Yale A955 ERP 16-20 VF Service Manual – PDF DOWNLOAD
FILE DETAILS:
Yale A955 ERP 16-20 VF Service Manual – PDF DOWNLOAD
Format: PDF
Language: English
Brand: Yale
DESCRIPTION:
Yale A955 ERP 16-20 VF Service Manual – PDF DOWNLOAD
FRAME
ERP15-20VT (ERP030-040VT) [G807];
ERP16-20VF (ERP30-40VF) [A955]
- When lifting parts or assemblies, make sure all slings, chains, or cables are correctly fastened, and that the load being lifted is balanced. Make sure the crane, cables, and chains have the capacity to support the weight of the load. Do not lift heavy parts by hand, use a lifting mechanism.
- Wear safety glasses. DISCONNECT THE BATTERY CONNECTOR before doing any maintenance or repair on electric lift trucks. Disconnect the battery ground cable on internal combustion lift trucks. Always use correct blocks to prevent the unit from rolling or falling. See HOW TO PUT THE LIFT TRUCK ON BLOCKS in the Operating Manual or the Periodic Maintenance section.
- Keep the unit clean and the working area clean and orderly. Use the correct tools for the job. Keep the tools clean and in good condition. Always use YALE APPROVED parts when making repairs. Replacement parts must meet or exceed the specifications of the original equipment manufacturer. Make sure all nuts, bolts, snap rings, and other fastening devices are removed before using force to remove parts.
- Always fasten a DO NOT OPERATE tag to the controls of the unit when making repairs, or if the unit needs repairs. Be sure to follow the WARNING and CAUTION notes in the instructions. Gasoline, Liquid Petroleum Gas (LPG), Compressed Natural Gas (CNG), and Diesel fuel are flammable.
- Be sure to follow the necessary safety precautions when handling these fuels and when working on these fuel systems. Batteries generate flammable gas when they are being charged. Keep fire and sparks away from the area. Make sure the area is well ventilated. NOTE: The following symbols and words indicate safety information in this manual:
TABLE OF CONTENTS:
Yale A955 ERP 16-20 VF Service Manual – PDF DOWNLOAD
Introduction 1
General 1
Description of Operation 2
Discharging the Capacitors 3
Covers and Floor Plates 3
Overhead Guard Replacement 5
Remove 5
Install 7
Hood and Seat Assembly 9
Remove 11
Install 11
Ground Test 13
Counterweight Replacement 13
Remove 14
Install 17
Safety Labels 19
Painting Instructions 23
Battery Specifications 24
ERP15-20VT (G807) European Model Trucks 24
ERP030-040VT (G807) US Model Trucks 24
ERP16-20VF (A955) European Model Trucks 25
ERP30-40VF (A955) US Model Trucks
