1960 DODGE PASSENGER CAR SERVICE MANUAL – PDF DOWNLOAD
DESCRIPTION:
1960 DODGE PASSENGER CAR SERVICE MANUAL – PDF DOWNLOAD
FOREWORD
This manual is dedicated to the thousands of Dodge Service Technicians all over the world … who, enthused with their responsibility to the motoring public, constantly search for knowledge and new service methods in the increasingly complicated skill of modern day auto mechanics … in order to provide a better and more economical service to their community.
It covers many conditions that may be encountered, together with their possible causes. Each section contains practical disassembly, repair and assembly procedures. The customer’s description of a condition, when brought to the attention of the Dealer’s Service Department, should be verified by a road test, unless the condition is obvious by visual examination. The service tools referred to in this Manual, or their equivalent, are necessary for efficient servicing of Dodge cars. All tools listed are available
DODGE VEHICLE NUMBERS
All vehicle numbers contain ten digits. The vehicle number is a code which tells the make of car (1st digit), model of car (2nd digit), year built (3rd digit), assembly plant ( 4th digit) and vehicle serial number (last six digits). Listed below is the coding for Dodge cars
VEHICLE NUMBER LOCATION :
The vehicle number (serial number) is located on a plate which is attached to the left front door hinge pillar post.
ENGINE IDENTIFICATION
Engines may be identified by engine numbers according to the following prefixes: Super Red Ram V-8, P-36; Ram Fire V-8, P-38; D-500 Ram Induction 361 V-8, P-36; D-500 Ram Induction 383 V-8, P-38; Economy Slant “6”. P-22-numbers of these engines are stamped in position “A” shown at right. Red Ram V-8 prefix P-318-number stamped in position “B” shown at right.
BODY NUMBER LOCATION
The body number is stamped on a plate which is attached to the left or right side of the engine side of the dash, or on front of radiator yoke
2. ENGINE LUBRICATION
Engine Oil A special break-in oil has been added to your new Dodge Dart at the factory. Do not change this oil until your Dodge Dart has gone 1,000 miles. If necessary to maintain a proper level, (Fig. 5) add oil appropriate to the temperature range shown on the following chart. Because weather and road conditions vary throughout the country, it is best to consult your local Dodge dealr as to how often you should change oil. Your particular driving requirements will also determine how often oil should be changed. In general, oil should be changed every 2,000 miles. However, your particular driving requirements may permit extended oil change periods; whereas, short trip operation and cold weather or extremely dusty conditions may require oil changes mor often. Follow the recommendation of your Dodge dealer.
TABLE OF CONTENTS:
1960 DODGE PASSENGER CAR SERVICE MANUAL – PDF DOWNLOAD
Generator (2 oilers)
Upper Ball Joints (2 fittings, 1 on each joint)
Lower Ball Joints (2 fittings, l on each joint)
Distributor ( 1 oiler)
Clutch Torque Shaft (if so equipped) ( 1 fitting)
Tie Rod Ball Ends ( 4 fittings, 2 on each tie rod)
Gearshift Tube and Lower Support Assembly (if so equipped)
( 1 fitting)
Door Guides, Latches, Striker Plates and Rotor Wheels
Trunk and Hood Latches, Door Hinges and Check Arms
Parking Brake Pull Rod
Parking Brake Linkage (External-Contracting Type Only)
(if so equipped)
Manifold Heat Control Valve
Transmission Lubricant Level-3-Speed, Manual Shift
Manual Steering Lubricant Level –
Power Steering Lubricant Level
Rear Axle
Fuel Tank Filler Tube Accessory Cover Hinge
Type of Lubricant
(See “Lubricant Key”)
TorqueFlite, PowerFlite and TorqueFlite Six Transmissions (Check
Fluid Level)
Check Brake Fluid Level in Master Cylinder Reservoir
\Perform all operations in 1,000 mile service–plus the following:
Engine Oil -Drain and Refill*
Rotate Tires (including spare)
* Add 1 quart of oil if filter is changed
Type of Lubricant
(See “Lubricant Key”)
EO
EVERY 5,000 MILES
Check the
Items Below
Tire Pressures
Radiator-Coolant
Battery
Check the
Items Below
Type of Lubricant Check the
SP-rvice (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service–plus the following:
