Volvo Ew160d Wheeled Excavator Service Manual
DESCRIPTION:
The machine is a wheeled excavator with a 360 degree swing movement. The machine is equipped with a computerized monitoring and control system. The different control units are communicating via bus systems. The machine is equipped with a Volvo D6H, tier 4i compliant, low-emission diesel engine with a respective after treatment system for the exhaust gases. The whole system is adapted for this excavator model. The engine and the after treatment system is controlled by two control units.
The diesel engine drives the machine’s working pump, which gives hydraulic oil flow to the working hydraulics and the travel motor. The double gear pump is mounted behind the working pump and supplies the servo, brake and steering hydraulics. The standard cooling fan for the radiator, hydraulic oil cooler, charge air cooler and air conditioner condenser is direct driven. The hydraulic system is monitored and controlled by the vehicle control unit (V-ECU). The machine has a load-sensing hydraulic system which always ensures that each movement receives oil according to the demand and no function stops.
SCREENSHOT OF THE MANUAL:
TABLE OF CONTENTS:
General
Standard Parts, Service
Engine with Mounting and Equipment
Elec. System, Warning System ,Information System, Instruments
Power Transmission
Brake
Steering
Frame and Wheel
Machinery House, Cab, Exterior Trim Parts Anywhere
Hydraulic System, Digging, Handling, Grading Equipment, Misc Equipment
and more
