Manitou TMP55 HT TMV50 55 HT TIER 2 ENGINE VERTICAL LIFT MAST Operator Manual – PDF DOWNLOAD
TMP55/HT
TMV50/55/HT
TIER 2 ENGINE
VERTICAL LIFT MAST
TMP55 S/N: 751864, 755749 & ABOVE
TMV50/55 S/N: 755748 & ABOVE
CATALOG 809800
ROUGH TERRAIN FORKLIFT TRUCK GENERAL SAFETY STANDARDS
STUDY THE OPERATOR/SERVICE MANUALS:
The information in this manual provides general instructions for the safe operation and maintenance of your forklift truck. This information is vital and must be clearly understood by the operator and serviceman. Study this manual and the Rough Terrain Forklift Safety Manual (part no. 422494) thoroughly and carefully before operating or servicing your forklift. Contact your dealer or Manitou North America, Inc. if you have any questions concerning your forklift, its operation, service or parts. Keep both manuals in the literature box on the forklift available for reference. If either manual becomes illegible or is missing, contact your dealer for replacements immediately. This manual cannot cover every situation that might result in an accident. It is the responsibility of the operator to always remain alert for potential hazards and be prepared to avoid them!
ADDITIONAL RECOMMENDED LITERATURE:
ANSI / ITSDF B56.6 is the national consensus standard for rough terrain forklift trucks. It contains rules about forklift safety, maintenance, safe operation, training, and supervision. Forklift owners should learn this standard and make it available for their operators, service personnel, and supervisors.
These standards can be obtained, free of charge, from the Industrial Truck Standards Development Foundation (ITSDF) on their website at www.itsdf.org. The following references are examples from the standard, addressing forklift operators:
A.) OPERATOR TRAINING QUALIFICATIONS
1.) The user shall ensure that operators understand that safe operation is the operator’s responsibility. The
user shall ensure that operators are knowledgeable of, and observe, all safety rules and practices.
2.) Create an effective operator training program centered around user company’s policies, operating conditions,
and rough terrain forklift trucks. The program should be presented completely to all new operators and
not be condensed for those claiming previous experience.
3.) Information on operator training is available from several sources, including rough terrain forklift truck manufacturers,
users, government agencies, etc.
4.) An operator training program should consist of the following:
a.) careful selection of the operator, considering physical qualifications, job attitude, and aptitude;
b.) emphasis on safety of stock, equipment, operator, and other personnel;
c.) citing of rules and why they were formulated;
d.) basic fundamentals of rough terrain forklift truck and component design as related to safety, e.g.,
in.-lb (N-m) loading, mechanical limitations, center of gravity, stability, etc.;
e.) introduction to equipment, control locations, and functions. Explain how they work when used
properly and problems when used improperly.
f.) supervise practice on operating course remote from normal activity and designed to simulate
actual operations, e.g., lumber stacking, elevating shingles to the roof, etc.;
g.) oral, written, and operational performance tests and evaluations during and at completion of the
course;
h.) refresher courses, which may be condensed versions of the primary
course, and periodic “on job” operator evaluation;
i.) understanding of nameplate data and operator instructions and warning information appearing on
the rough terrain forklift truck.
TABLE OF CONTENTS:
Manitou TMP55 HT TMV50 55 HT TIER 2 ENGINE VERTICAL LIFT MAST Operator Manual – PDF DOWNLOAD
SECTION ONE – FORKLIFT OPERATION AND SAFETY 1 – 1
– GENUINE SPARE PARTS 1 — 2
– GENERAL OPERATING INSTRUCTIONS 1 — 3
– LOAD HANDLING INSTRUCTIONS 1 — 7
– MOUNTING THE LIFT TRUCK TO THE FLATBED TRAILER 1 — 12
– MAINTENANCE INSTRUCTIONS OF THE LIFT TRUCK 1 — 15
– BEFORE STARTING UP A NEW LIFT TRUCK 1 — 17
SECTION TWO – Forklift DESCRIPTION 2 – 1
– IDENTIFICATION NAME PLATES 2 — 2
– CHARACTERISTICS 2 — 4
– SPECIFICATIONS 2 — 8
– INSTRUMENTS AND CONTROLS 2 — 12
SECTION THREE – SERVICING THE FORKLIFT 3 – 1
– FILTER CARTRIDGES AND BELTS 3 — 2
– LUBRICANTS 3 — 3
– SERVICING SCHEDULE 3 — 4
– ALTERNATIVE TRANSPORT 3 — 22
A – TOWING THE LIFT TRUCK 3 — 22
B – FLATBED TRANSPORTING 3 — 22