Engine Oil-Drain and Refill EO Brake Adjustment
Engine Oil Filter Element-Replace
Carburetor Air Cleaner-CLEAN WITH AIR PRESSURE ONLY
EVERY 7,000 MILES
Service
Perform all operations in 1,000 mile service–plus the following:
Engine Oil-Drain and Refill*
* Add 1 quart of oil if filter is changed
Type of Lubricant
(See “Lubricant Key”)
EO
Check the
Items Below
5
MyMopar com
6 LUBRICATION AND MAINTENANCE
EVERY 9,000 MILES
Type of Lubricant Check the
Service (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill EO Brake Adjustment
Engine Oil Filter Element-Replace
Rotate Tires (including spare)
Engine Tune-Up (Minor)
EVERY 11,000 MILES
Service
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill
Carburetor Air Cleaner-CLEAN WITH AIR PRESSURE ONLY
Steering Column Gearshift Lever Upper Pivot
Door Lock Cylinders
Speedometer Cable
Distributor Cam
Front Wheel Bearings-Repack
Automatic Transmissions
(Maintenance Tune-Up) (Drain, Clean Oil Pan and Screen,
Adjust Complete)
Type of Lubricant
(See “Lubricant Key”)
EVERY 13,000 MILES
Service
Type of Lubricant
(See “Lubricant Key”)
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill EO
Engine Oil Filter Element-Replace
EVERY 15,000 MILES
Check the
Items Below
Brake Adjustment
Brake Lining
Headlight Aiming
Check the
Items Below
Type of Lubricant Check the
SP rvice (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill* EO Brake Adjustment
Carburetor Air Cleaner-Replace
Rotate Tires (including spare)
* Add 1 quart of oil if filter is replaced
Service
EVERY 17,000 MILES
Type of Lubricant
(See “Lubricant Key”)
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill EO
Engine Oil Filter Element-Replace
Check the
Items Below
MyMopar com
LUBRICATION AND MAINTENANCE
EVERY 19,000 MILES
Type of Lubricant Check the
Service (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill* , EO Brake Adjustment
Engine Tune-Up-(Minor)
* Add 1 quart of oil if filter is replaced
Service
EVERY 21,000 MILES
Type of Lubricant
(See “Lubricant Key”)
Perform all operations in 1,000 mile service-plus the following:
Check the
Items Below
7
Engine Oil-Drain and Refill
Oil Filter Element-Replace
Carburetor Air Cleaner-Clean
EO Brake Linings
Front End Alignment
Headlight Aiming
Rear Axle-Drain and Refill
(Sure Grip)
Universal Joints-Clean and Refill
Manual Transmission -Drain and Refill
Automatic Transmission-Drain and Refill
(Clean Oil Pan and Screen-Adjust Complete)
Rotate Tires (including spare)
Door Lock Cylinders
Steering Column Gearshift Lever Upper Pivot
Speedometer Cable
Distributor Cam
Front Wheel Bearings-Repack and Adjust
MP
EVERY 23,000 MILES
Service
Perform all operations in 1,000 mile service-plus the following:
Type of Lubricant
(See “Lubricant Key”)
Engine Oil-Drain and Refill* EO
Fuel Line Filter Element (Paper)-Replace
* Add 1 quart of oil if filter is replaced
PARTS REQUIRING NO LUBRICATION
Check the
Items Below
Rubber bushings (See Paragraph 25)
Oilite bearings
Gearshift and automatic transmission drive selector
Rear springs, bolts and shackles
Starter bearings
Carburetor air cleaner
Carburetor linkage
Accelerator pedal linkage
Steering gear arm pivot
linkage
Brake and clutch pedals, and linkage
Clutch release bearing
Idler arm pivots
Upper and lower control arm bearings
Fan belt idler pulley
Water pump
Rear wheel bearings Generator (2 oilers)
Upper Ball Joints (2 fittings, 1 on each joint)
Lower Ball Joints (2 fittings, l on each joint)
Distributor ( 1 oiler)
Clutch Torque Shaft (if so equipped) ( 1 fitting)
Tie Rod Ball Ends ( 4 fittings, 2 on each tie rod)
Gearshift Tube and Lower Support Assembly (if so equipped)
( 1 fitting)
Door Guides, Latches, Striker Plates and Rotor Wheels
Trunk and Hood Latches, Door Hinges and Check Arms
Parking Brake Pull Rod
Parking Brake Linkage (External-Contracting Type Only)
(if so equipped)
Manifold Heat Control Valve
Transmission Lubricant Level-3-Speed, Manual Shift
Manual Steering Lubricant Level –
Power Steering Lubricant Level
Rear Axle
Fuel Tank Filler Tube Accessory Cover Hinge
Type of Lubricant
(See “Lubricant Key”)
TorqueFlite, PowerFlite and TorqueFlite Six Transmissions (Check
Fluid Level)
Check Brake Fluid Level in Master Cylinder Reservoir
\Perform all operations in 1,000 mile service–plus the following:
