Massey Ferguson 3600 Series Tractor Workshop Service Manual – PDF DOWNLOAD
DESCRIPTION:
Massey Ferguson 3600 Series Tractor Workshop Service Manual – PDF DOWNLOAD
INTRODUCTION:
- The purpose of this manual is to assist Dealers and Distributors in the efficient repair and maintenance of Massey Ferguson farm machinery. Carrying out the procedures as detailed, together with the use of special tools where appropriate, will enable the operations to be completed within the time stated in the Repair Time Schedule.
- To assist with locating information, each section of the manual is preceded by a contents page listing the operations. Each instruction within an operation has a sequence number, and to complete the operation in the minimum time it is essential that these instructions are performed in numerical sequence commencing at 1, unless otherwise stated. When applicable, these sequence numbers identify the components in the appropriate illustration. Where an operation requires the use of a special tool, the tool number is quoted under the operation heading and is repeated in, or following, the instruction involving its use.
Indexing :
For convenience the manual is divided into sections and parts, each page bearing a section and part number. The sections are subdivided into numbered operations. Example: 1-7 A would be Operation 1 in Section 7, Part A. This simplifies cross referencing and enables the subject to be found easily.
Definition of Terms :
The operation descriptions generally used throughout the schedules may be defined as follows:
Removal and Refitment – Remove and refit an original part or assembly, or a new part or assembly which does not involve additional operations or time.
Install – Install a part or component not previously fitted e.g., accessories. O
Overhaul – Remove a part or assembly, dismantle, inspect and recondition, re-assemble, and re-install making all necessary adjustments.
Dis-assembly and Re-assembly – The terms ‘Disassembly’ and ‘Re-assembly’ indicate the orderly taking apart of an assembly into individual parts and rebuilding it into the original assembly.
Adjust – Make the necessary adjustments to restore specified setting or performance.
Check – Ascertain if a setting or condition is within the limits of acceptability, either as defined in the manufacturer’s specifications or, where a dimension is not specified, in the judgement of the mechanic. The checking of fixings, e.g. nuts and bolts, includes tightening to the specified torque figures listed in this Manual.
Servicing – All technical work undertaken to maintain the machine in working order.
Special Tools :
Where the use of a special tool is specified in an operation the tool number will be shown under the operation heading and also following the instruction requiring its use. The use of the special tools mentioned in the text contributes to a safe, efficient and profitable repair. Some operations are impracticable without their use, for example, the refitment of the differential unit. Distributors and Dealers are therefore urged to check their tools against the list provided. For further details, refer to the special tool catalogue for this range of tractors, Section 14 of this manual.
Repairs and Replacements :
- When service parts are required it is essential that only genuine AGCO replacements are used. Attention is particularly drawn to the following points concerning repairs and the fitting of replacement parts and accessories: Safety features embodied in the tractor may be impaired if other than genuine parts are fitted.
- In certain territories, legislation prohibits the fitting of parts not to the tractor manufacturer’s specification. Torque wrench setting figures given in the Workshop Manual must be strictly adhered to. Locking devices where specified must be fitted. If the efficiency of a locking device is impaired during removal it must be renewed. The tractor warranty may be invalidated by the fitting of other than genuine AGCO parts. All AGCO replacements have the full backing of the manufacturer’s warranty. Massey Ferguson Dealers are obliged to supply only genuine service parts.
TABLE OF CONTENTS:
Massey Ferguson 3600 Series Tractor Workshop Service Manual – PDF DOWNLOAD
INTRODUCTION AND SAFETY 01
GENERAL INFORMATION, SPECIFICATIONS 02
DIFFERENTIAL 03
TRANSMISSION 048
2WD AXLE 0SA
FRONT AXLE 058
ENGINE 06
AMENDMENT 07
