Claas Combine RAKE UP P420 LEXION RAKE UP P420 MEDION MEGA Set-Up Instructions Manual – PDF DOWNLOAD
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION
Claas Combine RAKE UP P420 LEXION RAKE UP P420 MEDION MEGA Set-Up Instructions Manual – PDF DOWNLOAD
1.1 GENERAL SAFETY PRACTICES
All operators must
- Be instructed in the safe and proper use of this machine and understand all safety signs and instructions in this manual.
- Carefully read all safety messages in this manual and on your machine.
- Keep all safety signs in good condition. Replace when necessary.
- Use and maintain all safety lights and devices.
- Wear necessary protective clothing when operating or servicing machinery.
- Be prepared for emergencies by keeping a first aid kit and emergency numbers easily accessible.
- Have authorized personnel repair/replace any damaged or deteriorated parts immediately to reduce the risk of personal injury.
- Find a spacious, clear, and level surface to perform any maintenance or adjustments.
- Always shut-off machinery before performing any adjustments or service.
- Never remove obstructions from running machinery.
- Never operate machinery without all shields in place.
- Never engage pickup drive with people near machine.
- Review safety instructions annually.
TABLE OF CONTENTS:
Claas Combine RAKE UP P420 LEXION RAKE UP P420 MEDION MEGA Set-Up Instructions Manual – PDF DOWNLOAD
11 General Safety Practices1
12 Safety During Combine Installation1
13 Safety During Operation2
14 Safety During Servicing 2
A) Tire Safety 2
B) Hold down Safety Locks 3
C) Feeder House Safety Locks 3
SECTION 2 SET UP
21 Assembling Units From Shipping Configuration4
A) Lower Unit Into Operating Position / Remove Shipping Stands 4
B) Hold Down Assembly (up to machine no 4324000) 6
B) Hold Down Assembly (from machine no 4324000) 8
C) Wheel Installation (up to machine no 4324000) 10
C) Wheel Installation (from machine no 4324000)11
D) Hydraulic Connections11
E) Shock Installation 12
F) Driveshaft Installation12
G) Hydraulic Motor Installation12
22 Connecting Header/Pickup to Combine 13
23 Disengaging Storage Braces and Locks 16
24 Rotating Spring Wires Out of Shipping Position 16
25 Testing Hydraulic Holddown 17
A) Test 17
B) Servicing Hold down Hydraulics 17
C) Bleed Hydraulics 18
26 Drive Shaft Installation19
TABLE OF CONTENTS
SECTION 3 ADJUSTMENTS
31 Tire Pressure and Wheel Torque 21
32 Opening Header Side Panels 21
33 Tooth Height Adjustment (up to machine no 4324000) 21
34 Tooth Height Adjustment (from machine no 4324000) 22
35 Suspension Adjustment 23
36 Draper Belt Tensioning 24
37 Fiberglass Rod/Spring Wire Orientation 25
38 Speed Control 26
39 Auger Finger Adjustment 26
310 Auger & Stripper Bar Adjustment27
311 Header Drive Chain Adjustment 29
