Liebherr R 9350 R 994B Hydraulic Excavator Service Manual – PDF DOWNLOAD
FILE DETAILS:
Liebherr R 9350 R 994B Hydraulic Excavator Service Manual – PDF DOWNLOAD
Language : English
Pages : 2973
Downloadable : Yes
File Type : PDF
DESCRIPTION:
Liebherr R 9350 R 994B Hydraulic Excavator Service Manual – PDF DOWNLOAD
1 Safety instructions:
Obey all safety instructions given in the Operating manual (which is included in the chapter “Operating
maintenance” of this Service manual).
Tightening:
3.1 Factory standard: tightening torques for screws on LIEBHERR Mining excavators
This section gives the torque values for screws in dry or greased condition. These torque tables must
be used unless a specific torque is given in the manual.
Use the 8.8 torque values from the tables that follow when:
Tightening an aluminium part without tapping insert
Tightening a welded nut
Tightening in GL grey cast iron (flake graphite cast iron), e.g. by splitterboxes, engine blocks or
cast counterweights (in addition with “medium strength” thread locker like Loctite 243)
Tightening of stainless steel screws (in addition with special stainless steel mounting oil/grease).
From screw size M20 and larger (except for screws with corrosion protective coating), grease must
be applied on the thread and under the screw head (use swing teeth grease):
Use a paintbrush or similar tool to apply the grease
Do not put grease inside the thread but on the screw
Do not put grease in excess on the screw.
TABLE OF CONTENTS:
Liebherr R 9350 R 994B Hydraulic Excavator Service Manual – PDF DOWNLOAD
1 General
2 Safe Work Procedures / Risk Assessment
3 Technical Data
4 Operating I Maintenance
5 Tooling
6 Engine
7 Attachment / Travel Systems
8 Swing System
9 Cooling Systems
10 Grease Systems
11 Ladder / Service Trap Systems
12 Hydraulic Track Tensioning System
13 Electrical Systems
14 Pneumatic Control
15 Uppercarriage – Mechanical
16 Undercarriage – Mechanical
17 Attachment – Mechanical
18 Heater I Air conditioning
19 Fire Suppression
20 Starting aids (optional)
21 Schematics
