Genie Z33/18 Parts Manual 1257101 – PDF DOWNLOAD
Language : English
Pages : 144
Downloadable : Yes
File Type : PDF
Table of Contents:
Genie Z33/18 Parts Manual 1257101 – PDF DOWNLOAD
100 Decals
101 1 608530 Safety Decals
101 2 608569 Safety Decals – ANSI
102 1 608531 Decals With Symbols
103 1 608571 Decals With Words
200 Chassis Components
201 1 608532 Front Axle Assembly
202 1 608533 Rear Axle Assembly
203 1 608534 Drive Chassis Components – View 1
204 1 608535 Drive Chassis Components – View 2
205 1 608536 Power Cables
206 1 608537 Battery Charger
300 Turntable Components
301 1 608538 Turntable Rotator
302 1 608539 Turntable Components – View 1
303 1 608540 Turntable Components – View 2
304 1 608541 Ground Control Box – View 1
305 1 608542 Ground Control Box – View 2
306 1 608543 Turntable Cover – View 1
307 1 608544 Turntable Cover – View 2
308 1 608545 Wire Harness Diagram
400 Boom Components
401 1 608546 Boom Pins and Bearings – View 1
402 1 608547 Boom Pins and Bearings – View 2
403 1 608548 Cable Track
404 1 608549 Secondary Linkage
405 1 608550 Primary Boom Wear Pads
406 1 608551 Platform Leveling – UE Version
406 2 608561 Platform Leveling – USA Version
407 1 608552 Mid Pivot
500 Pumps and Manifolds
501 1 608553 Hydraulic Power Unit
502 1 608554 Functions Manifold
600 Platform Components
601 1 608555 Platform Components
602 1 608556 Platform Control Box – View 1
603 1 608557 Platform Control Box – View 2
604 1 608558 Joystick Controller
700 Hydraulic Hoses and Fittings
701 1 608559 Turntable Components
702 1 608560 Cylinders
800 Accessories
801 1 608562 Flashing Beacon
802 1 608563 Supply Power – UK Plug 110V
803 1 608564 Supply Power – US Plug 110V
804 1 608565 Supply Power – EU Plug 220V
805 1 608566 Supply Power – No Plug 110/230V
806 1 608567 Air Line To Platform
807 1 608568 Control Box Cover
808 1 608572 Work And Road Lights
809 1 608573 Lift Guard Contact Alarm (from November 2017) – View 1
809 2 608574 Lift Guard Contact Alarm (from November 2017) – View 2
810 1 608576 Power To Platform RCBO
811 1 Telematics Option (from SN Z331815M-124)
