Wacker Neuson WL52 Wheel Loader Operator’s Manual – PDF DOWNLOAD
1 Foreword
1.1 Operator’s Manual
Information on this Operator’s Manual
- This Operator’s Manual describes how to operate and perform maintenance on the machine. It provides operating and maintenance personnel with the necessary knowledge of the machine’s functional characteristics to ensure safe handling, correct maintenance, inspection and cleaning, and to ensure that the technical safety regulations for the machine are
- complied with. Your own safety, as well as the safety of others, depends to a great extent on how the machine is moved and operated. Therefore, carefully read and understand this Operator’s Manual prior to the first drive. By reading the Operator’s Manual, the operator familiarizes himself more quickly with the machine, and uses it more safely and efficiently.
- If required, the user/owner of the machine must supplement the Operator’s Manual with instructions and regulations regarding environmental protection and national accident prevention regulations. Operational safety and readiness of the machine do not only depend on the operator’s skill, but also on maintenance and servicing of the machine.
- This is why regular maintenance and servicing is absolutely necessary. Please refer to chapter Information on cleaning and maintenance on page 7-17 for an overview of the maintenance and service work. An inspection booklet is also supplied with the machine.
Information
The maintenance and repair work that is not specified in this Operator’s
Manual may only be performed by an authorized service center.
The Operator’s Manual must be read and applied by all persons involved
in work with or on the machine, for example with regard to:
• Operatiion, including setting up, rectifying malfunctions during
operation, maintenance, disposal of auxiliary and operating material,
and disposal of the entire machine.
• Repairs (inspection, maintenance).
• Transportation.
Your dealer and the Wacker Neuson service team will be happy to answer any questions you may have on this Operator’s Manual. All technical indications in this Operator’s Manual refer to series models tested under standard operating conditions for Central Europe and describe the standard functions of these series models. The equipment and its functional modes and accessories depend on the relevant model and the product options, as well as on the national requirements. Illustrations may show optional/additional equipment that is not mentioned in the text or not supplied as standard
