Liebherr Wheel Loader L507-1578 Service manual – PDF DOWNLOAD
IMAGES PREVIEW OF THE MANUAL:
FILE DETAILS:
Liebherr Wheel Loader L507-1578 Service manual – PDF DOWNLOAD
Language : English
Pages :688
Downloadable : Yes
File Type : PDF
Size:138 MB
DESCRIPTION:
Liebherr Wheel Loader L507-1578 Service manual – PDF DOWNLOAD
- This service manual is designed for trained specialist staff of the Liebherr organisation and their dealers.
- This service manual contains specialist knowledge for repairing Liebherr construc- tion machines. Basic specialist knowledge on electronics, hydraulics, mechanics and engine technology is not contained in this service manual. Therefore special- ized training and qualifications are necessary. Liebherr recommends participating in the Liebherr training program for construction machines.
In this service manual you will find information on:
- You will find information on controls and operation in the operator’s manual. Information on spare parts are in the spare parts catalogue. Please observe the local accident prevention laws.
- You can find information on repairs of machine parts in the service documentation under “Wheel loader – repair instructions”.
To ensure safe operation:
- Consult with the worksite manager about safety regulations at the place of use.
- Adhere to safety regulations at the place of use.
- Follow traffic regulations.
- Adhere to valid guidelines provided by insurers (for example, employers’ professional liability insurance companies, accident insurance, etc.).
- Avoid working methods that can endanger safety.
- Follow all intervals specified for recurrent checks and inspections as outlined in this operator’s manual.
1.2. Intended Use of Wheel Loader
The wheel loader is used to pick up, move, and dump the following materials:
- Soil
- Stones
- Broken rocks
- Bulk materials
This applies to a standard machine under normal operating conditions. Special applications are described in a separate options operator’s manual.
To ensure the intended use:
- Adhere to the operator’s manual.
- Follow maintenance intervals.
- Carry out inspection and maintenance tasks.
- Follow the specifications in the technical data.
- When using the machine on public roads, ensure it complies with applicable national regulations.
- Only lift loads with intended working attachments (fork prongs, crane boom), which must be properly fitted and functioning.
- Ensure that machines used underground (for mining and tunnel construction) are fitted with systems to reduce exhaust emissions (such as diesel particulate filters).
- Adhere to the requirements of each individual country for underground operation.
- For special uses, use special working attachments and, if necessary, special safety equipment.
- Exclusively mount and use special working attachments with approval and as per the stipulations of the manufacturer of the basic machine
TABLE OF CONTENTS:
Liebherr Wheel Loader L507-1578 Service manual – PDF DOWNLOAD
010.1 Safety instructions 010-4
010.1.1 Information on these instructions 010-4
010.1.1.1 Representation of warning messages 010-4
010.1.1.2 Graphic symbols in these instructions 010-4
010.1.2 Intended use 010-5
010.1.2.1 Laws, rules, guidelines and safety regulations 010-5
010.1.2.2 Intended use 010-5
010.1.2.3 Foreseeable misuse 010-6
010.1.2.4 Operating conditions 010-6
010.1.2.5 Disposal 010-7
010.1.3 Description of staff 010-7
010.1.3.1 Personal protective equipment 010-7
010.1.3.2 Requirements for staff 010-8
010.1.3.3 Operating company 010-8
010.1.3.4 Operator 010-9
010.1.3.5 Maintenance staff 010-9
010.1.3.6 Refrigeration technician 010-10
010.1.3.7 Slinger 010-11
010.1.3.8 Spotter 010-12
0101.4 Protective devices on the machine 010-12
010.1.4.1 Operator’s cab 010-12
010.1.4.2 Roll over protective structure (ROPS) 010-13
010.1.4.3 Falling object protective structures (FOPS) 010-13
0101.5 Emergency equipment on the machine 010-13
010.1.5.1 Emergency exit (standard) 010-13
010.1.5.2 Fire extinguisher (option) 010-14
010.1.6 Safe operation 010-14
010.1.6.1 Intoxicants 010-1
010.1.6.3 Transporting machine 010-15
010.1.6.4 Access to machine 010-15
010.1.6.5 Machine danger zone 010-16
010.1.6.6 Visibility 010-16
010.1.6.7 Protection against vibration 010-17
010.1.6.8 Operation of machine 010-18
010.1.7 Safe maintenance 010-21
010.1.7.1 Spare parts 010-21
010.1.7.2 Heavy parts 010-21
010.1.7.3 Regular checks 010-22
010.1.8 Modifications to the machine 010-22
