Plymouth Duster 1993 Workshop Repair Service Manual
IMAGE PREVIEW:
DESCRIPTION:
These manuals are the same as the manuals given to official dealers Workshops, they contain detailed instructions and step by step diagrams for all workshop procedures. Everything from changing the plugs to rebuilding the engine, as well as electrical diagrams, torque settings, fluid capacities, etc. All service and repair procedures are covered.
At the click of a mouse you have access to the most comprehensive diagnostic, service, repair and maintenance information as used by professional technicians & mechanics.
Written by the manufacturers, these OEM manuals contain HUNDREDS of pages of diagrams and detailed information for specific vehicle or equipment repair. These Original Service Manuals, Wiring Diagrams and Bulletins are the most accurate and complete available.
Each SHOP Manual is year and model specific. It features factory diagnostic and repair procedures and can give you access to the same repair information that certified technicians and mechanics use.
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
SAMPLE PAGE
CONNECTOR AND TERMINAL ASSEMBLY
REPLACEMENT
(1) Disconnect Battery.
(2) Disconnect the connector being repaired form
its mating half.
(3) Cut off the existing wire connector directly behind
the insulator. Remove six inches of tape from
the harness.
(4) Stagger cut all wires on the harness side about
1/2 inch apart (Fig. 14).
(5) Remove 1 inch of insulation from each wire on
the harness side.
(6) Stagger cut the matching wires on the repair
connector assembly in the opposite order as was done
on the harness side of the repair. Allow extra length
for soldered connections. Check that the overall
length is the same as the original (Fig. 14).
(7) Remove 1 inch of insulation from each wire.
(8) Place a piece of heat shrink tubing over one
side of the wire. Make sure the tubing will be long
enough to cover and seal the entire repair area.
(9) Spread the strands of the wire apart on each
part of the exposed wires (Fig. 11 example 1).
(10) Push the two ends of wire together until the
strands of wire are close to the insulation (Fig. 11 example
2).
(11) Twist the wires together (Fig. 11 example 3).
(12) Solder the connection together using rosin
core type solder only. Do not use acid core solder.
(13) Center the heat shrink tubing over the joint
and heat using a heat gun. Heat the joint until the
tubing is tightly sealed and sealant comes out of both
ends of the tubing.
(14) Repeat steps 8 thru 13 for each wire.
(15) Re-tape the wire harness starting 1-1/2 inches
behind the connector and 2 inches past the repair.
(16) Reconnect the repaired connector.
(17) Connect battery and test all affected systems.
