Notes on these instructions
This repair manual includes information and instructions on how to perform repair work on the GRAMMER seat suspension MSG97AL of the following seat models:
• Holder for height adjustment, lateral isolator and vertical shock absorber on the left
• Holder for height adjustment, lateral isolator and vertical shock absorber at the front
• Cable harness for seat suspension with vehicle plug integrated at the rear of the upper suspension part
• Cable harness for seat suspension with vehicle plug integrated at the outside of the cable harness
- The repair of the upper seat part is described in the repair manual for the upper seat part S721 – S742, to which a reference is made, if required. Example: The cable harness for the upper seat part has been inspected and found to be OK (see repair manual for upper seat part). The seat suspension MSG97AL with vehicle plug integrated at the rear of the upper suspension part forms the basis for illustrations in this repair manual.
- In the case of technical deviations in work procedures (due to different seat suspension designs), refer to the current text or individual chapters of the manual. Each chapter starts with a list of all preparatory work to be completed before starting repair.
- These preparations are described in separate chapters and shall be carried out without the preparatory steps described there. At the beginning of each description for repair you will find an overview diagram. All parts included in the overview diagrams within one chapter are consecutively numbered starting with “1”. Each component is referred to by the same number throughout the document.
- With the help of these overview diagrams, an experienced technician will gain a quick overview. For spare part orders, please use the numbers stated in the latest issue of the relevant spare parts catalogue.
- The description of the work procedures refers to the removed seat suspension. Depending on the individual installation situation, some work may also be performed on the installed seat suspension and/or with upper seat part. For this reason, check the environment of the installed seat suspension for this possibility before starting work.
- The safety instructions of the specific vehicle manufacturer and those stated in Chapter 1 of this repair manual must be strictly observed.
- This repair manual also includes some information on delivery options, if these require further explanation. Since the scope of delivery depends on the specific customer order, the actual seat suspension design may deviate from the descriptions and illustrations in this manual.
- The illustrated repair steps refer to the seat suspension for left-hand drive. Different work steps are to be performed laterally reversed when repairing vehicle models with right-hand drive.
- If not stated otherwise, the directional indications “front, back” and “right, left” refer to the installed seat suspension regarded in the driving direction of the vehicle.
- The document layout is suitable for later use of this repair manual via CD-ROM / INTERNET / INTRANET.
- A navigation line was entered below the heading for this. This navigation line includes the Chapter titles and it allows the user to jump directly to these Chapters after the corresponding hyperlinks have been set.
TABLE OF CONTENTS:
CLAAS Axion 850-810 Diagnostic Repair manual – PDF DOWNLOAD
TABLE OF CONTENTS
Preliminary remarks
1 Description
1.1 Safety instructions
1.2 Rating plate
2 Diagnosis
2.1 Overview of components
2.2 Functional test – Testing the specified status of functions
2.3 Overview of faults – Pointing out possible faults that might occur
2.4 Troubleshooting – Locating the fault
3.1 Seat suspension – removal and installation
3.2 Center and rear cover – removal and installation
3.2.1 Center and rear cover – removal and installation (seat suspension with handle on the left)
3.2.2 Center and rear cover – removal and installation (seat suspension with handle at the front)
3.3 Covers on the right and left side – removal and installation
3.4 Bellows – removal and installation
3.4.1 Bellows – removal and installation (seat suspension with handle on the left)
3.4.2 Bellows – removal and installation (seat suspension with handle at the front)
3.5 Bowden pull wire and handle for vertical shock absorber adjustment – removal and installation
3.5.1 Bowden pull wire and handle for vertical shock absorber adjustment – removal and installation
(seat suspension with handle on the left)
3.5.2 Bowden pull wire and handle for vertical shock absorber adjustment – removal and installation
(seat suspension with handle at the front)
3.6 Vertical shock absorber – removal and installation
3.7 Locking mechanism for fore/aft isolator – removal and installation
3.7.1 Locking mechanism for fore/aft isolator – removal and installation (seat suspension with handle on the left)
3.7.2 Locking mechanism for fore/aft isolator – removal and installation (seat suspension with handle at the front)
3.8 Handle for fore/aft isolator – removal and installation
3.8.1 Handle for fore/aft isolator – removal and installation (seat suspension with handle on the left)
3.8.2 Handle for fore/aft isolator – removal and installation (seat suspension with handle at the front)
3.9 Longitudinal horizontal shock absorber – removal and installation
3.10 Fore/aft isolator unit – removal and installation
3.11 Compressor – removal and installation
3.12 Level control – removal and installation
3.13 Level control (micro-switch, outlet valve) – adjustment
3.14 Air hoses – removal and installation
3.15 Handle for height adjustment – removal and installation
3.16 Holder for height adjustment – removal and installation
3.16.1 Holder for height adjustment – removal and installation (seat suspension with handle on the left)
3.16.2 Holder for height adjustment – removal and installation (seat suspension with handle at the front)
3.17 Bowden pull wires for height adjustment – removal and installation
3.17.1 Bowden pull wires for height adjustment – removal and installation (seat suspension with handle on the left)
3.17.2 Bowden pull wires for height adjustment – removal and installation (seat suspension with handle at the front)
3.18 Bowden pull wires for height adjustment – inspection and adjustment
3.19 Air spring – removal and installation
3.20 Additional air supply – removal and installation
3.21 Cable harness of vehicle connection – removal and installation
3.22 Cable harness of seat suspension (incl. U-profile) – removal and installation
3.22.1 Cable harness for seat suspension with vehicle plug integrated at the rear of the upper suspension part
– removal and installation
3.22.2 Cable harness for seat suspension with vehicle plug integrated at the outside of the cable harness
– removal and installation
3.23 Upper suspension part – removal and installation
3.24 Lower suspension part – removal and installation
3.25 Swinging structure – disassembly and assembly
3.26 Worn parts – replacement
3.27 Front cover – removal and installation (seat suspension with handle at the front
