DESCRIPTION:

O and K WHEEL LOADER MODEL 4000-TB053 PARTS MANUAL – PDF DOWNLOAD

Manual No. T3053
MANUAL PART NO. 2022684
(Includes Revision 3)

ORDERING PARTS:

In order to avoid delay, unnecessary correspondence, and to have your orders filled correctly, promptly and at the least possible expense, the following is the recom- mended procedure to use when ordering replacement ‘parts. Call, wire or write your authorized TROJAN distributor, giving him the following information:

1. Your purchase order numbers.
2. Complete invoicing and shipping address.
3. Specify method of shipment; otherwise, least expensive method will be used.
4. Give the correct part numbers and descriptions, using your parts manual as reference.
3. Provide the model and serial number of your tractor shovel and the model and serial number of the major components for which these parts are required.

WHEN PARTS ARE RECEIVED:

1. Check immediately for quantity, correctness and condition.
2. Advise your TROJAN distributor of any error.
3. Claims for damages during shipping, should be made to the carrier immediately.
SERIAL NUMBER PLATES :
  • The tractor shovel serial number plate is located in the operator’s compartment to the left of the seat and park- ing brake lever. Always give the serial number of the machine when ordering parts. The Cummins Engine serial number plate is located on the engine to the rear of the injection pump and air compressor. The engine model and serial number are given on the engine serial number plate.
  • Always provide the engine model and serial number when ordering parts from your Cummins Engine dealer. The General Motors Engine serial number plate is lo- cated on the rocker arm cover. The engine model, serial number and assembly group numbers are listed. Always provide engine model and serial numbers when order- ing parts from your local GM Diesel dealer.
  • The transmission serial number plate is located on the right rear of the transmission case. The part number and serial number of the transmission are stamped on the plate. See Fig. l. The Torque converter serial number plate is located on the converter housing. The part number and serial number of the converter are stamped on the plate.
  • The axle serial number plates are located on the front and rear axles on the left‘hand side near the diEerential carrier. The model number and serial number of each axle are given on these plates. The machine model and serial number, engine model and serial number, transmission part number and serial number, front axle part number and serial number and rear axle part number and serial number should be entered in the front of the parts and operator’s manual for quick reference when ordering parts.

TABLE OF CONTENTS:

O and K WHEEL LOADER MODEL 4000-TB053 PARTS MANUAL – PDF DOWNLOAD

GENERAL INSTRUCTIONS:

Adjustments
Axle Overhaul
Differential
Planetary
Ball Slip Overhaul
Brake Components
Air Chamber
Brake System
Adjusting the Brakes
Capacities Pressures Electrical System
Cylinder Overhaul
Bucket Cylinder
Lift Cylinder
Steering Cylinder
Filters and Breathers
General Instructions
Hydraulic Systems
Main Hydraulic
SteeringHydraulie
Transmission Hydraulic
InstrumentPanel
Lubrication Charts
Lubrication and Service
Main Pivot Overhaul
Operating Instructions
Pillow Bled: Overhaul
Pum Overhaul:
Steering Hydraulic
Start-Up Shut-Down Procedure
Steering Gear Overhaul
Steering Linkage
Torque Chart
Torque Converter (See Index Rear of Manual)
Towing
Transmission Overhaul
(See Index Rear of Manual)
Trouble Shooting Charts:
Brake System
Main Control Valve
Torque Converter
(See Index Rear of Manual)
Valve:
Main Hydraulic Control
Transmission Control
(See Index Rear of Manual)

PARTS LISTING:

A
Accelerator Pedal and Linkage (GM Diesel)
Accelerator Pedal and Linkage
(Cummins Diesel)
Air Chamber, Front Axle
Air Chamber, Rear Axle
Air Cleaner and Exhaust System (GM Diesel)
Air Cleaner and Exhaus tSystem
(Cummins Diesel)
Air Shift, ‘Reverse to Forward
Automatic Bucket Leveler and Piping
Axle Assembly, Rear
Axle Assembly, Front
B
Ball Slip Assembly
Battery and Wiring (GM Diesel)
Battery and Wiring (Cummins Diesel)
Brake Controls and lines (GM Diesel)
Brake Controls and Lines (Cummins Diesel)
Brake, Front Axle
Brake, Rear Axle
Brake, Parking
Bucket and Teeth Assembly
Bucket Cylinder
Bucket Indicator
Bucket Leveler
C
Clutch Cut-Out Switch
Clutch CutaOut System
Control Valve, Main Hydraulic (2 Spool)
Cooling System, Hydraulic Oil
Cylinder, Bucket
Cylinder, Lift
Cylinder, Steering
D
Decals
Demand Valve
Diflerential Group, Front Axle
Differential, Group, Rear Axle
Directional Lever, F-N—R
Dra Link
DualBrake Valve
E
Engine and Related Parts (GM Diesel)
Engine and Related Parts (Cummins Diesel)
Engine Controls (GM Diesel)
Engine Controls (Cummins Diesel)
Ether Starting Kit
Exhaust System (GM Diesel)
Exhaust System (Cummins Diesel)
F
Filter Element Assembly, Hydraulic Oil
Filter, Steering Hydraulic
Filter Assembly, Transmission Oil
Floorboards ‘
Frame, Main
Front Axle Brake Group
Fuel Tank and Lines (GM Diesel)
Fuel Tank and Lines (Cummins Diesel)
G
Gauges, Instrument Panel
Grille
H
Head Lights
Hood
Hydraulic Control Valve Levers, Main
Hydraulic Control Valve, Main (2 Spool)
Hydraulic Oil Cooling System
Hydraulic Pump, Main
Hydraulic Pump, Steering
Hydraulic System, Main
Hydraulic System, Steering
Hydraulic System, Transmission
I
Instrument Panel
L
Leveling Arm
Lift Arm Linkage
Lift Cylinder
M
Main Frame Components
Main Hydraulic System
MainHydraulic Pump
Motor Mounts (GM Diesel)
Motor Mounts (Cummins Diesel)
Motor, Windshield Wiper
Muffler (GM Diesel)
Muffler (Cummins Diesel)
O
Oil Filter Assembly, Transmission
Oil Filter Element Assembly, Hydrulic
P
Parking Brake Lever Assembly
Parking Brake Linkage
Pillow, Block Assemibly
Pivot Group
Planetary Hub, Rear Axle
Planetary Hub, Front Axle
Propeller-Shafts
Pump, Main Hydraulic
Pump, Steering Hydraulic
Pump, Torque Converter Charging
R
Radiator (GM Diesel)
Radiator (Cumimns Diesel) :
Range Selector Lever
RearAxle
Regenerative Valve
S
Seat :
Selector Valve ;
Sheetmetal
Shift, Reverse to Forward Air
Steering Gear Assembly and Linkage
Steering Gear
Steering Hydraulic Filter
Steering Hydraulic System
Steering Pump
Steering Valve
Switch, Clutch Cut-Out
T
Throttle Linkage
Tires and Wheels
Tools
Torque Converter Charging Pum;
Transmission Controls
Transmission Hydraulic System
Transmission Mounting Parts
V
Valve Controls, Main
Valve, Demand
Valve, Dual Brake
Valve, Main Hydraulic Control
(2 Spool)
Valve, Regenerative
Valve, Selector
Valve, Steering
W
Wheels
Windshield Wiper Kit
Windshield Wiper Installation
Wiring (GM Diesel]
Wiring (Cummins Diesel)
