JCB Engines Perkins 402D, 403D, 404D Systems, Operation, Testing and Adjusting Manual
FILE DETAILS:
JCB Engines Perkins 402D, 403D, 404D Systems, Operation, Testing and Adjusting Manual
Size: 11.2 MB
Fomat: PDF
Language: English
Brand: JCB
Type of machine: Engines Perkins 402D, 403D, 404D
Type of document: Systems, Operation, Testing and Adjusting
Model: 9806-5400
Page of number: 68
DESCRIPTION:
JCB Engines Perkins 402D, 403D, 404D Systems, Operation, Testing and Adjusting Manual
GENERAL INFORMATION:
The 4020-05, 4030-07. 4030-11, 4030-15. 4030-1 5T. 4030-17. 404015. 4040-22.4mo-221* and 4040-22TA engines are diesel engines that are controlled with a mechanically actuated fuel injection pump. The engine cylinders are arranged inline. The cylinder head assembly has one inlet valve and one exhaust valve for each cylinder. Each cylinder valve has a single valve spring. The pistons have two compression rings and an all control ring.
It Is Important to ensure the correct piston height so that the piston does not contact the cylinder head. The correct piston height also ensures the efficient combustion of fuel which is necessary in order to conform to requirements tor emissions. The crankshaft for the 4020-05 engine has two main bearing jcumals. The crankshaft tor the 4030-07. 4030-11, 4030-15, 4030-15I’ and 4030-17 engines have tour main bearing journals.
The crankshaft for the 4040-15, 41040-22, 4040-22T and 4040-22TA engines have five main bearing journals. End play for all the engines is controlled by the thrusl washers that are located on the rear main bearing. The 4030—11, 4040-15 and 4040-15 engines have aluminium bearing caps on the rear main bearing that act as thrust washers. The timing gears are stamped with timing marks in order to ensure the correct alignment of the gears during assembly.
When the No. 1 piston is at top center compression stroke. the teeth that are stamped on the crankshaft gear and the camshaft gear will be In alignment with the idler gear. The crankshaft gear turns the idler gear which then turns the camshaft gear. The fuel injection pump and the fuel priming pump are mounted on the cylinder block. Both pumps are operated by the camshaft lobes.
