Ingersoll Rand RT-706H 708H Rough Terrain Forklift Parts Manual – PDF DOWNLOAD
DESCRIPTION:
Ingersoll Rand RT-706H 708H Rough Terrain Forklift Parts Manual – PDF DOWNLOAD
- Ingersoll -I-(and’s Word Index well make this Item easy to locate. I he Word Index IS found In the very back of the book. The items listed are in alphabetical order and may be repeated several times depending on their functional descriptions.
- Let’s assume you need to replace the PRIMARY AIR CLEANER FILTER ELEMENT.
- Use any of the functional words in the item description to locate the desired item. Example: The first listing for the Primary Air Cleaner Filter Element in the Word Index is: Air Cleaner Primary Filter Element. The index shows the component will be found on page C-45 that is the Parts List page number for the Air Cleaner And Exhaust Installation.
Using the Parts Identification Pages: •
- The PARTS IDENTIFICATION PAGES consist of the PARTS ILLUSTRATION (even numbered pages) and the PARTS LIST (odd numbered pages). •
- The Parts Illustration shows the assembly with its component parts identified by Item Numbers.
- • On the Parts List, the components are listed in Item Number order as found in the ITEM column. Other information provided by the Parts List is the Comm.
- Number which will be required to order Genuine Ingersoll-Rand Replacement Parts, a functional description, the quantity required to assemble one complete assembly, and any additional notes/ dimensions required to help place your parts order. • For the example: The Air Cleaner Primary Filter Element is listed under the Air Cleaner (Item 1), Comm. Number 59155119, Quantity of 1.
TABLE OF CONTENTS:
Ingersoll Rand RT-706H 708H Rough Terrain Forklift Parts Manual – PDF DOWNLOAD
TITLE PAGE
TABLE OF CONTENTS . A
ABBREVIATIONS USED IN THIS MANUAL . D
LUBRICANTS, FILTERS AND MANUALS . F
RECOMMENDED SERVICE PARTS H
Section A – Frame
FENDER INSTALLATION . A-
HOOD INSTALLATION . A-
STEP INSTALLATION A-
COUNTERWEIGHT INSTALLATION A-
MAST PIVOT INSTALLATION A-
Section B – Axle and Tires
DRIVE AXLE INSTALLATION B-
DRIVE AXLE () – INTERNAL BREAKDOWN B-
WD STEERING AXLE INSTALLATION B-
AXLE – -WHEEL DRIVE STEERING () – INTERNAL BREAKDOWN
WD STEERING DRIVE AXLE INSTALLATION
AXLE (WD STEERING) () – INTERNAL BREAKDOWN .
SERVICE BRAKE INSTALLATION
PARKING BRAKE INSTALLATION
Section C – Engine and Transmission
ENGINE AND TRANSMISSION MOUNTING INSTALLATION
WD TRANSMISSION/DRIVELINE INSTALLATION
TRANSMISSION () – INTERNAL BREAKDOWN .
EXHAUST INSTALLATION C-
ALTERNATOR INSTALLATION C-
THROTTLE INSTALLATION . C-
THROTTLE PEDAL ASSEMBLY . C-
FUEL LINE INSTALLATION . C-
RADIATOR INSTALLATION . C-
ETHER COLD START INSTALLATION – OPTIONAL C-
B
TABLE OF CONTENTS
RT-H/H – Effective With (See Cover)
TITLE PAGE
Section D – Operators Station
OVERHEAD GUARD INSTALLATION . D-
CONSOLE ASSEMBLY . D-
SWITCH PANEL ASSEMBLY D-
DECK INSTALLATION . D-
MANUAL POUCH INSTALLATION D-
SEAT INSTALLATION D-
SOLID SEAT () – INTERNAL BREAKDOWN D-
SUSPENSION SEAT () – INTERNAL BREAKDOWN D-
SEAT SUPPORT INSTALLATION . D-
GAUGE PANEL INSTALLATION D-
INSTRUMENT PANEL ASSEMBLY – STANDARD D-
INSTRUMENT PANEL ASSEMBLY – OPTIONAL D-
STEERING WHEEL INSTALLATION D-
STEERING ORBITAL () – INTERNAL BREAKDOWN . D-
VANDAL COVER INSTALLATION – OPTIONAL D-
HEATER/DEFROSTER INSTALLATION D-
DEFROSTER INSTALLATION . D-
FLOOR MAT INSTALLATION D-
WIPER INSTALLATION . D-
MIRROR INSTALLATION . D-
ENCLOSED CAB INSTALLATION D-
ENCLOSED CAB () – INTERNAL BREAKDOWN . D-
SAFTEY LABEL MANUAL INSTALLATION . D-
Section E – Electrical
BATTERY INSTALLATION E-
HORN INSTALLATION . E-
WORK/ROAD LIGHT INSTALLATION . E-
MAIN WIRING HARNESS INSTALLATION E-
BACKUP ALARM INSTALLATION E-
WD/WD CONTROL INSTALLATION . E-
SENDER INSTALLATION . E-
DOME LIGHT INSTALLATION . E-
C
TABLE OF CONTENTS
RT-H/H – Effective With (See Cover)
TITLE PAGE
Section F – Masts and Carriages
MAST PIVOT INSTALLATION F-
MAST/CARRIAGE ASSEMBLY – MV . F-
MAST/CARRIAGE ASSEMBLY – FL F-
MAST/CARRIAGE ASSEMBLY – MV . F-
MAST ASSEMBLY () AND () – INTERNAL BREAKDOWN F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
MAST/CARRIAGE ASSEMBLY – FL F-
MAST/CARRIAGE ASSEMBLY – MV . F-
MAST ASSEMBLY () – INTERNAL BREAKDOWN F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
MAST/CARRIAGE ASSEMBLY – FL F-
MAST/CARRIAGE ASSEMBLY – MV . F-
MAST ASSEMBLY () – INTERNAL BREAKDOWN F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
MAST/CARRIAGE ASSEMBLY – FL F-
MAST/CARRIAGE ASSEMBLY – FL F-
MAST/CARRIAGE ASSEMBLY – MV . F-
MAST ASSEMBLY () – INTERNAL BREAKDOWN F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN
CARRIAGE ASSEMBLY () – INTERNAL BREAKDOWN . F-
LOAD BACKREST INSTALLATION
FORKS INSTALLATION – OPTIONAL
Section G – Decals and Paint
DECAL INSTALLATION
MODEL DECAL INSTALLATION
Section H – Hydraulics
HYDRAULIC SUPPLY AND RETURN INSTALLATION
CONTROL VALVE INSTALLATION
DIRECTIONAL VALVE INSTALLATION
THREE SECTION DIRECTIONAL VALVE () – INTERNAL BREAKDOWN
FOUR SECTION DIRECTIONAL VALVE () – INTERNAL BREAKDOWN
MAST SIDE SHIFT INSTALLATION
MAST TILT INSTALLATION
MAST LIFT INSTALLATION