010.1.8.1 Modifications, add-ons and retrofittings 010-22
Special tools for maintenance and repair work 010-23
010.21 Special tools, general 010-23
010.2.2 Special tools for diesel engine 010-25
010.2.3 Special tools for lift cylinders 010-26
010.2.4 Special tools for tilt cylinders 010-26
010.25 Special tools for steering wheel 010-27
010.2.6 Special tools for steering cylinders 010-27
010.2.7 Special tools for the electrical system 010-28
010.2.8 Special tools for the air conditioning system 010-29
010.2.9 Special tools for cab glazing 010-31
010.2.10 Special tools for the central lubrication system (Liebherr) 010-31
Standards and regulations 010-32
010.3.1 Prestressing forces and tightening torques for bolts with metric
standard and fine threads as per DIN ISO 261 010-32
010.3.1.1 Range of application and purpose 010-32
010.3.1.2 Other applicable documents 010-32
010.3.1.3 Modifications and descriptions 010-33
010.3.1.4 Tightening torques 010-33
010.3.2 Liebherr standards for assembly instructions and tightening torques010-39
Preservation guidelines 010-40
010.4.1 General information 010-40
010.4.2 Machine out of service for an unknown period of time 010-40
010.4.3.1 Out of service for up to 2 months 010-41
010.4.3.2 Out of service for up to 12 months 010-42
010.4.3.3 Out of service for longer than 12 months 010-43
010.44 Putting back into service 010-43
010.4.4.1 After being out of service for 2 months 010-43
010.44.2 After being out of service for 12 months 010-44
010.4.4.3 After being out of service for longer than 12 months 010-44
020 Technical data 020-1
020.1 Overall machine 020-4
020.1.1 Complete machine with bucket (z-bar kinematics)
L507-1578; 020-4
0201.2 Working attachment: light material bucket
L507-1578; 020-5
020.1.3 Working attachment: 4 in 1 bucket
L507-1578; 020-6
020.1.4 Working attachment: forklift
L507-1578; 020-8
020.2 Drive group 020-10
020.2.1 Diesel engine
L507-1578/0-53994; 020-10
0202.2 Diesel engine
L507-1578/53995-; 020-11
0202.3 Fuel tank
L507-1578; 020-12
020.24 Fuel level sensor
L507-1578; 020-13
020.3 Cooling system 020-14
020.3.1 Fan pump
L507-1578; 020-14
020.3.2 Fan motor
L507-1578; 020-14
020.3.3 Hydraulic oil temperature sensor B8
L507-1578; 020-14
020.4 Working hydraulics 020-15
0204.1 Working pump
L507-1578; 020-15
0204.2 Control block
L507-1578; 020-15
copyright ® Liebherr-Werk Bischofshofen GmbH 2020
L507-1678 LIEBHERR 7
Contents
020.4.4 Pilot control hydro accumulator
1507-1578; 020-15
020.4.5 Stabilisation module
L507-1578; 020-15
020.4.6 Ride control hydro accumulator
L 507-1578; 020-16
020.4.7 Lift cylinder
L507-1578; 020-16
020.4.8 Tilt cylinder
1507-1578; 020-16
020.49 Working pump
L507-1578; 020-17
020.5 Travel hydraulics 020-18
020.5.1 Travel pump
L 507-1578; 020-18
020.5.2 Travel pump high pressure sensor B45
L507-1578; 020-18
020.5.3 Travel motor
1507-1578; 020-18
020.6 Hydraulic components 020-20
020.6.1 Return suction filter
1507-1578; 020-20
020.6.2 Breather filter with filler strainer
L507-1578; 020-20
020.7 Steering system 020-21
020.7.1 Servostat
1507-1578; 020-21
020.7.2 Steering cylinder
L507-1578; 020-21
020.8 Brake system 020-22
020.8.1 Drum brake
L 507-1578; 020-22
020.8.2 Inch/brake unit
1507-1578; 020-22
020.8.3 Brake light pressure switch B12
L507-1578; 020-22
020.8.4 Spring accumulator cylinder for parking brake
L507-1578; 020-23
020.9 Electrical system 020-24
020.9.1 Central control unit (Master 4)
L507-1578; 020-24
020.9.3 Battery
L507-1578; 020-24
0209.4 Voltage transformer
L507-1578; 020-25
020.10 Gearbox 020-26
020.10.1 Transmission
L507-1578; 020-26
020.11 Axles and drive shafts 020-27
020.11.1 Front axle
L507-1578; 020-27
020.11.2 Rear axle
L507-1578; 020-27
020.11.3 Drive shaft
L507-1578; 020-27
020.114 Tyres
L507-1578; 020-27
020.11.4.2 Special tyres 020-29
020.12 Working attachment 020-30
020.12.1 Quick coupler locking hydraulic cylinder
L507-1578; 020-30
020.13 Operator’s cab, heating and air conditioning 020-31
020.13.1 Dryer
L507-1578; 020-31
020.13.2 Pressure switches
L507-1578; 020-31
020.14 Lubrication system 020-32
020.14.1 Central lubrication pump EP1
L507-1578; 020-32
020.14.2 Progressive distributor
L507-1578; 020-32
020.14.2.1 MX-F 020-32
020.14.22 MX-F25 020-32
020.14.2.3 MX-F 45 020-32
020.1424 MX-F75 020-33
020.14.2.5 MX-F105 020-33
030 Maintenance 030-1
030.1 Maintenance and inspection schedule 030-9
030.2 Filling quantities and lubrication chart 030-14