Engine Oil -Drain and Refill*
Rotate Tires (including spare)
* Add 1 quart of oil if filter is changed
Type of Lubricant
(See “Lubricant Key”)
EO
EVERY 5,000 MILES
Check the
Items Below
Tire Pressures
Radiator-Coolant
Battery
Check the
Items Below
Type of Lubricant Check the
SP-rvice (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service–plus the following:
Engine Oil-Drain and Refill EO Brake Adjustment
Engine Oil Filter Element-Replace
Carburetor Air Cleaner-CLEAN WITH AIR PRESSURE ONLY
EVERY 7,000 MILES
Service
Perform all operations in 1,000 mile service–plus the following:
Engine Oil-Drain and Refill*
* Add 1 quart of oil if filter is changed
Type of Lubricant
(See “Lubricant Key”)
EO
Check the
Items Below
5
MyMopar com
6 LUBRICATION AND MAINTENANCE
EVERY 9,000 MILES
Type of Lubricant Check the
Service (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill EO Brake Adjustment
Engine Oil Filter Element-Replace
Rotate Tires (including spare)
Engine Tune-Up (Minor)
EVERY 11,000 MILES
Service
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill
Carburetor Air Cleaner-CLEAN WITH AIR PRESSURE ONLY
Steering Column Gearshift Lever Upper Pivot
Door Lock Cylinders
Speedometer Cable
Distributor Cam
Front Wheel Bearings-Repack
Automatic Transmissions
(Maintenance Tune-Up) (Drain, Clean Oil Pan and Screen,
Adjust Complete)
Type of Lubricant
(See “Lubricant Key”)
EVERY 13,000 MILES
Service
Type of Lubricant
(See “Lubricant Key”)
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill EO
Engine Oil Filter Element-Replace
EVERY 15,000 MILES
Check the
Items Below
Brake Adjustment
Brake Lining
Headlight Aiming
Check the
Items Below
Type of Lubricant Check the
SP rvice (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill* EO Brake Adjustment
Carburetor Air Cleaner-Replace
Rotate Tires (including spare)
* Add 1 quart of oil if filter is replaced
Service
EVERY 17,000 MILES
Type of Lubricant
(See “Lubricant Key”)
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill EO
Engine Oil Filter Element-Replace
Check the
Items Below
MyMopar com
LUBRICATION AND MAINTENANCE
EVERY 19,000 MILES
Type of Lubricant Check the
Service (See “Lubricant Key”) Items Below
Perform all operations in 1,000 mile service-plus the following:
Engine Oil-Drain and Refill* , EO Brake Adjustment
Engine Tune-Up-(Minor)
* Add 1 quart of oil if filter is replaced
Service
EVERY 21,000 MILES
Type of Lubricant
(See “Lubricant Key”)
Perform all operations in 1,000 mile service-plus the following:
Check the
Items Below
7
Engine Oil-Drain and Refill
Oil Filter Element-Replace
Carburetor Air Cleaner-Clean
EO Brake Linings
Front End Alignment
Headlight Aiming
Rear Axle-Drain and Refill
(Sure Grip)
Universal Joints-Clean and Refill
Manual Transmission -Drain and Refill
Automatic Transmission-Drain and Refill
(Clean Oil Pan and Screen-Adjust Complete)
Rotate Tires (including spare)
Door Lock Cylinders
Steering Column Gearshift Lever Upper Pivot
Speedometer Cable
Distributor Cam
Front Wheel Bearings-Repack and Adjust
MP
EVERY 23,000 MILES
Service
Perform all operations in 1,000 mile service-plus the following:
Type of Lubricant
(See “Lubricant Key”)
Engine Oil-Drain and Refill* EO
Fuel Line Filter Element (Paper)-Replace
* Add 1 quart of oil if filter is replaced
PARTS REQUIRING NO LUBRICATION
Check the
Items Below
Rubber bushings (See Paragraph 25)
Oilite bearings
Gearshift and automatic transmission drive selector
Rear springs, bolts and shackles
Starter bearings
Carburetor air cleaner
Carburetor linkage
Accelerator pedal linkage
Steering gear arm pivot
linkage
Brake and clutch pedals, and linkage
Clutch release bearing
Idler arm pivots
Upper and lower control arm bearings
Fan belt idler pulley
Water pump
Rear wheel bearings
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
PLEASE NOTE:
- This is the same manual used by the DEALERSHIPS to SERVICE your vehicle.
- The manual can be all yours – Once payment is complete, you will be taken to the download page from where you can download the manual. All in 2-5 minutes time!!
- Need any other service / repair / parts manual, please feel free to contact us at heydownloadss @gmail.com . We may surprise you with a nice offer
S.M
