Liebherr R 9350 & R 994B Litronic Hydraulic Excavator Service Manual – PDF DOWNLOAD
FILE DETAILS:
Liebherr R 9350 & R 994B Litronic Hydraulic Excavator Service Manual – PDF DOWNLOAD
Language : English
Pages : 2924
Downloadable : Yes
File Type : PDF
DESCRIPTION:
Liebherr R 9350 & R 994B Litronic Hydraulic Excavator Service Manual – PDF DOWNLOAD
General:
1 Safety instructions:
Obey all safety instructions given in the Operating manual (which is included in the chapter “Operating
maintenance” of this Service manual).
Tightening:
3.1 Factory standard: tightening torques for screws on LIEBHERR Mining excavators
This section gives the torque values for screws in dry or greased condition. These torque tables must
be used unless a specific torque is given in the manual.
Use the 8.8 torque values from the tables that follow when:
Tightening an aluminium part without tapping insert
Tightening a welded nut
Tightening in GL grey cast iron (flake graphite cast iron), e.g. by splitterboxes, engine blocks or
cast counterweights (in addition with “medium strength” thread locker like Loctite 243)
Tightening of stainless steel screws (in addition with special stainless steel mounting oil/grease).
From screw size M20 and larger (except for screws with corrosion protective coating), grease must
be applied on the thread and under the screw head (use swing teeth grease):
Use a paintbrush or similar tool to apply the grease
Do not put grease inside the thread but on the screw
Do not put grease in excess on the screw.
