DYNAPAC CA3500 Vibratory Roller Parts Catalog Manual 4812160189_B PDF DOWNLOAD
FILE DETAILS:
DYNAPAC CA3500 Vibratory Roller Parts Catalog Manual 4812160189_B PDF DOWNLOAD
Language : English
Pages : 632
Downloadable : Yes
File Type : PDF
TABLE OF CONTENTS:
DYNAPAC CA3500 Vibratory Roller Parts Catalog Manual 4812160189_B PDF DOWNLOAD
CA3500D/PD s/n 10000145xxA012701 – 021082
Engine: Cummins QSB 4.5 (IIIA/T3)
CA3500D/PD (IIIA/T3) SN 10000145xxA012701 – 021082 1
Service kits, non-remote engine oil filter
4812156993 Service kit, 50h Plus 3
4812159996 Service kit, 50h Plus Limited slip Rear axle 5
4812160173 Service kit, 500h Plus Cummins QSB 4.5 7
4812160172 Service kit, 500h Cummins QSB 4.5 9
4812160175 Service kit, 1000h Plus Cummins QSB 4.5 11
4812160174 Service kit, 1000h Cummins QSB 4.5 13
4812160178 Start up kit Cummins QSB 4.5 15
4812160177 Service kit, 2000h Plus Cummins QSB 4.5 17
4812160176 Service kit, 2000h Cummins QSB 4.5 19
Service kits, remote engine oil filter
4812156993 Service kit, 50h Plus See page 3
4812159996 Service kit, 50h Plus Limited slip Rear axle See page 5
4812158281 Service kit, 500h Plus Cummins QSB 4.5 21
4812158369 Service kit, 500h Cummins QSB 4.5 23
4812158282 Service kit, 1000h Plus Cummins QSB 4.5 25
4812158283 Service kit, 1000h Cummins QSB 4.5 27
4812158370 Start up kit Cummins QSB 4.5 29
4812158582 Service kit, 2000h Plus Cummins QSB 4.5 31
4812158583 Service kit, 2000h Cummins QSB 4.5 33
Repair kits
Eccentric shaft kit 35
4812157275 Drum rotation kit 37
4812158579 Shock absorber kit, drum 39
General – Keys and others
Fuses 41
Keys 43
Frame
Frame, front 45
Steering hitch, To A016503 incl. A016505
4812117507 Steering hitch, cpl 47
Steering hitch, From A016504 excl. A016505
Steering hitch module 49
4812114990 Steering hitch, cpl 51
Scrapers, option
Scrapers, option 53
Scraper module Steel 55
Scraper module Rubber 57
Scraper assy 59
Scraper module PD 61
Scraper module PD Heavy duty 63
Scraper mount 65
Frame, rear 67
Frame, rear 69
Cover assembly 71
Step module 73
Step assy 75
Tool box module, Option 77
Engine structure 79
Engine hood 81
4812120749 Engine hood, cpl
4812120749 Engine hood, cpl 83
4812118994 Lock handle, cpl 85
Fender module 87
Hinge module 89
Lock handle assy 91
Gas spring module 93
Safety link module 95
Drum
Drum, cpl 97
4812113266 Drum gear 101
Vibration motor adapter 103
Tooth wheel module 105
Drum cartridges (D-version)
4812158089 Drum cartridge, vibration side (D version) 107
4812158092 Drum cartridge, vibration side (D version) 109
4812158094 Drum cartridge with shaft nut, vibration side (D version) 111
4812158097 Drum cartridge with shaft nut, vibration side (D verison) 113
4812158084 Drum cartridge, drive side (D version) 115
4812158087 Drum cartridge, drive side (D version) 117
Drum cartridges (PD-version)
4812158090 Drum cartridge, vibration side (PD version) 119
4812158093 Drum cartridge, vibration side (PD version) 121
4812158095 Drum cartridge with shaft nut, vibration side (PD version) 123
4812158098 Drum cartridge with shaft nut, vibration side (PD version) 125
4812158085 Drum cartridge, drive side (PD version) 127
4812158088 Drum cartridge, drive side (PD version) 129
Pad shell, option 131
Engine
Engine 133
Diesel engine 137
Belt guard module 139
Bracket module 141
Cooling system 143
Cooler stand module To A015844
Cooler stand module 145
Cooler stand module From A015845
Cooler stand module 148
Hose assy kit 151
Air cleaner 153
Air cleaner module 155
Fuel system
Fuel system 157
Fuel hoses 159
Fuel tank module 161
Fuel tank 163
Brackets assy 165
Draining module 167
Exhaust system 169
Expansion tank assembly 171
Transmission
Rear axle and wheels 173
4812113344 Rear axle, limited slip
4812113344 Rear axle, limited slip 175
Differential & Bevel gear 177
Brakes 179
Hub reduction 181
4812113341 Rear axle No spin
4812113341 Rear axle No spin 183
Differential 185
Central housing and brakes 187
Hub reduction 189
Hydraulic system
Hydraulic system, drum Traction control
Hydraulic system, drum Traction control 191
Hydraulic motor module, vibration 193
4812112216 Hydraulic motor, vibration
4812112216 Hydraulic motor, vibration 195
Rotary group 197
Flush & boost pressure valve with orifice 199
Cover 201
