EZGO RXV ELECTRIC GOLFCAR FREEDOM SHUTTLE2+2 Service Manual – PDF DOWNLOAD
DESCRIPTION:
EZGO RXV ELECTRIC GOLFCAR FREEDOM SHUTTLE2+2 Service Manual – PDF DOWNLOAD
ELECTRIC POWERED GOLF CARS & PERSONAL VEHICLES RXV GOLF CARMRXV FREEDOM RXV SHUTTLE 2+2
- Many vehicles are used for a variety of tasks beyond their original intended use. It is impossible to anticipate and warn against every possible combination of circumstances that may occur. Warnings cannot replace good common sense and prudent driving practices. Common sense and prudent driving practices do more to prevent accidents and injury than warnings and instructions can provide.
- .The manufacturer strongly suggests anyone operating the vehicle read the entire owner’s guide provided with the pur— chase of the vehicle. Pay particular attention to the CAUTIONS, WARNINGS and DANGERS within. For any questions or concerns, contact the closest representative, or write to the address on the back cover of this pub- lication,
- Attention: Customer Care Department. E-Z-GO Division of Textron reserves the right to make design changes without obligation to make these changes on units previously sold and the information contained in this manual is subject to change without notice.
- E-Z-GO Division of Textron is not liable for errors in this manual or for incidental or consequential damages that result from the use of the material in this manual. This vehicle conforms to the current applicable standard for safety and performance requirements. This vehicle is designed and manufactured for off-road use.
- it does not conform to Federal Motor Vehicle Safety Stan- dards and is not equipped for operation on public streets. Some communities may permit these types of vehicles to be operated on their streets on a limited basis and in accordance with local ordinances.
