt is received showing that shipment was in good condition when delivered to them; therefore, claims (if any) should be filed with the transportation company and not with Allis-Chalmers.
- The right is reserved to change the construction or material of any parts where it seems desirable to do so without incurring the obligation of installing such changes on units already delivered.