Hydraulic motor 203
4812112215 Hydraulic motor
4812112215 Hydraulic motor 205
Rotary group 207
Flush and boost pressure valve 209
Cover with shaft seal ring 211
Hydraulic motor 213
4812112200 Hydraulic motor
4812112200 Hydraulic motor 215
Loop flushing 219
Hydraulic system, drum Anti-spin system
Hydraulic system, drum Anti-spin system 221
Hydraulic motor module, vibration See page 193
4812112216 Hydraulic motor, vibration
4812112216 Hydraulic motor, vibration See page 195
Rotary group See page 197
Flush & boost pressure valve with orifice See page 199
Cover See page 201
Hydraulic motor See page 203
4812112215 Hydraulic motor
4812112215 Hydraulic motor See page 205
Rotary group See page 207
Flush and boost pressure valve See page 209
Cover with shaft seal ring See page 211
Hydraulic motor 223
4812112202 Drum motor
4812112202 Drum motor 225
Drum motor. Front section 227
Loop flushing 229
Drum motor. Rear section 231
Hydraulic system, rear axle Traction control, limited slip
Hydraulic system, rear axle Traction control, limited slip 233
Hydraulic motor 235
4812112208 Rear axle motor
4812112208 Rear axle motor 237
Front section 239
Rear section 241
Hose holder 243
Hydraulic system, rear axle Traction control, no slip
Hydraulic system, rear axle Traction control, no slip 245
Hydraulic motor 247
4812112211 Rear axle motor
4812112211 Rear axle motor 249
Loop flusing 253
4812122932 Hydraulic motor 255
Hose holder See page 243
Hydraulic system, rear axle Anti-spin system
Hydraulic system, rear axle Anti-spin system 259
Hydraulic motor 261
Hose holder See page 243
Hydraulic system, rear axle Dual speed
Hydraulic system, rear axle Dual speed 263
Hydraulic motor 265
4812112207 Axle motor 267
Hose holder See page 243
Hydraulic system, oil tank
Hydraulic system, oil tank 271
Hydraulic oil tank assembly 273
Hydraulic valve module 277
4812120840 Hydraulic valve 279
4812112238 Hydraulic valve 281
Connector assy 283
Fan module 285
4812117796 Hydraulic motor 287
Hydraulic system, engine room
Hydraulic system, engine room 289
Hydraulic pump module 291
4812112170 Hydraulic pump, propul pump
4812112170 Hydraulic pump, propul pump 293
Front section 295
Rear section 297
Hydraulic pump module 301
Hydraulic oil filter assy 303
Hydraulic pump module 305
4812118150 Hydraulic pump, steering 307
Hydraulic system, engine room Adjustable frequency, eco opti
Hydraulic system, engine room Adjustable frequency, eco opti 309
Hydraulic pump module See page 291
4812112170 Hydraulic pump, propul pump
4812112170 Hydraulic pump, propul pump See page 293
Rear section See page 297
Front section See page 295
Hydraulic pump 311
4812112180 Hydraulic pump 313
Hydraulic oil filter assy See page 303
Hydraulic pump module See page 305
4812118150 Hydraulic pump, steering See page 307
Hydraulic pump module, Eco 315
4812118151 Hydraulic pump 317
Hydraulic system, frame rear
Hydraulic system, frame rear 319
Connector kit 321
Connector kit 323
Hydraulic system, steering
Hydraulic system, steering 325
Hydraulic cylinder 327
4812113826 Hydraulic cylinder 329
Hydraulic cylinder 331
4812121946 Hydraulic cylinder 333
Steering valve module 335
Hydraulic hoses, steering 337
Hydraulic system, emergency steering
Hydraulic system, emergency steering 339
4812112188 Hydraulic pump Emergency steering unit 341
4812112236 Hydraulic valve 343
Electric equipment
Electric cables, power supply, 1-pole
Electric cables, power supply, 1-pole 345
Battery module 347
Battery disconnector module 349
Electric cables, power supply, 2-pole, option
Electric cables, power supply, 2-pole, option 351
Battery module See page 347
Battery disconnector, 2-pole 353
Electrical cables, engine – ECU Horn, back-up alarm
Electrical cables, engine – ECU Horn, back-up alarm 355
Standard ECU assembly 358
Power converter module 361
Inclination sensor module 363
Inclination sensor module 365
Back-up alarm module 367
Back-up alarm module, Quacker 369
Horn module 371
Bracket module 373
Cable harness kit Power supply cab
Cable harness kit Power supply cab 375
Driving & side direction lights, number plate light, option
Driving & side direction lights, number plate light, option 377
Steering column switch module 379
Cable harness kit 381
Registration plate light module 383
