Renault Ceres 325 335 345 355 Workshop Manual
FILE DETAILS:
Renault Ceres 325 335 345 355 Workshop Manual
FILE TYPE:PDF
DOWNLOADABLE:YES
MANUAL LANGUAGE:ENGLISH
PAGES:898
SAMPLE PAGE FROM THE MANUAL:
Renault Ceres 325 335 345 355 Workshop Manual
1 – Loosen the belts tensron usrng a Jornted handle and a socket on the tension arm. Remove the belt from the pulleys.
2 – Release the tension applied to the tension arm and remove the jointed handle.
3 – Scribe a mark (A) on the tensioner swivel arm as shown in the illustration.
4 – Measure 21 mm from (A) and scribe a mark (B) on the tensionerfitting base.
5 – Swivel the arm using a torque wrench until the marks (A) and (B) are aligned with (C).
6 – Log the torque wrench measurement and compare it with the specification below. Change the tensioner if required.
TABLE OF CONTENTS:
Renault Ceres 325 335 345 355 Workshop Manual
IDENTIFICATION
INJECTION PUMPS IDENTIFICATION
SPECIFICATIONS
MAIN SPECIFICATIONS
TIGHTENING TORQUES
OPERATING PRINCIPLES
SUPPLY
FUEL FILTER
INJECTION PUMP
INJECTORS
CHECKS – ADJUSTMENTS
ENGINE SPEED
STATIC ADJUSTMENT OF THE ROTARY INJECTION PUMP
DYNAMIC ADJUSTMENT OF THE ROTARY INJECTION PUMP
INJECTORADJUSTMENT
CRACKING PRESSUREADJUSTMENT
NEEDLE STROKE ADJUSTMENT
SHUT-OFF SOLENOID VALVE FUNCTIONAL CHECK
COLD-START SWITCH FUNCTIONAL CHECK
REMOVAL – INSTALLATION
FUEL FILTER REPLACEMENT
INJECTION SYSTEM BLEEDING
ROTARY INJECTION PUMP REMOVAL
ROTARYINJECTION PUMPINSTALLATION
INJECTORSEATING CLEANING
INJECTORINSTALLATION
CARRYING OVER OF THE ADJUSTMENT MARK ONTO THE FRONT PLATE
ADJUSTMENT OF CONTROLS
ADJUSTMENT OF THE ACCELERATORCABLE
DIAGNOSTIC SHEETS
ENGINE START FAILURE SHEET
ENGINE IRREGULAROPERATION SHEET
GREY OR BLACK SMOKE EMISSION SHEET
WHITE SMOKE EMISSION SHEET
CHECKING THE FUEL SUPPLY SYSTEM SHEET
TOOLS
INJECTION TOOLS
