CLAAS Axos 340-310 Diagnostics Repair Manual – PDF DOWNLOAD
DESCRIPTION:
CLAAS Axos 340-310 Diagnostics Repair Manual – PDF DOWNLOAD
Language :English
Pages :146
Downloadable : Yes
File Type : PDF
Size:11.5 mb
TABLE OF CONTENTS:
CLAAS Axos 340-310 Diagnostics Repair Manual – PDF DOWNLOAD
GENERAL
CLAAS COMPONENT NUMBERS (CCN) list 7
List of connectors10
GENERAL WIRING 15
List of harnesses16
List of grounding points17
Fuse plates and electronic plates 18
F1 – FUNCTION DIAGRAMS
WORK LIGHTS
Work light on rear fender 5
ROAD SIGNALLING
Position and police plate lights 6
Dipped headlights 7
Main beam lights 8
Brake lights 9
Rotating beacons 10
Horn 11
Flashing indicators and hazard warning lights 12
Instrument panel lighting 13
PTO
Front power take-off – Shuttle reverser 14
Front power take-off – Mechanical reverser 15
Rear power take-off – Mechanical reverser 16
Rear power take-off – Shuttle reverser 17
STARTING AND LOADING CIRCUIT
Starting and loading circuit – Mechanical reverser 18
Starting and loading circuit – Revershift 19
Pre-heating 20
TRANSMISSION
Forward – Reverse 21
4-wheel drive control 22
Hydraulic pressure – Mechanical reverser 23
Hydraulic pressure – Shuttle reverser 24
Transmission temperature 25
Hydraulic dual range unit 26
4 Axos 340-310 – 052009 – GB
10 Electric system (platform)
F1 Function diagrams
NETWORKS
Controller Area Network (CAN) 27
SUPPLY
Supply before contact 28
Supply after contact 29
Earth 30
Earth 31
Earth 32
Transmission module power supply 33
Diagnostic plug – Mechanical reverser 34
Diagnostic plug – Shuttle reverser 35
Dashboard module power supply 36
TRACTOR/TOOL LINK
25A power socket 37
Charger socket 38
BRAKE SYSTEM
Handbrake 39
TRANSMISSION SPEED
Theoretical forward speed and transmission load 40
LEVELS
Fuel gauge 41
ENGINE
Oil pressure, air filter clogging, engine temperature 42
Fuel pump 43
INSTRUMENT PANEL
Calibration, dashboard display 44
