Kobelco SK110 SK130 SK130LC Operator’s Manual PDF

Description

Kobelco SK110 SK130 SK130LC Hydraulic Excavator Operator’s Manual – PDF DOWNLOAD

FILE DETAILS:

Kobelco SK110 SK130 SK130LC Hydraulic Excavator Operator’s Manual – PDF DOWNLOAD

Language : English
Pages : 152
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Kobelco SK110 SK130 SK130LC Hydraulic Excavator Operator’s Manual – PDF DOWNLOAD

IMPORTANT INFORMATION 0-1
FOREWORD 0-2
ORDERING SPARE PARTS 0-3
SAFETY 0-4
CHAPTER 1 SAFETY
SAFETY
PROHIBITED MACHINE OPERATION 1-1
PRECAUTIONS DURING OPERATION 1-5
PRECAUTIONS DURING INSPECTIONS AND MAINTENANCE 1-9
PRECAUTIONS WHEN HANDLING BATTERIES
WARNING LABEL
HANDLING OF WARNING LABELS 1 – 13
WARNING LABEL POSITION
PROHIBITED MACHINE OPERATION
SAFETY PROCEDURES TO COMPLETE
AFTER SUDDEN ENGINE FAILURE
CHAPTER 2 OPERATING EQUIPMENT
1-21
LOCATION OF COMPONENTS 2-1
ARRANGEMENT OF OPERATING CONTROLS
OPERATING CONTROLS
CONTROL CONSOLE AND SWITCHES 2-3
ARRANGEMENT AND OPERATION OF LEVERS 2-7
CLUSTER GAUGE PANEL 2-11
SWITCH PANEL 2-14
FUSE BOX 2-15
CAB 2-16
OPERATOR’S SEAT 2-18
SEAT BELT
CHAPTER 3 OPERATION
STARTING AND STOPPING THE ENGINE 3-1
OPERATING PROCEDURE 3-4
OPERATING METHODS FOR IMPROVING EFFICIENCY 3-12
CHAPTER 4 MAINTENANCE
INTRODUCTION 4-1
TIGHTENING TORQUE OF CAP SCREWS
AND NUTS (SK1101V) 4-4
TIGHTENING TORQUE OF CAP SCREWS AND NUTS
(SK1301V SK130LC1V) 4-5
TIGHTENING TORQUE OF CAP SCREWS AND NUTS 4-6
TIGHTENING THE TORQUE OF COUPLINGS
AND HYDRAULIC HOSES 4-7
REGULAR MAINTENANCE ITEMS AND INTERVALS 4-8
LUBRICATION AND FILTER CHART 4-11
LIST OF OILS, GREASES, FILTERS
AND ELEMENTS (SK1101V)
LIST OF OILS, GREASES, FILTERS AND ELEMENTS
(SK1301V / SK130LCTV) 4-13
ENGINE MAINTENANCE PROCEDURES 4-14
MAINTENANCE OF HYDRAULIC TANK 4-20
PILOT SYSTEM FILTER 4-21
MAINTENANCE PROCEDURE FOR
THE SWING POWER TRAIN 4-23
MAINTENANCE PROCEDURE FOR
THE TRAVEL MOTOR REDUCTION UNIT 4-25
MAINTENANCE PROCEDURE FOR’ ATTACHMENTS 4-27
REPLACING ATTACHMENT DUST SEAL 4-32
INSPECTION AND MAINTENANCE OF
ELECTRICAL EQUIPMENT 4-33
PERIODICAL PREVENTIVE MAINTENANCE INSPECTION·· 4-36
MACHINE STORAGE 4-37
CHAPTER 5 TRANSPORTATION
TRANSPORTATION 5-1
TRANSPORTATION WEIGHT (SK110TV) 5-3
TRANSPORTATION WEIGHT (SK130TV / SK130LCTV) 5-6
CHAPTER 6 SPECIFICATIONS
MACHINE DIMENSIONS (SK110TV) 6-1
MACHINE DIMENSIONS (SK130TV / SK130LCTV) 6-2
SPECIFICATIONS AND PERFORMANCE (SK110TV) 6-3
SPECIFICATIONS AND PERFORMANCE
(SK130TV / SK130LCTV) 6-4
TYPE OF SHOES (SK110TV) 6-5
TYPE OF SHOES (SK130TV / SK130LCTV) 6-5
TYPE OF BUCKETS (SK110TV) 6-6
TYPE OF BUCKETS (SK130TV / SK130LCTV) 6-6
COMBINATIONS OF ATTACHMENTS (SK110TV) 6-8
COMBINATIONS OF ATTACHMENTS
(SK130TV / SK130LCTV) 6-9
WORKING RANGES OF ATTACHMENTS (SK110TV) 6-10
WORKING RANGES OF ATTACHMENTS
(SK130TV / SK130LCTV) 6-12
WORKING RANGES OF ATTACHMENTS (CLAMSHELL)
(SK110TV) 6-14
WORKING RANGES OF ATTACHMENTS (CLAMSHELL)
(SK130TV / SK130LCTV) 6-15
WEIGHT OF COMPONENTS (SK110TV) 6-16
WEIGHT OF COMPONENTS (SK130TV / SK130LCTV) 6-17
ELECTRIC CIRCUIT DIAGRAM 6-18
RATED OBJECT HANDLING CAPACITIES TABLE 6-20
EC REGULATION APPROVED 6-22
CHAPTER 7 TROUBLESHOOTING 1-1
CHAPTER 8 BREAKER & OPTIONAL ATTACHMENTS
HYDRAULIC BREAKER S-1
