Kramer Telehandler 4407 Spare Parts List Manual
FILE DETAILS:
Kramer Telehandler 4407 Spare Parts List Manual
Language : English, German, French
Pages : 479
Downloadable : YES
Format : PDF
Size : 52.8 MB
DESCRIPTION:
Kramer Telehandler 4407 Spare Parts List Manual
General information about spare parts manual :
When ordering spare parts, care must be taken to ensure that all information about the machine is complete. This includes the name of the model, the serial number and the year of construction. In the event of orders for motor or axle parts, the type and serial number of the components are also required. The following details are also necessary: material number and position number. The serial number is stamped on the machine chassis. It is also located on the type label. The serial number must be given in full.
- In the course of technical development, we work continuously to improve and optimize our products. For this reason the pictures in the spare parts manual can sometimes deviate from the actual model. We reserve the right to make changes to the spare parts at any time.
- This applies to the specified quantity of spare parts as well as to the technical model. In order to provide the latest information about the machine, we ask you to contact the appointed dealer. Technical information, dimensions, weights and the given quantity of spare parts are not binding. Responsibility for errors or omissions not accepted.
- The cover features the machine with possible optional equipment. The representation given is not binding for the actual model. The number of spare parts specified in the manual refers only to the quantity installed at this point. This spare parts manual shows options that are available for the vehicle direct from the factory.
- For this reason, options might be shown that are not compatible with your machine. Not all the options shown are available in all countries/regions. Some options can be retrofitted. However, please note that it is not possible to combine all options with each other. In some cases, parts are shown that are not available as spare parts. These parts are not itemized in the drawings. The portrayal is for clarification only and does not mean that the part shown can be ordered.
TABLE OF CONTENTS:
Kramer Telehandler 4407 Spare Parts List Manual
1 WARTUNG 25
1 1 WARTUNGSSATZ 1 DURCHSICHT 25
1 2 WARTUNGSSATZ 1 DURCHSICHT 27
1 3 WARTUNGSSATZ 2 DURCHSICHT 29
1 4 WARTUNGSSATZ 2 DURCHSICHT 31
1 5 WARTUNGSSATZ JÄHRLICH 33
1 6 WARTUNGSSATZ JÄHRLICH 35
1 7 SCHELLEN 37
1 8 DICHTUNGEN 47
2 MOTOR 49
2 1 MOTORLAGERUNG 49
2 2 MOTORBLOCK 51
2 3 MOTORTEILE 53
416-22 11 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
2 4 MOTOR ANBAUTEILE 55
2 5 ABGASANLAGE 57
2 6 ABGASANLAGE LRC 59
2 7 KRAFTSTOFFVERSORGUNG 61