Registration plate light 385
Holder, Registration plate light 387
Reversing light, option
Reversing light module 389
DCA/GPS equipment module, option
DCA/GPS equipment module, option 391
Holder 393
GPS equipment module 395
GPS equipment assy 397
Computer 399
Tachograph, option
Tachograph, option 401
Holder assy 403
Power supply module 405
Speed sensor, frequency sensor, option
Speed sensor, frequency sensor, option 407
Pulse sensor module (6-pol) 409
Pre-heater installation, option
Pre-heater installation, option 411
Heater 413
Rotating beacon, working light, option
Rotating beacon, working light, option 415
Rotating beacon module 417
Bracket, Rotating beacon 419
Working light module H3 421
Cable harness, emergency steering, option
Cable harness, emergency steering, option 423
Displacement shift
Displacement shift 425
Compaction meter, option
Compaction meter, option 427
Power supply 429
External emergency stop, option
External emergency stop, option 431
Drivers platform
Platform, rops
Platform, rops 433
4812120545 Platform with 4-post ROPS
4812120545 Platform with 4-post ROPS 435
Basic kit Rops, roof, front handrail 437
Rear cover 439
Handrail 441
Cab, basic kit 443
Manual box 445
Decals basic kit 447
Cab symmetric module
Cab symmetric module 449
4812119366 Cab, cpl Comfort
4812119366 Cab, cpl Comfort 451
Screens 453
4812115202 Cab door, cpl 455
4812115200 Sliding screen, left hand 457
Windshield wiper 459
Roof 461
Heater assy 463
Hose kit heater 465
Cab cable harness 467
Cab Interior 469
Heater controls 471
Cab, electrical equipment 473
Emergency hammer, hook 475
Cab, rear cover 477
Cab, front cover 479
Floor mat 481
Step light, front wiper switches 483
Cab, basic kit See page 443
Air channel 485
Sun-blind, inner light 487
4812119367 Cab, cpl Basic
4812119367 Cab, cpl Basic 489
Screens See page 453
4812115202 Cab door, cpl See page 455
4812115200 Sliding screen, left hand See page 457
Windshield wiper See page 459
Hose kit heater See page 465
Roof See page 461
Heater assy See page 463
Cab cable harness See page 467
Cab, electrical equipment See page 473
Cab Interior See page 469
Heater controls See page 471
Emergency hammer, hook See page 475
Cab, rear cover 491
Cab, front cover 493
Wiper switch, front 495
Cab, basic kit See page 443
Manual box See page 445
Decals basic kit See page 447
Rear view mirror 497
Car stereo module, option 499
Heater hoses 501
Drivers seat
Drivers seat 503
Seat frame structure 505
4700391163 Steering column 507
Floor cassette module 509
Seat frame adapter module, rotating 511
Seat frame adapter module, fixed 513
Seat comfort, fabric suspensioned 515
Seat, galon suspensioned 517
Seat belts
Seat belt 2″ 519
Seat belt 3″ 521
Seat belt 2″ with reminder 523
Seat belt 3″ with reminder 525
Control module 527
Forward reverse control module 529
Display unit 533
Reading light 535
Control panel cover 537
Decals
Decals 539
Decals 543
Plain Dynapac decals, kit 545
Optional equipment
Air conditioning
Air conditioning 547
Drying filter module 549
4812114257 Drying filter assy 551
Condensor assembly 553
ACC module 555
4812113624 ACC kit 557
AC module 559
4812113623 Evaporator, cpl 561
Hose kit AC 563
Compressor module 565
Hose assy kit for AC 567
Strike off blade kit
Strike of blade kit 569
Hydraulic and Electrical kit 571
4812113498 Hydraulic valve, Strike-off blade 573
4812121948 Hydraulic cylinder 575
Strike off blade, mount 577
Locking device, module 579
Indicator, module 581
Fire extinguisher/First Aid Cushion
Fire extinguisher/First Aid Cushion 583
Fire extinguisher 585
Level sensor module, option
Level sensor module, option 587
SMV-sign
SMV-sign 589
Cooling box module
Cooling box module 591
Lunch box
Lunch box 593
Dyn@Link module 595
4812013038 GPS module 597
Compaction meter (DCM) 599
Dyn@lyzer 601
Appendix B:Parts Index
IMAGES PREVIEW OF THE MANUAL:
PLEASE NOTE:
- This is the same manual used by the dealers to diagnose and troubleshoot your vehicle
- You will be directed to the download page as soon as the purchase is completed. The whole payment and downloading process will take anywhere between 2-5 minutes
- Need any other service / repair / parts manual, please feel free to contact [email protected] . We still have 50,000 manuals unlisted
G.P
