Daewoo Doosan ADT MT25 MT26 MT31 MT36 MT41 Operation and Maintenance Manual MX519828 – PDF DOWNLOAD
DESCRIPTION:
Daewoo Doosan ADT MT25 MT26 MT31 MT36 MT41 Operation and Maintenance Manual MX519828 – PDF DOWNLOAD
Foreword
- This manual provides rules and guidelines which will help you use this dump truck safely and effectively. This manual describes procedures for operating, handling, lubricating, maintenance, checking and adjustment. It will help the operator to achieve peak performance through effective, economical and safe dump truck operation and maintenance.
- Keep this manual in the dump truck at all times and ensure that all personnel read it carefully before operating the dump truck. • Continue studying the manual until proper operating are completely adopted as personal habit. • This manual describes the basic techniques. The operator’s skill will increase with correct knowledge of dump truck operation.
- Operation, inspection and maintenance should be carefully carried out, and safety must be given first priority. If this manual has been lost or has become dirty and cannot be read, request a replacement manual from your local Moxy Dealer. If you sell the dump truck, be sure to give this manual to the new owners. Moxy Engineering AS cannot be held responsible for damage or injury caused through use of improper spare parts not specified by Moxy Engineering AS, improper handling, operation and utilisation of the dump truck in other ways than those described in this manual.
- Nor can Moxy Engineering AS be held responsible for unauthorised modifications or the non-adherence to local, national government or international regulations. This Operating & Maintenance Manual may contain standard extra equipment and optional accessories that are not available in your area. Please consult your local Moxy Dealer for those items you may require.
- Moxy Engineering AS aim to continuously improve the dump trucks and therefore retain the right to make design changes and improvements whenever we feel it will improve the efficiency of the dump truck. Moxy Engineering AS also reserve the right to change data and equipment without prior notice, as well as amending instructions for maintenance and other service measures
WARNING
- This dump truck complies with EC directives 98/37/EC with amendments and 89/336/EC with amendments. Dump trucks complying with the directives display the CE mark. The dump truck must not be modified in such a way that it no longer complies with the EC – directive. • Improper operation and maintenance of this dump truck can be hazardous and could result in serious injury or death.
- Operators and maintenance personnel should read this manual thoroughly before operation or maintenance. • Some actions involved in operation and maintenance of the dump truck can cause serious accidents, if they are not carried out in a manner described in this manual. • The procedures and precautions given in this manual apply only to intended uses of the dump truck.
- If you use your dump truck for any unintended uses that are not specifi cally prohibited, you must be sure that it is safe for you and others. In no event should you or others engage in the prohibited uses or actions which are described in this manual.
- Moxy Engineering AS delivers dump trucks that comply with all applicable regulations and standards of the country to which it has been shipped. If this dump truck has been purchased in another country or purchase from someone in another country, it may lack certain safety devices and specifi cations that are necessary for use in your country.
- If there is any question about whether your product complies with the applicable standards and regulations of your country, consult your local Moxy Dealer before operating the dump truck.
TABLE OF CONTENTS:
Daewoo Doosan ADT MT25 MT26 MT31 MT36 MT41 Operation and Maintenance Manual MX519828 – PDF DOWNLOAD
Table 1o. fF coroewnoterdnts
1. Foreword …………………………………………………5-8
Foreword …………………………………………………………… 5
Safety information ………………………………………………. 6
Introduction ……………………………………………………….. 7
2. Safety Instructions ……………………………………. 9-40
3. Operating Controls …………………………………. 41-80
Overview of the instrument panels and controls ……… 43
Instruments ……………………………………………………….. 44
Warning / indicator lights ……………………………………… 49
Switches …………………………………………………………… 57
Controls ……………………………………………………………. 65
Cab ventilation …………………………………………………… 71
Other cab equipment ………………………………………….. 75
4. Running-in period ………………………………….. 81-86
1. Running-in operation ……………………………………… 83
2. Running-in services……………………………………….. 84
5. Operating Instructions …………………………… 87-120
Precautions on work sites ……………………………………. 89
Some simple rules to be observed prior to operation. 92
1. Starting the engine ………………………………………… 93
2. Operating the dump truck ……………………………….. 95
3. Parking the dump truck ………………………………….. 107
4. Stopping the engine ………………………………………. 107
5. Checks after stopping the engine …………………….. 108
6. Loading and tipping ……………………………………….. 108
7. Tyre handling ………………………………………………… 110
8. Cold weather ………………………………………………… 112
9. Long term storage …………………………………………. 113
10. Battery power assistance ……………………………….. 114
11. Towing the dump truck. …………………………………… 115
12. Manual release of parking brake ……………………… 115
13. Manual release of the tip valve ……………………….. 116
14. Troubleshooting …………………………………………….. 117
6. Lubricants ………………………………………….121 – 134
Lubrication schedule (MT25/26/31
Serial Number 710655 and up) …………………………….. 123
Oil specifi cation sheet (MT25/26/31
Serial Number 710655 and up) …………………………….. 125
Filling capacities (MT25/26/31
Serial Number 710655 and up) …………………………….. 126
Oil specifi cation sheet (MT36/41
Serial Number 810053 and up) …………………………….. 129
Filling capacities (MT36/41
Serial Number 810053 and up) …………………………….. 130
Transmission oil list …………………………………………….. 131
Automatic Transmission Fluid (ATF) ……………………… 132
7. Maintenance ………………………………………. 135 – 202
Maintenance precautions …………………………………….. 137
Maintenance table ………………………………………………. 139
Initial 100 Hours Service ……………………………………… 142
Initial 500 Hours Service ……………………………………… 146
8 Hours / Daily Service ……………………………………….. 149
40 Hours / Weekly Service …………………………………… 159
500 Hours Service ……………………………………………… 162
1000 Hours Service ……………………………………………. 178
2000 Hours Service ……………………………………………. 191
4000 Hours Service ……………………………………………. 197
Yearly recommended maintenance ……………………….. 201
8. Technical Data …………………………………… 203 – 220
Contents …………………………………………………………… 204
Measurements …………………………………………………… 205
Engine ………………………………………………………………. 206
Transmission ……………………………………………………… 206
Hydraulic system………………………………………………… 207
Tyre pressures …………………………………………………… 207
Electrical system ………………………………………………… 208
Metering conversion table ……………………………………. 209
Tool kit content (standard)……………………………………. 209
Tool kit content (optional) …………………………………….. 209
Performance chart ……………………………………………… 210
Engine and retarder brake capacity chart ……………… 213
Torque limits for bolts ………………………………………….. 216
Reference information …………………………………………. 216
Consumeable parts …………………………………………….. 216
Product signs …………………………………………………….. 217
Periodic service………………………………………………….. 219
9. Index …………………………………………………..221 – 226