2 8 ANSAUGANLAGE 67
2 9 ANSAUGANLAGE LRC 69
2 10 UNTERDRUCKVORABSCHEIDER 71
2 11 UNTERDRUCKVORABSCHEIDER 73
2 12 GASREGULIERUNG 75
2 13 BEHÄLTER HARNSTOFF 77
2 14 HARNSTOFF-FÖRDERPUMPE 79
2 15 HARNSTOFFVERSORGUNG 81
3 KÜHLUNG 85
416-22 12 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
3 1 LÜFTERANTRIEB 85
3 2 KÜHLUNG + LAGERUNG 89
4 ANTRIEBSEINHEITEN 93
4 1 GETRIEBELAGERUNG 93
4 2 FAHRANTRIEB KREISLAUF 95
4 3 FAHRANTRIEB KÜHLKREISLAUF 99
4 4 VERSTELLPUMPE 101
4 5 SCHNELLGANGGETRIEBE 105
4 6 SCHNELLGANGGETRIEBE 107
5 ACHSEN 109
5 1 ACHSEN-BEFESTIGUNG 109
5 2 GELENKWELLEN 111
5 3 VORDERACHSE 113
416-22 13 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
5 4 WINKELTRIEB 115
5 5 DIFFERENTIAL 117
5 6 BREMSE 119
5 7 DOPPELGELENKWELLE 121
5 8 HINTERACHSE 123
5 9 WINKELTRIEB 125
5 10 DIFFERENTIAL 127
5 11 DIFFERENTIAL_SPERRE 129
5 12 BREMSE 131
5 13 DOPPELGELENKWELLE 133
5 14 LENKZYLINDER 135
5 15 RADNABE 137
6 BREMSANLAGE 139
416-22 14 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
6 1 BREMSPEDAL 139
6 2 BETRIEBSBREMSE 141
6 3 ANHAENGER BREMSE 149
7 LENKUNG 153
7 1 LENKSÄULE 153
7 2 KREISLAUF LENKUNG-PUMPE-TANK 155
7 3 LENKUNG 159
8 ARBEITSHYDRAULIK 163
8 1 ÖLBEHÄLTER 163
8 2 STEUERGERÄT BEFESTIGUNG 165
8 3 HYDRAULIKPUMPE 167
8 4 VERSTELLPUMPE 169
8 5 STEUERGERÄT 4-FACH LS 171
416-22 15 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
8 6 STEUERGERÄT 5-FACH LS 173
8 7 STEUERGERÄT 6-FACH LS 175
8 8 STEUERGERÄT 7-FACH LS 177
8 9 HUBZYLINDER 179
8 10 KIPPZYLINDER 181
8 11 AUSSCHUBZYLINDER 183
8 12 AUSGLEICHSZYLINDER 185
8 13 KREISLAUF-HUBZYLINDER 187
8 14 KREISLAUF-AUSSCHUBZYLINDER 191
8 15 KREISLAUF-KIPPZYLINDER 193
8 16 KREISLAUF-AUSGLEICHSZYLINDER 195
8 17 3 STEUERKREIS 197
8 18 STEUERKREIS VORN 201
416-22 16 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
8 19 3 STEUERKREISL MULTIKUPPLER 2-FACH 205
8 20 3 STEUERKREISL MULTIKUPPLER 4-FACH 207
8 21 KREISLAUF LASTSTABILISATOR 209
8 22 KREISLAUF KIPPER 213
8 23 ZUSATZSTEUERKREIS HI 215
8 24 ZUSATZSTEUERKREIS AUSSEN 217
8 25 KREISLAUF TANK-PUMPE-STEUERGERÄT 223
8 26 KREISLAUF STEUERGERÄT-TANK 225
8 27 ARBEITSHYDRAULIK – STEUERGERÄT 227
8 28 HITCH + KIPPER + ZUSATZSTEUERKREIS 229
8 29 KREISLAUF – ABSCHALTVENTIL 233
8 30 KREISLAUF DRUCKENTLASTUNG 237
8 31 SCHMIERLEITUNGEN 239
416-22 17 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
8 32 ZENTRALSCHMIERANLAGE 241
8 33 ZENTRALSCHMIERANLAGE 243
9 ELEKTRISCHE ANLAGE 245
9 1 FAHRZEUGBELEUCHTUNG 245
9 2 ARMATURENBRETT 249
9 3 ARMATURENBRETT 251
9 4 ARMATUREN – DACH 253
9 5 PLATINE 255
9 6 KABINENKABELBAUM 257
9 7 RAHMENKABELBAUM 265
9 8 MOTORKABELBAUM 269
9 9 KABELBAUM HEIZUNG/KLIMA 275
9 10 MOTOR-ÖLVORWÄRMUNG 277
416-22 18 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
9 11 KABELBAUM ÖLVORWÄRMUNG 279
