Kobelco Sk80msr 1e Crawler Excavator Service Repair Manual Lf02 -01001 Lf03-01280
FILE DETAILS:
LANGUAGE:ENGLISH
PAGES:894
DOWNLOADABLE:YES
FILE TYPE:PDF
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Kobelco Sk80msr 1e Crawler Excavator Service Repair Manual Lf02 -01001 Lf03-01280
The servicemen or mechanic may be unfamiliar with many of the systems on this machine. This makes it important to use caution when performing service work. A knowledge of the system and or components is important before the removal or disassembly of any component Because of the size of some of the machine components, the serviceman or mechanic should check the weights noted in this Manual. Use proper lifting procedures when removing any components. Following is a list of basic precautions that should always be observed.
1. Read and understand all Warning plates and decals on the machine before operating, lubricating or repairing this product.
2. Always wear protective glasses and protective shoes when working around machines. In particular, wear protective glasses when pounding on any part of the machine or its attachments with a hammer or sledge. Use welders gloves, hood/goggles, apron and other protective clothing appropriate to the welding job being performed. Do not wear loosevfitting or torn clothing. Remove all rings from fingers when working on machinery.
3. Disconnect battery and discharge any capacitors before starting to work on machine. Hang “Do Not Operate” tag in the Operator’s Cab.
4. If possible, make all repairs with the machine parked on a level. hard surface. Block machine so it does not roll while working on or under machine.
5. Do not work on any machine that is supported only by lift jacks or a hoist. Always use blocks or jack stands to support the machine before performing any disassembly.
6. Relieve all pressure in air, oil or water systems before any lines, fittings or related items are disconnected or removed. Always make sure all raised components are blocked correctly and be alert for possible pressure when disconnecting any device from a system that utilizes pressure.
7. Lower the bucket, blade. ripper or other attachment to the ground before performing any work on the machine. If this cannot be done, make sure the bucket, blade, ripper or other attachment is blocked correctly to prevent it from dropping unexpectedly.
8. Use steps and grab handles when mounting or dismounting a machine. Clean any mud or debris from steps, walkways or work platforms before using. Always face machine when using steps. ladders and walkways. When it is not possible to use the designed access system. provide ladders. scaffolds, or work platforms to perform safe repair operations.
9. To avoid back injury, use a hoist when lifting components which weigh 23 kg (50 lb) or more. Make sure all chains, hooks, slings, etc., are in good condition and are in the correct capacity. Be sure hooks are positioned correctly. Lifting eyes are not to be side loaded during a lifting operation.
10. To avoid burns, be alert for hot parts on machines which have just been stopped and hot fluids in lines, tubes and components.
TABLE OF CONTENTS:
Kobelco Sk80msr 1e Crawler Excavator Service Repair Manual Lf02 -01001 Lf03-01280
- OUTLINE I
- SPECIFICATION I
- ATTACHMENT DIMENSION I
- TOOLS I
- STANDARD MAINTENANCE
- TIME SCHEDULE
- MAINTENANCE STANDARD AND’
- TEST PROCEDURE
- MECHATRO CONTROL
- SYSTEM
- HYDRAULIC SYSTEM
- ELECTRICAL SYSTEM
- COMPONENTS SYSTEM
- AIR-CONDITIONER SYSTEM
- DISASSEMBLING AND
- ASSEMBLING
- ATTACHMENT
- UPPER STRUCTURE
- TRAVEL SYSTEM
- MECHATRO CONTROL I
- HYDRAULIC
- ELECTRICAL
- ENGINE
