MB-248-93 Operation, Maintenance and Parts 1
Table of Contents 2
Section A: Inspection, Safety, and Introduction 3
Section B: Operating Instructions 5
Section D: Maintenance Guide Checklist 8
Section E: Lubrication Diagram10
Section F: Trouble Shooting Procedures11
Section G: Wiring Diagram13
Section H: Parts Ordering Procedure14
Section I: Suggested Spare Parts List15
Section J1: Front Axle, Fork, Steering and Tires – Maintenance Procedures17
Section J2: Power Traction Rear Axle, Motor and Brakes – Maintenance Procedures34
Section J3: Hydraulic Brake System – Maintenance Procedures49
Section J4: Mechanical Control Linkage – Maintenance Procedures55
Section J5: Forward/Reverse Control Switch – Maintenance Procedures58
Section J6: Rheostat Control Switch – Maintenance Procedures63
Section J7: General Electrical System – Maintenance Procedures69
Section J8: Batteries – Maintenance Procedures71
Section J9: Body and Trim – Maintenance Procedures84

DESCRIPITION:

Taylor-Dunn B,BN,M Operation & Maintenance Instructions With Parts Manual S.NO 15000 through 19799 – PDF DOWNLOAD

OPERATING INSTRUCTIONS:

The controls _on your Taylor-Dunn vehicle have been designed and located for convenience of operation and efficient performance. Before driving your vehicle for the first time, familiarize yourself with each of the controls. Read the following instructions and with power OFF, operate each control.

• STEERING The steering wheel and steering system is similar to automotive types. Turn the steering wheel to the right (clockwise) for a right turn and left (counterclockwise) for a left turn.
• KEY LOCK Your vehicle 1.s equipped with a keyed lock located on the corner of forward reverse switch. It is designed to lock the switch in the neutral position only.The key will remove from the lock in the locked position (neutral) only.
• PARK B RAKE (HAND) The hand parking brake is located in the right center of floor board. To engage hand brake, grasp top lever and pull towards rear, all the way, till hand lever stops. To release brake, push hand lever all the way forward.
• SERVICE BRAKE (FOOT) The brake pedal is designed and located for right foot operation. It is the pedal located to the left of accelerator pedal. It functions the same as the brake pedal in your automobile. Depressing the pedal applies the braking action. The greater the effort applied to the pedal with your foot, the greater the braking action to your vehicle. Removing your foot from the pedal allows immediate release of the braking action to your vehicle.
• FORWARD/REVERSE SWITCH The forward/reverse switch is located to the right of the drivers seat. It is operated by the red handle. To place in forward position pull the red handle to the left towards the driver. To place in reverse position~ the red handle to the right,~ from the driver.
• CAUTION: The forward/reverse switch serves the same purpose as the transmission in your automobile. Treat it with the same respect and care. DO NOT SHIFT from forward to reverse or vice-versa while the vehicle is in motion. Shifting while in motion, especially near top speed, causes great strain to your entire vehicle and will eventually cause severe damage, complete loss of power and could cause an accident
