Mitsubishi S12A2-Y1TAA1 Diesel Engine Parts Manual PN H98260H0130 – PDF

OIL SYSTEM
OIL PUMP
OIL STRAINER
OIL PIPE (PART-1)
OIL PIPE (PART-21
OIL COOLER
OIL COOLER ASSY
OIL FILTER & BY-PASS FILTER
OIL FILLER & LEVEL GAGE
BREATHER
COOLING SYSTEM
WATER PUMP & TENSION PULLEY
COOLING SYSTEM (PART-1)
COOLING SYSTEM (PART-2)
FAN DRIVE
FUEL SYSTEM
FUEL INJECTION PUMP GENERAL
FUEL SYSTEM
NOZZLE ASSY
FUEL RACK CONTROL
INJECTION PUMP R. H
INJECTION PUMP LH (UP TO E/#-23033)
INJECTION PUMP LH (FROM E/#23034-1COUPLING
FEED PUMP
COUPLING ASSY
FUEL RETURN PIPING
FUEL FILTER PIPING
ACTUATOR
STARTING SYSTEM
STARTER (24V-11KW)
ALTERNATOR GENERAL
ALTERNATOR (24V-150A)
STOP SYSTEM
STOP SYSTEM
INSTRUMENT
INSTRUMENT (PART-1)
INSTRUMENT (PART-2)
TOOL
TOOLS
REPAIR PARTS
OVERHAUL GASKET KIT (PART-1)
OVERHAUL GASKET KIT (PART-2)
LOCK WASHER & OIL SEAL KIT
NUMERICAL PARTS INDEX

This Parts Catalogue contains service parts for the following Hitachi S12A2-Y1TAA1 basic engi

2. This Parts Catalogue applies to the engiines whose serial numbers are 22328 and up.

3. When ordering parts, give the Hitachi dealer or distributor the following information:

(1) Part number (or assembly number) and part name.

(2) Quantity required

(3) Model and serial number NOTE: In case where the ordered parts happen to be out of stock, substitute parts (interchangeable with those ordered) will be supplied.

4. Indication of assembled bolts with washer Of the standard bolts, those with washers are identified by the symbol “B/W” in the Description column of each list. (Part Name: BOLT,W/WASHER) For the part numbers of the bolts and washers and those of bolts with washers, refer to the listing (beginning with the page D1) at the end of this parts catalogue. These bolts and washers should be ordered individually.

5. Indication of combination for replase ability -” G ” – The new part to be used in combination with the other part in place of an old part is Indented by the symbol “G” in the interchangeability code column of each list. For the parts to be combined, refer to the listing (beginning with the page E1) at the End of the parts catalogue.

6. For the numerical index, refer to the page beginning with C1 at the end of this parts catalogue.