9 12 KABELBAUM SCHNELLWECHSELPLATTE 281
9 13 KABELBAUM SCHNELLWECHSELPLATTE 283
9 14 KABELBAUM SCHNELLWECHSELPL – MULTIKUP 285
9 15 KABELBAUM SCHEIBENHEIZUNG 287
9 16 KABELBAUM SCHAUFELRÜCKFÜHRAUTOMATIK 289
9 17 KABELBAUM HARNSTOFF KABINE 291
9 18 KABELBAUM LUFTFILTER-EAT-KONSOLE-DOC 293
9 19 KABELBAUM LUFTFILTER-EAT-KONSOLE-LRC 295
9 20 KABELBAUM LUFTFILTER-EAT-KONSOLE-DPF 297
9 21 KABELBAUM ARMLEHNE 301
9 22 ELEKTRISCHER AUSSENSPIEGEL 303
9 23 KABELBAUM P370 305
416-22 19 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
9 24 ELEKTRIK-KOMPONENTEN 307
9 25 STEUERHEBEL INCL EL VORSTEUERGERAET 309
9 26 BATTERIE-BATTERIEKABEL 311
9 27 KENNZEICHENBELEUCHTUNG 313
9 28 POTENTIOMETER 315
9 29 ELEKTRIK TELESKOPARM 317
9 30 BELEUCHTUNG LED 321
9 31 BELEUCHTUNG HUBARM LED 323
9 32 STECKDOSE 325
9 33 RADIO 327
9 34 TELEMATIC 329
9 35 KAMERA SICHT 331
9 36 KAMERA HECK 333
416-22 20 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
10 RÄDER 335
10 1 BEREIFUNG 335
10 2 BEREIFUNG 339
11 FAHRWERK / RAHMEN 341
11 1 RAHMEN 341
12 VERKLEIDUNGEN 343
12 1 RADABDECKUNG 343
12 2 MOTORHAUBE 345
12 3 UNTERFAHRSCHUTZ 347
12 4 VERKLEIDUNGEN 349
12 5 ABDECKUNGEN 353
13 LADEANLAGE / ARMSYSTEM 355
13 1 TELESKOPAUSLEGER 355
416-22 21 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
13 2 LAGERUNG 359
13 3 KIPPHEBEL 363
13 4 SCHNELLWECHSELPLATTE 365
13 5 SCHNELLWECHSELPLATTE 367
13 6 SCHNELLWECHSELPLATTE 369
13 7 SCHNELLWECHSELPLATTE 373
13 8 SCHNELLWECHSELLPLATTE 375
13 9 SCHNELLWECHSELLPLATTE 377
13 10 ÜBERLASTBEGRENZUNG 381
13 11 SCHAUFELRÜCKFÜHRAUTOMATIK 383
14 FAHRERKABINE, FAHRERSITZ 385
14 1 FAHRERKABINE 385
14 2 KABINEN SCHEIBEN 389
416-22 22 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
14 3 HECKSCHEIBE 391
14 4 KABINENTÜR OBEN 393
14 5 KABINENTÜR UNTEN 395
14 6 WISCHERANLAGE 397
14 7 WISCHERANLAGE RECHTS 399
14 8 SPIEGEL 401
14 9 FAHRERKABINE VERKLEIDUNGEN 403
14 10 DÄMMATTEN 407
14 11 STAUFACH 409
14 12 FAHRERSITZ-BEFESTIGUNG 411
14 13 FAHRERSITZ 413
14 14 FAHRERSITZ LUFTGEFEDERT 417
14 15 SITZHEIZUNG 421
416-22 23 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
15 HEIZUNG, KLIMAANLAGE 423
15 1 HEIZUNG 423
15 2 KLIMAANLAGE 427
16 AUFKLEBER, WERKZEUG 431
16 1 AUFKLEBER 431
16 2 AUFKLEBER 435
16 3 WERKZEUG 437
16 4 DOKUMENTE 439
17 ANBAUGERÄTE 441
17 1 SCHAUFEL 441
17 2 SCHAUFEL 443
17 3 SCHAUFEL 445
17 4 SCHAUFEL 447
416-22 24 / 476
Inhaltsverzeichnis / Table des matières / Table of Contents
17 5 STAPELEINRICHTUNG 449
17 6 STAPELEINRICHTUNG 451
17 7 STAPELEINRICHTUNG 453
17 8 STAPELEINRICHTUNG 455
17 9 ANHAENGEKUPPLUNG 457
17 10 ANHAENGEKUPPLUNG 459
17 11 ANHAENGEKUPPLUNG 463
17 12 ANHAENGEKUPPLUNG 465
17 13 ANHAENGEKUPPLUNG 467
17 14 RANGIERKUPPLUNG 469
17 15 SPIEGEL ANHAENGEKUPPLUNG 471
17 16 HITCH 473
